Completing Ultrasound

Ultrasound therapy can be provided for an individual device on a single channel or two devices using both channels� Because each channel
operates independently, ultrasound can be stopped and completed for one or both channels at any time�
1� Press the Stop button on the Control Unit for the appropriate channel�
Stop
2� If desired, press the Disable "X" icon
(see Figure 30)�
Figure 30. Ready Screen Showing Disable Button
Press the Disable icon on the confirmation screen and the channel becomes inactive (see Figure 31 and Figure 32)�
Figure 31. Disable Confirmation Screen
Figure 32. Disabled/Ready to Activate Screen
3� Disconnect the Infusion Catheter and Ultrasonic Core from the Connector Interface Cable�
4� Press and hold the Power button
shuts down (see Figure 33)�
Note: If the Power button
saving mode and data may be lost� In this mode the battery charging indicator on the front panel will not illuminate� Connecting the
Control Unit to an AC power source and turning the Control Unit on will bring it out of the low power/battery saving mode�
Black (K) ∆E ≤5.0
for the appropriate channel to inactivate or disable the channel no longer in use
for 3 seconds to turn OFF the Control Unit� The shutdown screen displays as the Control Unit
is pressed and held for 10 seconds or more it will force the Control Unit into a low power/battery
