External wiring connections
ACQUITY UPLC I-Class instrument external wiring connections
The rear panel connections for ACQUITY UPLC I-Class system modules are
shown below.
Drain tube outlet
Solvent tray
Detector
Column heater
External power and
communications
cable (CH-A and
CH-30A only)
Ethernet switch
Sample manager
Ethernet cables
Binary solvent
manager
B-4
External Connections
TP03423
Power cords
Sample organizer
Ethernet
cable to PC
