Gree
Parameter
name
Comp3
Discharge
Temp
Comp4
Discharge
Temp
Comp5
Discharge
Temp
Comp6
Discharge
Temp
Comp3
Operation
Freq
Display integer
ODU Heating
with the actual
EXV1
value divided by
Display integer
ODU Heating
with the actual
EXV2
value divided by
Display integer
Subcooler
with the actual
EXV
value divided by
Defrosting
Temp
Subcooler
Liquid Temp
Separator
Outlet Temp
Oil Return
Temp
Condenser
Inlet Temp
Condenser
Outlet Temp
4.3.3.4.2 Parameter Setting
Parameters can be set under both ON and OFF status.
Press "MENU/OK" button on homepage to enter menu and select "Set" to enter setting interface; in
setting interface, select "Project Setting" to enter project setting interface, as shown below.
Parameter setting includes "User parameters Set" and "Project parameters set", "Project
parameters set" is used by the engineer in project setting, password shall be verified (password:
000000). "User parameters Set" is for the user and shall be set under the guidance of professionals,
otherwise, the system might not function normally, please refer to Table below "User parameter setting
Parameter
range
-30~150°C
-30~150°C
-30~150°C
-30~150°C
0~120 Hz
10
10
10
-30~139°C
-30~139°C
-30~139°C
-30~139°C
-30~139°C
-30~139°C
GMV6 HR DC Inverter VRF Units Service Manual
Instruction
85
