Balluff MATRIX VISION mvBlueNAOS Technical Manual page 256

248
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
RisingEdge"
"ExposureMode = Timed"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
Device Feature And Property List (p. 248)
1.19.2.1.2.4 Device Feature And Property List
1.19.2.1.3 BVS CA-BN2-0051ZC (5.1 Mpix [2464 x 2056])
1.19.2.1.3.1 Introduction The sensor uses a global shutter, i.e. light exposure takes place on all pixels in paral-
lel, although subsequent readout is sequential.
1
Measured accord. to EMVA1288 with gray scale version of the camera
1.19.2.1.3.2 Spectral Sensitivity
OnRisingEdge
OnAnyEdge
Feature
Manufacturer
Sensor name
Max. frames per second
Device Structure
1/
SNR [dB]
max
DNR (normal / HDR) [dB]
Image size
Number of effective pixels
Unit cell size
ADC resolution / output
Each rising edge of trigger signal
acquires one image.
Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
Description
Sony
IMX250
140
CMOS image sensor
40,2
1/
71,2 / -
2/3
2464 (H) x 2056 (V)
3.45µm (H) x 3.45µm (V)
→
12 bit 8/10/(12)
MATRIX VISION GmbH
