You can access these additional functions by right-clicking anywhere in the
sample manager control panel.
Additional functions in the sample manager control panel:
Control panel function
Prime
Wash needle
Reset SM
Help

TUV detector control panel

The TUV detector's control panel displays absorbance units and wavelength
values, which you can edit when the system is idle by clicking the underlined
value. Nevertheless, you cannot edit detector parameters when the system is
running samples.
Control panels for other detectors function similarly. See the ACQUITY UPLC
Photodiode Array Detector Getting Started Guide.
Control panel:
Status
Absorbance
units
Value of
wavelength A
3-10 Preparing the System
Description
Displays the Prime dialog box.
See "Priming the SM-FTN" in the Sample
Manager - Flow Through Needle Operator's
Overview and Maintenance
Displays the Wash Needle dialog box.
See "Washing the SM-FTN needle" in the
Sample Manager - Flow Through Needle
Operator's Overview and Maintenance
Information.
Resets the sample manager following an
error condition.
Displays the ACQUITY UPLC Console
online Help.
Information.
Lamp On/Off LED
Turn detector
lamp On/Off
