After selecting the corresponding basic module, press the SW3 confirm button. The module displays
as follows. The current factory default status is 00. Value 00 represents 0 Pa outdoor static pressure, 01
represents 30 Pa, 02 represents 50 Pa, 03 represents 80 Pa, and 04 represents 110 Pa.
LED1
Function code Display status
1G
Press the SW1 up button and the SW2 down button to select the corresponding static pressure
mode for the outdoor unit.
LED1
Function code Display status
1G
1G
1G
1G
1G
After selecting the corresponding static pressure mode for the outdoor unit, press the SW3 confirm
button. The master module displays as follows:
LED1
Function code Display status
1G
1G
1G
1G
1G
Each basic module memorizes this setting and does not clear it even upon power failure and
power-on again. The default value is 00.
Step 6: Switch the commissioning software to the commissioning control interface.
Click "Debug" to switch to the engineering commissioning interface. The unit will automatically
operate the commissioning modules listed in this interface from top to bottom and from left to right. Note:
The commissioning function only applies to the single-system network.
Current process
On 00
On 01
On 02
On 03
On 04
Mode
On ADD
Mode
On ADD
On ADD
On ADD
On ADD
On ADD
Mode
On ADD
On ADD
On ADD
On ADD
On ADD
GMV6 HR DC Inverter VRF Units Service Manual
