Figure 36. Screen Layout-Power Graph
Table 16.
Item
A
A
A
A
80 %
Power
73 %
Power
/CMYK
Channel A
Power Information
Channel label (A and B):
• Green icon indicates ultrasound is ready to start or currently running�
• Yellow icon indicates further steps are required to start the ultrasound�
• Red icon indicates there is an error detected and ultrasound is not running�
• Black icon indicates the channel is not active�
Percentage of the maximum average power currently being delivered�
Note: 0 % indicates ultrasound is NOT currently being delivered�
Channel A power is plotted with a solid line�
Channel B power is plotted with a dashed line�
39
Channel B
Power Information
Description
