Getinge Arjohuntleigh NIMBUS II Service Manual page 76

Pump Repair
Figure 32 - Replacing the Bio Filter (Nimbus 3 and DFS 3 Pumps Only)
Item Part Number
10 151450
20 151444
30 SW393
- BP196
40 BP044
Chap 3
Page 58
Corner Adaptor
Cable Ties
Table 25 - Bio Filter Part List
Bio Filter (Nimbus 3, DFS3 only)
Bio Filter Label (Nimbus 3, DFS3 only)
Silicon tube, Blue ID 6mm, OD 10mm
Cable Tie
Filter Inlet (Nimbus 3 only)
SER0001
Nimbus/DFS Service Manual
Wires fromPower Switch
(Blue and Brown)
Description
to Fuse Holder
10
40
Qty
1
1
A/R
A/R
2
Issue 2
April 2010
