Balluff MATRIX VISION mvBlueNAOS Technical Manual page 78

70
AcquisitionFrameRate
TriggerSelector
TriggerOverlap[TriggerSelector]
ExposureMode
ExposureTime
ExposureAuto
etc.
acquisitionFrameRate
triggerSelector
triggerOverlap
exposureMode
exposureTime
exposureAuto
Controls the acquisition rate (in
Hertz) at which the frames are cap-
tured.
Some cameras support a special
internal trigger mode that allows
more exact frame rates. This fea-
ture keeps the frame rate constant
to an accuracy of +/-0.005 fps at
200 fps. This is achieved using
frames with a length difference of
up to 1 us. Please check in the
sensor summary (p. 54) if this fea-
ture exists for the requested sen-
sor.
Selects the type of trigger to con-
figure.
A possible option
TimestampReset.
case about mvTimestampReset
is available (p. 194).
Specifies the type trigger overlap
permitted with the previous frame.
TriggerOverlap is only intended for
external trigger (which is usually
non-overlapped: i.e. exposure and
readout are sequentially).
leads to minimal latency / jitter
between trigger and exposure.
However, the camera accepts a
new trigger (the exposure time
earlier) before the end of the trans-
mission of the current image.
Maximum frame rate in
triggered mode = frame
rate of continuous mode
This however leads to higher la-
tency / jitter between trigger and
exposure.
A trigger will be not latched if it oc-
curs before this moment (trigger is
accurate in time).
See also
Principles of overlapped
and pipelined
(p. 120).
Sets the operation mode of the ex-
posure (or shutter).
Sets the exposure time (in mi-
croseconds) when ExposureMode
is Timed and ExposureAuto is Off.
Sets the automatic exposure mode
when ExposureMode is Timed.
MATRIX VISION GmbH
is mv
The use
This
trigger
