Gree
GMV6 HR DC Inverter VRF Units Service Manual
Specifications
Description
①NCHS1D, NCHS2D, NCHS4D models adopt one piece of
main board;
It is used for controlling the status of each load in the mode switch.
②NCHS8D adopts two pieces of same main boards.
Circuit diagram
Layout of electrical appliance box
Physical position
Models: NCHS2D
310
