Summary of Contents for Intermec SG20T1D
- Page 1 SG 20T Tethered Scanner User’s Guide...
- Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2011-2014 by Intermec by Honeywell.
-
Page 3: Document Change Record
Document Change Record This page records changes to this document. The document was originally released as version 01. Version Number Date Description of Change 5/2014 • Added Honeywell patent info and name. • Modified firmware download procedure - no longer need the firmware download bar code. - Page 4 SG20T Tethered Scanner User’s Guide...
-
Page 5: Table Of Contents
Intermec Ready-to-Work Indicator ........ - Page 6 Contents SG20T Interfaces ............17 USB Interface.
- Page 7 SG20T1D ........
-
Page 8: Before You Begin
Safety Information Your safety is extremely important. Read and follow all warnings and cautions in this document before handling and operating Intermec equipment. You can be seriously injured, and equipment and data can be damaged if you do not follow the safety warnings and cautions. -
Page 9: Global Services And Support
Web Support Visit the Intermec web site at www.intermec.com to download our current manuals (in PDF). To order printed versions of the Intermec manuals, contact your local Intermec representative or distributor. Visit the Intermec technical knowledge base (Knowledge Central) at www.intermec.com and click Support >... -
Page 10: Related Documents
(as PDF files) that you can download for free. To download documents 1 Visit the Intermec web site at www.intermec.com. 2 Click the Products tab. 3 Using the Products menu, navigate to your product page. For example, to find the CN3 computer product page, click Computers >... -
Page 11: Introducing The Sg20T Tethered Scanner
Introducing the SG20T Tethered Scanner This chapter provides an overview of the SG20T Tethered Scanner. This chapter covers these topics: • What is the SG20T Tethered Scanner • Supported Interfaces • Powering the SG20T • Connecting the Interface Cable • Removing the Interface Cable •... -
Page 12: What Is The Sg20T Tethered Scanner
Chapter 1 — Introducing the SG20T Tethered Scanner What is the SG20T Tethered Scanner The SG20T Tethered Scanner is a general purpose handheld scanner. The SG20T is lightweight, ergonomically designed, and it interfaces easily with Intermec computers and other host computers. Scanner window Status light Intermec Ready-to-Work indicator™... -
Page 13: Supported Interfaces
SG20T Scan Engine Option: The scan engine option of your SG20T can be found in the first part of the configuration number. In this illustration, the scan engine option is SG20T1D for 1D imager. Supported Interfaces The SG20T supports the following interfaces: •... -
Page 14: Connecting The Interface Cable
Chapter 1 — Introducing the SG20T Tethered Scanner Connecting the Interface Cable The cable you use depends on the interface and host device. However all cables are connected to the scanner in the same way. To connect the cable, insert it and press firmly until inserted all the way. -
Page 15: Removing The Interface Cable
Chapter 1 — Introducing the SG20T Tethered Scanner Removing the Interface Cable To remove the cable follow these steps: 1 Insert a pin or straightened paper clip into the release hole. 2 Push on the pin or paper clip while pulling out the cable. SG20T Tethered Scanner User’s Guide... -
Page 16: Accessories
Keyboard wedge cable (6 feet "Y" straight) CAB-SG20-KBWxxx RS232 Cable, DB9 (6 feet straight) CAB-SG20-SERxxx Universal Intermec power supply 5V 851-089-xxx Note: A power cord is also needed to plug in the power supply. The power cord needed depends on your country and is sold separately. -
Page 17: Desktop / Wall Mount
Chapter 1 — Introducing the SG20T Tethered Scanner Desktop / Wall Mount The desktop/wall mount holder can be used to store the SG20T when you are not using it. You can attach the holder with screws either to a desk or to a wall. SG20T Desktop / Wall Mount Holder: P/N Holder-SG20-xx Desktop Adjustable Stand The desktop adjustable stand can be used to adjust the scanning... -
Page 18: Flexible Stand
Chapter 1 — Introducing the SG20T Tethered Scanner Flexible Stand SG20 Flexible Stand: P/N Flexstand-SG20-xx SG20T Tethered Scanner User’s Guide... -
Page 19: Scanning With The Sg20T
Scanning with the SG20T This chapter explains how to scan bar codes and includes the following sections: • Understanding the Lights • Understanding the Beeps • Scanning Bar Codes... -
Page 20: Understanding The Lights
Chapter 2 — Scanning with the SG20T Understanding the Lights The SG20T uses the Intermec Ready-to-Work™ light and Status light to communicate information about your scanner. Intermec Ready-to-Work Indicator The Intermec-Ready-to-Work indicator™ (blue LED) indicates that the scanner is ready to scan bar codes. This light stays on all the time when the scanner is ready to work however your scanner will also flash status information using green and red lights. -
Page 21: Status Light
Chapter 2 — Scanning with the SG20T Status Light The status light on the SG20T flashes red or green depending on the status of the scanner. Default Status Light Description Light State What it Means Series of green Power-up flashes (USB At power-up the status light flashes to indicate the interface only) activated USB interface:... -
Page 22: Understanding The Beeps
Long-term exposure to the laser framing beam can damage your vision. The SG20T contains either a 1D imager (SG20T1D), a 2D imager (SG20T2D or SG20T2DHC) or high performance 2D imager (SG20THP or SG20THC) to scan bar code data. The type of scan engine you are using and the type of bar code you are decoding determines the way you scan the bar code. - Page 23 Chapter 2 — Scanning with the SG20T If you are using bar code labels that are encoded in a different symbology, you need to enable the symbology on your SG20T. Use EasySet version 5.6.5.1 or later to enable and disable symbologies for your scanner.
