6.8 Explosive View and Parts List of NRQR16L/A-T、NRQR30L/A-T
No. Name
1 Panel
Electric leakage circuit
2
breaker
3 Main Board
4
Main Board
5
Terminal Board
6
Terminal Board
7
Electric Box Assy
8
Chassis Sub-assy
9 Plate heat exchanger
10
Water flow swicth
11
Release valve
12
Strainer
13
Electronic Expansion Valve
GMV6 HR DC Inverter VRF Units Service Manual
Material code
012073060278P
4602800301
300002060336
300002060371
422000060011
42200006000401
100002062065
017000060136P
NRQR16L/A-T:010007060015
NRQR30L/A-T:010007060014
45028065
07108206
035021060012
07334503
396
Vulnerable part *
*
*
*
*
*
*
*
*
*
*
*
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
