Field Positioning

The printable area of the label forms a grid, where the X-axis runs across
the media and the Y-axis runs along the media path. Dots are used as the
unit for establishing position of the upper left corner of each field in rela-
tion to a specified reference point.
The printer is available with two different printhead densities (the 203.2
dpi printer and the 300 dpi printer have different firmware versions):
Density
X-axis
Y-axis
Number of active dots:
Max. print width:
Dot line to tear bar:
Dot line to cutter blade:
Text and bar code fields can be rotated around their insertion points,
whereas lines, boxes and graphics cannot be rotated. However, the entire
print image can be rotated 180°. The illustration below shows coordinates
for the default print direction (ZT).
ESim v5.12 for EasyCoder PD4—Programmer's Reference Manual
Medium
203.2 dpi (8 dots/mm)
203.2 dpi (8 dots/mm)
832
104 mm
136 dots
256 dots
Chapter 1—General Information
High
300 dpi (11.81 dots/mm)
304.8 dpi (12 dots/mm)
1208
102.2 mm
204 dots
384 dots
