1.13.3 Image Format Control

The "Image Format Control" contains features like
Feature name (acc.
(p. 121))
SensorWidth
SensorHeight
SensorName
Width
Height
BinningHorizontal, BinningVertical
DecimationHorizontal,
DecimationVertical
etc.
related to the format of the transmitted image.
Additionally, MATRIX VISION offers numerous additional features like:
• mvMultiAreaMode
which can be used to define multiple AOIs (Areas of Interests) in one image.
See also
The use case Working with multiple AOIs (mv Multi Area Mode) (p. 126) shows how this feature
works.
to SFNC Property name (acc. to mvIMPACT
Acquire (p. 119))
sensorWidth
sensorHeight
sensorName
width
height
binningHorizontal, binningVertical
decimationHorizontal,
decimationVertical
Description
Effective width of the sensor in pix-
els.
Effective height of the sensor in pix-
els.
Name of the sensor.
Width of the image provided by the
device (in pixels).
Height of the image provided by the
device (in pixels).
Number of horizontal/vertical
photo-sensitive cells to combine
together.
Sub-sampling of the image. This
reduces the resolution (width) of
the image by the specified decima-
tion factor.
