Message Error
Description Code
Check the E306 Connector Interface
Connector Cable is disconnected
Interface Cable from the Control Unit
connection to the while ultrasound is
Control Unit� running�
Replace the E307 Defective Connector
Connector E315 Interface Cable�
Interface Cable� E321
Check the device E311 Poor connection of the
connectors� Infusion Catheter and
Ultrasonic Core�
Infusion Catheter
and Ultrasonic Core
Connectors are wet at
the connection site�
Incompatibility E331 The Connector Interface
of CIC Cable is not compatible
with the Infusion
Catheter, Ultrasonic
Core, or both�
In rare circumstances
error code E331 may
also be presented due
to a software anomaly�
The same error n/a Control Unit has
has occurred detected the same error
three times� three times in a row�
/CMYK
Possible Cause
1� Ensure the Connector Interface Cable is securely connected to the Control Unit�
2� If the error persists, disconnect and reconnect the CIC�
3� If the error persists, press the Power button to turn off the Control Unit�
4� Let the Control Unit sit for 30 seconds�
5� Use the Power button to turn on the Control Unit�
6� If the error persists, try using another Control Unit 4�0-compatible CIC�
7� If the error persists, please call the phone number listed in the For
Support section�
8� If you were able to resume therapy after switching CICs, please call the phone
number listed in the For Support section to troubleshoot the issue with the
original CIC
1� Ensure the Connector Interface Cable is securely connected to the Control Unit�
2� If the error persists, disconnect and reconnect the CIC�
3� If the error persists, try using another Control Unit 4�0-compatible CIC�
4� If the error persists, press the Power button to turn off the Control Unit�
5� Let the Control Unit sit for 30 seconds�
6� Use the Power button to turn on the Control Unit�
7� If the error persists, please call the phone number listed in the For
Support section�
8� If you were able to resume therapy after switching CICs, please call the phone
number listed in the For Support section to troubleshoot the issue with the
original CIC�
1� Disconnect the Infusion Catheter and Ultrasonic Core from the Connector
Interface Cable�
2� Inspect for fluid or damage to the pins�
3� Dry the Infusion Catheter and Ultrasonic Core connectors, if necessary�
4� Reconnect the Infusion Catheter and Ultrasonic Core and ensure the
connections are secure�
5� Press Start to resume ultrasound�
6� If the error persists, disconnect and reconnect CIC�
7� If the error persists, try using another Control Unit 4�0-compatible CIC�
8� If the error persists, please call the phone number listed in the For
Support section�
9� If you were able to resume therapy after switching CICs, please call the phone
number listed in the For Support section to troubleshoot the issue with the
original CIC�
1� Disconnect the Infusion Catheter and Ultrasonic Core from the Connector
Interface Cable�
2� Inspect for fluid or damage to the pins�
3� Dry the Infusion Catheter and Ultrasonic Core connectors, if necessary�
4� Reconnect the Infusion Catheter and Ultrasonic Core and ensure the
connections are secure�
5� If the error persists, disconnect and reconnect the CIC�
6� If the error persists, try using a Connector Interface Cable that is compatible
with the Infusion Catheter and Ultrasonic Core�
7� If the error persists, please call the phone number listed in the For Support
section�
Please call the phone number listed in the For Support section
Troubleshooting Step
47
