Temperature
(°C)
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
Resistance
Voltage (V)
(kΩ)
20.54 1.393
19.63 1.429
18.75 1.467
17.93 1.503
17.14 1.54
16.39 1.577
15.68 1.613
15 1.65
14.36 1.686
13.74 1.722
13.16 1.758
12.6 1.793
12.07 1.829
11.57 1.863
11.09 1.897
10.63 1.931
10.2 1.964
9.779 1.998
9.382 2.03
9.003 2.062
8.642 2.094
5.997 2.125
7.653 2.185
7.352 2.215
7.065 2.243
6.791 2.272
6.529 2.299
6.278 2.326
6.038 2.353
5.809 2.379
5.589 2.404
5.379 2.429
5.179 2.453
4.986 2.477
4.802 2.5
4.625 2.522
4.456 2.544
4.294 2.566
4.139 2.586
3.99 2.607
3.848 2.626
3.711 2.646
3.579 2.664
3.454 2.682
3.333 2.7
GMV6 HR DC Inverter VRF Units Service Manual
Temperature
(°C)
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
402
Resistance
Voltage (V)
(kΩ)
0.779 3.137
0.758 3.141
0.737 3.145
0.717 3.15
0.697 3.153
0.678 3.157
0.66 3.161
0.642 3.165
0.625 3.168
0.608 3.171
0.592 3.175
0.577 3.178
0.561 3.181
0.547 3.184
0.532 3.187
0.519 3.19
0.505 3.192
0.492 3.195
0.48 3.198
0.467 3.2
0.456 3.203
0.444 3.205
0.433 3.207
0.422 3.21
0.412 3.212
0.401 3.214
0.391 3.216
0.382 3.218
0.372 3.22
0.363 3.222
0.355 3.224
0.346 3.226
0.338 3.227
0.33 3.229
0.322 3.231
0.314 3.232
0.307 3.234
0.299 3.235
0.292 3.237
0.286 3.238
0.279 3.24
0.273 3.241
0.266 3.242
0.261 3.244
0.254 3.245
