Balluff MATRIX VISION mvBlueNAOS Technical Manual page 150

142
Note
mvGammaEnable can only be set if no LUT in LUTControl is active
Note
To avoid artifacts while changing the Gamma value, stop Acquisition before changing values and after-
wards, start Acquisition
The second way is setting Gamma via LUTControl using wxPropView (p. 65), here, the following steps have to be
done:
1. Click on "Setting -
2. Afterwards, click on "Wizard" to start the LUT Control wizard tool.
The wizard will load the data from the camera.
Figure 5: Gamma using AnalogControl
Base - Camera - GenICam - LUT Control - LUT Selector".
MATRIX VISION GmbH
