INFUSION STAND

Using an Infusion Stand or EKOS CU 4�0 Cart
During use or storage, the Control Unit can be attached to the EKOS CU 4�0 Cart or an infusion stand that meets at least the minimum
specifications� Alternatively, the Control Unit can be placed on a flat table or cart�
Note: For more information on the EKOS Cart see the EKOS CU 4�0 Cart Instructions for Use�
Note: EKOS CU 4�0 Cart may not be available in all geographic regions�
Warning: The Control Unit should be placed on a flat table or attached to the EKOS CU 4�0 Cart or an infusion stand during use� If attached
to an infusion stand adhere to following guidelines:
• Always use an infusion stand that meets the specifications in these Instructions for Use�
• Follow the mounting instructions described in these Instructions for Use to ensure the Control Unit is securely attached to infusion
stand�
• Attach the Control Unit and infusion pumps to a position on the infusion stand such that the combined weight of the infusion pumps
and Control Unit is as low as practical�
• When transporting the infusion stand, hold the pole in the middle or use the handle if available to ensure the best control�
• Always evaluate infusion stand stability for use environment after configuring for treatment�
Failure to follow these guidelines could result in the infusion stand tipping or equipment falling, resulting in bodily injury�

Selecting the Appropriate Infusion Stand

Use this guideline when selecting an infusion stand for mounting the Control Unit�
Table 21.
Component
Pole diameter:
Pole Height:
Base:
Minimum Safe Working Load Capacity:
Material:
Construction:
Handle (optional):
/CMYK
Specification
Minimum – 0�75 in (1�9 cm)
Maximum – 1�25 in (3�2 cm)
Maximum – 100 in (254�0 cm)
Minimum Number of Legs/Casters – 6
Minimum Diameter – 25 in (63�5 cm)
100 lb (45�4 kg)
Steel
Welded
Fixed-position handle located at the ideal push-point height
