Repairing the Tubeset Connector Assembly

23.1 Remove and discard the adhesive label (Fig 51, Item 50) from the rear of the connector
assembly (Refer to Figure 53).
Note: A new label must always be fitted after any repair, since the old label is easily damaged
and will not stick properly to the connector assembly after it has been re-assembled.
Connector Assembly
23.2 Remove the rear cover (Fig 51, Item 30) from the front cover (Fig 51, Item 20), as follows (Refer
to Figure 54):
23.2.1 At one corner at the bottom of the connector assembly, carefully insert a small flat-
bladed screwdriver between the front cover and rear cover.
23.2.2 Pull this bottom corner of the rear cover outwards, to release it from the front cover.
23.2.3 Repeat Paras 23.2.1 and 23.2.2 to release the other bottom corner of the rear cover.
23.2.4 Pull the rear cover downwards to release the top of the rear cover from the front cover.
Front Cover
23.3 Remove the front cover (Fig 51, Item 20) from the connector body (Fig 51, Item 10), as follows
(Refer to Figure 55):
23.3.1 Push the connector body downwards and the front cover upwards to compress the two
springs (Fig 51, Item 40).
23.3.2 When fully compressed, carefully insert a small flat-bladed screwdriver between the top
of the connector body and the slot in the top centre of the front cover, and push the top
of the connector body out of the slot in the front cover.
23.3.3 Lift the bottom of the connector body, together with the two springs, out of the bottom of
the front cover.
23.3.4 Remove the two springs from the connector body.
Issue 2
April 2010
Figure 53 - Replacing the Label
Rear Cover
Step 2: Pull the bottom corner of the Rear Cover outwards
Step 3: Pull the Rear Cover downwards
Step 1: Insert a Flat-Bladed Screwdriver at the bottom corner
Figure 54 - Removing the Rear Cover
SER0001
Mattress Repair
Label
