Z-Fold Half Sheet (shown here with 3-hole punch)
As with a regular Z-Fold, it has two folds that are folded in the opposite directions. The
difference between a regular Z-Fold and a Z-Fold Half Sheet is that the Z-Fold Half
Sheet is not folded in two equal folds. The two folds are unequal which allows one edge
of the Z-Fold Half Sheet to have a longer edge, and the longer edge allows for stapling
or hole punching.
Loading Paper or Tabs in the Post-Process Inserter (Tray T1)
1. If necessary, remove any remaining media that is currently loaded in Tray T1.
2. Hold the center of the paper guides and slide them to their desired paper size.
3. Load the paper or tabs, aligning it to the front side of the tray.
a) If the paper is preprinted, load the paper with the printed side facing up.
b) If the media is tab stock, load the tab side to be fed first (in the direction of the
arrow as shown in the above illustration).
4. From the Tray Properties window, enter the correct paper information, including size,
type, weight, and if needed, decurler and / or alignment option.
5. Select OK to save the information and close the Tray Properties window.
Finishing Transport
Finishing Transport Main Components
The Finishing Transport is comprised of the following components:
®
®
Xerox
Versant
2100 Press
User Guide
Standard Finisher Plus
18-7
