"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
Device Feature And Property List (p. 228)
1.19.1.1.6.4 Device Feature And Property List

1.19.1.2 mvBlueNAOS4

• BVS CA-BN4-0051BG (5.1 Mpix [2464 x 2064]) (p. 228)
• BVS CA-BN4-0081ZG (8.1 Mpix [2848 x 2848]) (p. 230)
• BVS CA-BN4-0124BG (12.4 Mpix [4128 x 3008]) (p. 233)
• BVS CA-BN4-0162ZG (16.2 Mpix [5328 x 3040]) (p. 235)
• BVS CA-BN4-0204ZG (20.4 Mpix [4512 x 4512]) (p. 238)
• BVS CA-BN4-0246ZG (24.6 Mpix [5328 x 4608]) (p. 240)
1.19.1.2.1 BVS CA-BN4-0051BG (5.1 Mpix [2464 x 2064])
1.19.1.2.1.1 Introduction The sensor uses a global shutter, i.e. light exposure takes place on all pixels in paral-
lel, although subsequent readout is sequential.
1
Measured accord. to EMVA1288 with gray scale version of the camera
OnAnyEdge
Feature
Manufacturer
Sensor name
Max. frames per second
Device Structure
1/
SNR [dB]
max
DNR (normal / HDR) [dB]
Image size
Number of effective pixels
Unit cell size
ADC resolution / output
Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
Description
Sony
IMX537
234.0
CMOS image sensor
39,9
1/
69,9 / -
1/1.8
2464 (H) x 2064 (V)
2.74µm (H) x 2.74µm (V)
→
12 bit 8/10/(12)
MATRIX VISION GmbH
