Gree
4.2.2 Temperature Sensors
Specifications
The type of temperature sensors of mode exchange box are
20K.
Circuit diagram
The sensors are used to measure the temperature of the unit at different positions.
Layout of electrical appliance box
Models：NCHS1D
294
GMV6 HR DC Inverter VRF Units Service Manual
Description
Physical position
①Air outlet temperature sensor of subcooler
②Air inlet temperature sensor of subcooler
