Gree GMV-VQ680WM/C-X Service Manual page 13

Gree
Model -
Packing
dimensions mm
(W × D × H)
Net weight kg
Gross weight kg
Note:
① Rated cooling capacity test conditions: indoor 27℃ DB/19℃ WB, outdoor 35℃ DB; without
height drop between units.
② Rated heating capacity test conditions(Tdesingnh): indoor 20℃ DB, outdoor -10℃ DB/-11 ℃
WB; without height drop between units. Max heating capacity test conditions: indoor 20℃ DB,
outdoor 7℃ DB/6 ℃ WB; without height drop between units.
③ The total capacity of connected indoor units must be in the range of 50%~135% of the outdoor
unit capacity. The relevant parameters can be corrected by referring to the unit capacity
correction table.
④ The above parameters are tested based on the standard connection pipe length. In the actual
project, the parameters should be corrected referring to the capacity correction for the long
connection pipe of units.
⑤ Specifications may be changed due to product improvement. Please refer to nameplates of the
units.
2.2 Parameters of Mode Exchange Box
Model
Numbers of branches
Maximum numbers of
connectable IDUs
Maximum capacity of
connectable IDUs
Power supply
ODU
Piping connections
IDU
Outline dimension(W×D×H)
GMV-VQ2295WM/C- GMV-VQ2349WM/C-
X
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855
325+385+385+385
340+400+400+400
unit
Per branch unit
Total unit
Per branch kW
Total kW
Liquid mm
High
mm
pressure gas
Low
mm
pressure gas
Liquid mm
Gas mm
mm
GMV6 HR DC Inverter VRF Units Service Manual
GMV-VQ2405WM/C-
X
1400×830×1855+ 1400×830×1855+
1400×830×1855+ 1400×830×1855+
1400×830×1855+ 1400×830×1855+
1400×830×1855
385+385+385+385 385+385+385+385
400+400+400+400 400+400+400+400
NCHS1D NCHS2D
1
8
8
16
16
Φ9.52
Φ19.05 Φ19.05
Φ22.2
Φ6.35/9.52 Φ6.35/9.52
Φ12.7/15.9 Φ12.7/15.9
340×388×250 340×388×250
11
GMV-VQ2460WM/C-
X
1400×830×1855+
1400×830×1855+
1400×830×1855+
1400×830×1855 1400×830×1855
385+385+385+385
400+400+400+400
NCHS4D
2 4
8 8
16 32
16 16
28 45
220-240V ~ 50/60Hz
Φ9.52 Φ12.7
Φ22.2
Φ22.2 Φ28.6
Φ6.35/9.52
Φ12.7/15.9
460×388×250
X
NCHS8D
8
8
64
16
85
Φ15.9
Φ22.2
Φ28.6
Φ6.35/9.52
Φ12.7/15.9
784×388×250
