1.19 Appendix A. Specific Camera / Sensor Data
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
LevelLow"
"ExposureMode = Timed"
"TriggerSelector =
AcquisitionActive"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
LevelHigh"
"ExposureMode = Timed"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
FallingEdge"
"ExposureMode = Timed"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
RisingEdge"
"ExposureMode = Timed"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
Device Feature And Property List (p. 215)
1.19.1.1.1.4 Device Feature And Property List
1.19.1.1.2 BVS CA-BN2-0032ZG (3.2 Mpix [2064 x 1544])
1.19.1.1.2.1 Introduction The sensor uses a global shutter, i.e. light exposure takes place on all pixels in paral-
lel, although subsequent readout is sequential.
MATRIX VISION GmbH
OnLowLevel
OnHighLevel
OnFallingEdge
OnRisingEdge
OnAnyEdge
Start an exposure of a frame as
long as the trigger input is below
the trigger threshold. (No Frame
Trigger!)
Start an exposure of a frame as
long as the trigger input is above
the trigger threshold. (No Frame
Trigger!)
Each falling edge of trigger signal
acquires one image.
Each rising edge of trigger signal
acquires one image.
Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
