Table 11.
Item
The battery charge level (shown in %) is displayed in the upper right corner of the display, next to the AC power / battery status indicator
(see Figure 12)�
Figure 12. Screen with AC Power/Battery Status
/CMYK
Connected to AC power and battery is charging�
Connected to AC power and battery is fully charged�
If the battery is defective the battery icon is red with an X�
25
Description
AC Power/Battery Status
