Symbol Description
Disables channel when pressed�
Disable button may be green, yellow or red�
Displays the current runtime for the channel� Runtime is the length of time a device has delivered
ultrasound therapy on a channel� Time is displayed in Hours:Minutes:Seconds�
Ultrasound therapy is ON�
When audio alert tone is on, the alert icon displays�
When the audio alert tone is silenced, the alert icon is crossed-out indicating audio is silenced�
Decrease screen brightness�
Increase screen brightness�
Decrease audible tone�
Increase audible tone�
Connector Interface Cable:
Used to connect the Infusion Catheter and Ultrasonic Core to the Control Unit�
Infusion Catheter:
The device Infusion Catheter connects to the Connector Interface Cable�
Ultrasonic Core:
The device Ultrasonic Core connects to the Connector Interface Cable�
Canadian Standards Association
Certification for the United States
US
Equipotential Terminal
The terminal marked with this symbol is the equipotential terminal� It can be connected to a locally
available external equipotential line to prevent danger caused by the difference in the potentials between
this device and the other devices�
