With this setting, there is still an acceptable time delay of approx. 100 to 130 us possible.
1.18.3.6.2 Creating the use case using wxPropView
First of all, we have to set the timer in "Setting -
with following settings:
Afterwards, we have to set the logical gates in "Setting -
Control" with following settings:
Finally, we have to set the trigger in "Setting -
settings:
Figure 1: Schematic illustration of the settings
Property name wxPropView
Timer Selector
Timer Trigger Source
Timer Duration
Property name wxPropView
mv Logic Gate AND Selector
mv Logic Gate AND Source 1
mv Logic Gate AND Source 2
mv Logic Gate OR Selector
mv Logic Gate OR Source 1
Base -
Property name wxPropView
Trigger Selector
Trigger Mode
Trigger Source
Trigger Activation
Exposure Mode
Base - Camera - GenICam -
Setting
Timer1
Timer1End
100.000
Base - Camera -
Setting
mvLogicGateAND1
Line4
Time1Active
mvLogicGateOR1
mvLogicGateAND1Output
Camera - GenICam -
Setting
FrameStart
On
mvLogicGateAND1Output
RisingEdge
Timed
Counter And Timer Control"
GenICam - mv Logic Gate
Acquisition Control" with following
