1.18.5.3 Working with the UserFile section (Flash memory)

The mvBlueNAOS offers a 64 KByte section in the Flash memory that can be used to upload a custom file to
(UserFile).
To read or write this file you can use the following GenICam File Access Control (p. 80) and its interfaces:
• IDevFileStream (read)
• ODevFileStream (write)
Note
The UserFile is lost each time a firmware update is applied to the device.
1.18.5.3.1 Using wxPropView
wxPropView (p. 65) offers a wizard for the File Access Control (p. 80) usage:
1. Click on "Setting -
Selector".
Now, the "Wizard" button becomes active.
Base - Camera - GenICam - File Access Control - File Selector - File Operator
