Icon Name
Standard floor
heating
Schedule
Memory
Sun-flower
High-temp
sterilization
Auto function
Rapid heat function
Solar
Shield
Group control
Slave wired
controller
Cycle
Anti-freeze
E-heater
Child lock
Defrost
Invalid operation
NOTE：
When wired controller is connected with different hydro boxes, some functions will be different.
GMV6 HR DC Inverter VRF Units Service Manual
It means the current mode is the standard floor heating mode
Display when schedule function is enabled
Memory status (when the unit is re-energized after power failure, the indoor unit will
It is displayed when the sun-flower function is valid
The icon will light up when the high-temp sterilization function is valid and will be
The corresponding interface will display this icon when automatic floor heating water
temp. setting or automatic hot water temp. setting function is valid
The corresponding interface will display this icon when rapid floor heating or rapid
It is displayed when the hydro box is connected to solar energy; Flicker when solar
It means the wired controller is in shielding status
It displays when a wired controller controls several hydro boxes at the same time
It means the wired controller is the slave wired controller
Running status of the back water pump
It displays under anti-freezing status
It displays when the auxiliary electrical heating is on
It means the wired controller is in child lock status
It displays if the ODU is in defrosting status
It displays when the operation is invalid
