1.7 Introduction

1.7.2.2 mvBlueNAOS4

The mvBlueNAOS4 nomenclature scheme is as follows:
Sensor
5.1 Mpix, 2464 x 2064, 1/1.8'', IMX537, CMOS
8.1 Mpix, 2848 x 2848, 2/3'', IMX536, CMOS
12.4 Mpix, 4128 x 3008, 1/1.1'', IMX535, CMOS
16.2 Mpix, 5328 x 3040, 1.1'', IMX532, CMOS
20.4 Mpix, 4512 x 4512, 1.1'', IMX531, CMOS
24.6 Mpix, 5328 x 4608, 1.2'', IMX530, CMOS
Series
Model name BVS CA-BN4-
Legend Product name
HW Variant (1)(2)(3)(4)(5)(6)
(1): Handling
1: Standard handling
(2): Lensholder
0: None
1: C-Mount, Type2, with high durability and factory-set backfocus, fixed square filter
2: C-Mount, Type1, with adjustable backfocus, round filter with screw ring, Ø23.2 mm
5: C-Mount, Type3, low cost, factory-set backfocus, D23.2mm Filter
A: C-Mount, Type2, with high durability and factory-set backfocus, fixed square filter, adjustable
center position
B: C-Mount Type2 + D23.2mm Filter with screwring
Y: S-Mount, 13 mm length for sensors with image circule
(3): Filter
0: None
1: IR-CUT (standard)
2: Glass
3: Daylight cut filter
6: Dualband filter DB850
8: Customized filter type
(4): Housing
0: None
1: Color blue (standard)
5: Mounting and thermal conduction plate for board level camera
(5): I/O
1: NAOS for Embedded (N4e) interface (standard)
H: OCuLink for PCIe
(6): Software Adjustments
0: None
CUP/STD 001
MATRIX VISION GmbH
Sensor Color HW Variant
xxxxx G/C - see legend below
Model name
BVS CA-BN4-0051BG/C
BVS CA-BN4-0081ZG/C
BVS CA-BN4-0124BG/C
BVS CA-BN4-0162ZG/C
BVS CA-BN4-0204ZG/C
BVS CA-BN4-0246ZG/C
CUP/STD
- see legend below
