1.18.2.4.1 Binning
Possible binning modes are:
• Sum: The response from the combined pixels will be added, resulting in increased sensitivity.
• Average: The response from the combined pixels will be averaged, resulting in increased signal/noise ratio.
Binning can be used to lighten the image at the expense of the resolution. This is a neat solution for applications
with low light and low noise.
The following results were achieved with the mvBlueFOX3-2124G:
Exposure [in us] Binning
2500 -
Exposure [in us] Binning
2500 -
Exposure [in us] Binning
2500 2H 2V
Gain [in dB] Averager
0 -
Gain [in dB] Averager
30 -
Gain [in dB] Averager
30 -
