5.2.3 Disassembly and assembly operation of magnet valve
Preparation
（1）Turn off the power supply of the unit system;
（2）Ensure that there is no refrigerant in the piping system of the unit;
（3）To remove the unit cover, please refer to section 5.2.1.1 Remove the Unit Cover;
（4）To remove the electric box cover of the unit, please refer to section 5.2.1.2 Remove the
Electric Box Cover; （ 5） To remove the mounting plate of electric component of the unit, please
refer to section 5.2.1.3 Remove the Mounting Plate of Electrical Component;
（6）To remove the side plate of the unit, please refer to section 5.2.1.4 Remove the Side
Plate.
Disassembly steps
（1）Use a screwdriver to remove the screw 1 used to fix the magnet valve coil;
（2）Remove magnet valve coil 2;
（3）Unsolder the connecting pipe of the magnet valve, and then remove the valve body 3;
Note: Wrap the surrounding magnet valve and important components with a damp cloth
during welding.
