1.18 Use Cases 145
Figure 9: Synchronize
After gamma correction, the image will look like this:
Figure 10: After gamma correction
Figure 11: Corresponding histogram after gamma correction
The third way to set Gamma, is gamma correction via ("Setting - Base - ImageProcessing - LUTControl").
Here, the changes will affect the 8 bit image data and the processing is running on the CPU of the host system:
