1.9 Technical Data

1.9.4.1 Pin assignment

Note
The red dot marks pin 1.
Directions of the PCIe signals (Transmitter/Receiver) are from the FPGA to the add-in card.
MATRIX VISION GmbH
Pin Signal
A1 -
A2 GND
A3 PCIe_RX0_P
A4 PCIe_RX0_N
A5 GND
A6 PCIe_RX1_P
A7 PCIe_RX1_N
A8 GND
A9 -
A10 WAKE_PCIE
A11 GND
A12 PCIe_CLK_P
A13 PCIe_CLK_N
A14 GND
A15 PCIe_RX2_P
A16 PCIe_RX2_N
A17 GND
A18 PCIe_RX3_P
A19 PCIe_RX3_N
A20 GND
A21 PWR_IN (p. 52)
B1 PWR_IN (p. 52)
B2 GND
B3 PCIe_TX0_P
B4 PCIe_TX0_N
B5 GND
B6 PCIe_TX1_P
B7 PCIe_TX1_N
B8 GND
B9 -
B10 -
B11 GND
B12 PCIe_PERST
_N
B13 CPRSNT
B14 GND
B15 PCIe_TX2_P
B16 PCIe_TX2_N
B17 GND
B18 PCIe_TX3_P
B19 PCIe_TX3_N
B20 GND
B21 -
Description
Do not connect
Ground
PCIe Receiver IN (differential)
PCIe Receiver IN (differential)
Ground
PCIe Receiver IN (differential)
PCIe Receiver IN (differential)
Ground
Do not connect
IN CWAKE
Ground
IN PCIE_CLK +
IN PCIE_CLK +
Ground
PCIe Receiver IN (differential)
PCIe Receiver IN (differential)
Ground
PCIe Receiver IN (differential)
PCIe Receiver IN (differential)
Ground
Power-In
Power-In
Ground
PCIe Transmitter OUT (differential)
PCIe Transmitter OUT (differential)
Ground
PCIe Transmitter OUT (differential)
PCIe Transmitter OUT (differential)
Ground
Do not connect
Do not connect
Ground
IN Reset
IN PRESENT
Ground
PCIe Transmitter OUT (differential)
PCIe Transmitter OUT (differential)
Ground
PCIe Transmitter OUT (differential)
PCIe Transmitter OUT (differential)
Ground
Do not connect
