1. Connect the female end of the power cord to the receptacle on the rear
panel of each module.
2. Connect the male end of the power cord to a suitable wall outlet.
Alternative:
female end of the FlexCart's electrical cables (included in the startup
kit) to the receptacle on the rear panel of each system module. Connect
the hooded, male end of the FlexCart's electrical cables to the power
strips on the back of the cart. Finally, connect each power strip's cable to
a wall outlet operating on its own circuit.
FlexCart power connections:
To circuit A
FlexCart
power strips
To circuit B
B-12 External Connections
If your system includes the optional FlexCart, connect the
AC line
AC line
Network switch
(if needed)
Detector
Sample manager
Binary solvent
manager
Sample organizer
LCD/monitor
Computer
workstation
Column manager
(optional)
