1.19 Appendix A. Specific Camera / Sensor Data
1.19.1.2.5.3 Timings For calculating the frame rates, please use the frame rate calculator of the online manual:
See also
https://www.matrix-vision.com/manuals/mvBlueNAOS/mvBlue_models_BVS
_CA-BN4-0204ZG_.html#mvBC_subsubsection_sensors_CMOS_models_BVS_CA-
BN4-0204ZG_Calc
The following trigger modes are available:
Setting (GenICam)
"TriggerSelector =
FrameStart"
"TriggerMode = Off"
"TriggerSelector =
FrameStart"
"TriggerMode = On"
"TriggerSource =
Software"
"ExposureMode = Timed"
To trigger one frame execute
the TriggerSoftware@i command
then.
MATRIX VISION GmbH
Figure 1: Spectral sensitivity BVS CA-BN4-0204ZG
Mode / Setting (obsolete "Device
Specific")
Continuous
OnDemand
Description
Free running, no external trigger
signal needed.
Image acquisition triggered by
command (software trigger).
