Balluff MATRIX VISION mvBlueNAOS Technical Manual page 274

266
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
<desired Line>"
"TriggerActivation =
AnyEdge"
"ExposureMode = Timed"
Device Feature And Property List (p. 266)
1.19.2.2.3.4 Device Feature And Property List
1.19.2.2.4 BVS CA-BN4-0162ZC (16.2 Mpix [5328 x 3040])
1.19.2.2.4.1 Introduction The sensor uses a global shutter, i.e. light exposure takes place on all pixels in paral-
lel, although subsequent readout is sequential.
1
Measured accord. to EMVA1288 with gray scale version of the camera
1.19.2.2.4.2 Spectral Sensitivity
OnAnyEdge
Feature
Manufacturer
Sensor name
Max. frames per second
Device Structure
1/
SNR [dB]
max
DNR (normal / HDR) [dB]
Image size
Number of effective pixels
Unit cell size
ADC resolution / output
Start the exposure of a frame when
the trigger input level changes from
high to low or from low to high.
Description
Sony
IMX532
82.8
CMOS image sensor
39,8
1/
70,5 / -
1.1
5328 (H) x 3040 (V)
2.74µm (H) x 2.74µm (V)
→
12 bit 8/10/(12)
MATRIX VISION GmbH
