TROUBLESHOOTING

Power Graph

The Control Unit monitors and presents a historical graph of the ultrasound power delivered to the EKOS Device(s)� The percentage of the
maximum average power actually delivered by each of the two channels, is plotted over time on the power graph�
Warning: The Control Unit user interface presents a historical graph of the ultrasound power delivered� The power data should not be
used for diagnostic purposes� Diagnosis of drug/ultrasound therapy should always be made using other clinical diagnostic tools (e�g�,
fluoroscopy)� An incorrect diagnosis could result in prolonged therapy or inadequate therapy�

Reading the Power Graph

1� To view the power graph, press the Graph tab
Figure 35. Power Graph Menu Tab
2� The power graph displays the power information for each channel with a 6 hour, 12 hour, or 24 hour time scale� As runtime increases
the power graph will automatically update to the most appropriate time scale�
3� The percentage of the maximum average power is plotted in the graph�
4� The graph and power data will be displayed as zero if the therapy is stopped for any reason (i�e� stop button pressed, cables
disconnected, channel made inactive)� See the figures below for examples of a power graphs�
5� The power graph shows the total runtime for the channel, not for the device� If possible, always reconnect devices to the same
channels they started on� If two devices are switched from one channel to another, the runtime will reflect the total amount of time
that specific channel delivered therapy regardless of the device currently connected�
Screen Layout – Power Graph
Power Graph information is provided for each channel independently showing percent of the maximum average power for the duration of
the therapy� Additionally, the current state of the device is shown by the colored channel icon (see Figure 36 and the Table 16)�
Black (K) ∆E ≤5.0
Serial number for Control Unit
Version number for Software
Indication of Channel A or B
Serial number for the Connector Interface Cable
Serial number for the Ultrasonic Core
Serial number for the Infusion Catheter
Ultrasound treatment zone (cm)
Infusion Catheter treatment zone (cm)
Ultrasonic Core with 5 transducer groups present and active� Displayed for each catheter�
Note: Number is dimmed if the transducer group is inactive and number is not displayed if the transducer
group is not present�
on the display (see Figure 35)�
