1.13 GenICam and advanced features

1.13.7 Color Transformation Control

The "Color Transformation Control" contains features like
Feature name (acc.
(p. 121))
ColorTransformationSelector
ColorTransformationSelector
ColorTransformationValue
ColorTransformationValueSelector
related to the control of the color transformation.
This control offers an enhanced color processing for optimum color fidelity using a color correction matrix (CCM)
and enables
• 9 coefficients values (Gain
• 3 offset values (Offset
to be entered for RGB
IN
temperatures.
Coefficients will be made available for sensor models and special requirements on demand.
See also
Optimizing the color/luminance fidelity of the camera (p. 138)
MATRIX VISION GmbH
to SFNC Property name (acc. to mvIMPACT
Acquire (p. 119))
colorTransformationEnable
colorTransformationSelector
colorTransformationValue
colorTransformationValueSelector
.. Gain ) and
00 22
.. Offset )
0 2
- RGB transformation. This can be used to optimize specific colors or specific color
OUT
Figure 4: Color correction sample
Description
Activates the selected color trans-
formation module.
Selects which color transformation
module is controlled by the various
color transformation features.
Represents the value of the se-
lected Gain factor or Offset inside
the transformation matrix.
Selects the gain factor or Offset
of the Transformation matrix to ac-
cess in the selected color transfor-
mation module.
