Nimbus/DFS Service Manual
4

Disassembling the Rear Case

WARNING: BEFORE DISMANTLING THE PUMP UNIT, ENSURE THE UNIT HAS BEEN
ISOLATED FROM THE POWER SUPPLY BY REMOVING THE MAINS/POWER
PLUG FROM THE WALL SOCKET.
4.1 Remove the hanging bracket from the pump (Refer to Chapter 3, Page 3, Section 2).
4.2 Place the pump unit on a flat surface with the front case (Fig 4, Item 20) face down.
4.3 Unscrew the 8 pan head screws (Fig 4, Item 30) and lift the rear case (Fig 4, Item 10) away from
the front case (Fig 4, Item 20). Keep the screws (Fig 4, Item 30) in a safe place.
4.4 Carefully remove the neoprene sponge cord (Fig 4, Item 40) and inspect for damage.
5

Assembling the Rear Case

5.1 Assembly of the rear case is in the reverse order of disassembly.
5.2 Install the hanging bracket to the pump (Refer to Page 3, Section 3).
Item Part Number
10 151052
20 151307
30 FAS188
40 151105
50 507413
Issue 2
April 2010
Table 3 - Rear Case Parts List
Rear Case Assembly
Front Case
Pan Head Screws M4 x 30 mm
Neoprene Sponge Cord (Dia 2 mm)
Rubber foot
SER0001
Description
Pump Repair
Qty
1
1
8
1
8
Chap 3
Page 5