- Page 24 Chapter 2 — Scanning with the SG20T ABCD ABCD Scanning Bar Codes: The aiming and scanner beams that you see depend on which SG20T model you are using. To scan with a 2D imager 1 Point the scanner window at the bar code label and hold the SG20T steady a few inches from the label.
-
Page 25: Hands-Free Scanning
Autostand Triggering Mode Autostand mode is different depending on the scanner model. This section explains the difference between: • Autostand for all models except SG20T1D • Autostand for SG20T1D Autostand For All Models Except SG20T1D Autostand is a mix of Level and Presentation triggering modes. When in Level mode you simply pull the trigger to scan a bar code (hand held scanning). - Page 26 Chapter 2 — Scanning with the SG20T SG20T Tethered Scanner User’s Guide...
-
Page 27: Sg20T Interfaces
SG20T Interfaces This chapter explains the different interfaces available with the SG20T: • USB Interface • RS-232 Interface • Keyboard Wedge Y-Cable Interface... -
Page 28: Usb Interface
Chapter 3 — SG20T Interfaces USB Interface The SG20T can be connected to a USB host using one of the USB cables. The SG20T is USB 2.0 and operates at full speed. Power is provided either by the host or by the external power supply connected to the USB cable. -
Page 29: Setting Up The Usb Interface
Chapter 3 — SG20T Interfaces 3 If your host device is off, turn it on. The scanner beeps twice and the green LED flashes to indicate the USB interface (see “Status Light” on page 11). Note: If you are using a non-powered USB cable, you may get a message that the host does not provide enough power. - Page 30 Chapter 3 — SG20T Interfaces French Canadian Windows XP/2000 German Windows Spanish Windows Italian Windows Swedish Windows UK English Windows Japanese Windows Brazilian Portuguese Windows Czech Republic Windows Slovakian Windows SG20T Tethered Scanner User’s Guide...
-
Page 31: Usb Cable Mode
Chapter 3 — SG20T Interfaces Hungarian 101-Key USB Cable Mode By default the USB cable mode is set to keyboard HID. However you can also set up your scanner to use the following USB cable modes: • HID POS IBM POS Hand Held •... - Page 32 For a first time setup when using the virtual COM USB cable mode you will need to download and install the driver. You can download the driver from Knowledge Central on the Intermec web site. To download the USB virtual COM driver: 1 Go to http://intermec.custhelp.com.
-
Page 33: Rs-232 Interface
Chapter 3 — SG20T Interfaces RS-232 Interface The SG20T can be connected to a host using one of the RS-232 cables. Power is provided by the external power supply connected to the RS- 232 cable. See the “Required Accessories” on page 6 for a list of part numbers for the different cables. -
Page 34: Setting Up The Rs-232 Interface
Chapter 3 — SG20T Interfaces The default serial parameters for the SG20T are: Serial Parameter Default Setting Baud rate 57600 Data bits Parity None Stop bits Setting up the RS-232 Interface This section provides configuration bar codes for a basic setup. All bar codes marked with (*) indicate the default value. -
Page 35: Data Bits
Chapter 3 — SG20T Interfaces 460800 Data Bits 8 (*) Parity None (*) Even Stop Bits 1 (*) SG20T Tethered Scanner User’s Guide... -
Page 36: Keyboard Wedge Y-Cable Interface
Chapter 3 — SG20T Interfaces Keyboard Wedge Y-Cable Interface The SG20T can be connected to a host using a keyboard wedge Y- cable. Power is provided either by the host or by the external power supply connected to the cable. See the “Required Accessories”... -
Page 37: Configuring The Sg20T Scanner
Configuring the SG20T Scanner This chapter provides some basic configuration bar codes and information on how to configure the SG20T using the EasySet configuration application. This chapter includes: • Basic Setup with Configuration Bar Codes • Hands-Free Scanning • Optimizing Decoding •... -
Page 38: Basic Setup With Configuration Bar Codes
Chapter 4 — Configuring the SG20T Scanner Basic Setup with Configuration Bar Codes This chapter provides you with configuration bar codes for a basic setup. For more configuration options, use EasySet (see “Configuring Your System with EasySet” on page 31). Resetting Your Scanner To reset your scanner, read the reset factory defaults configuration bar code. -
Page 39: Hands-Free Scanning
Chapter 4 — Configuring the SG20T Scanner Hands-Free Scanning For hands-free scanning as explained in “Hands-Free Scanning” on page 15 activate Autostand triggering mode by scanning this configuration bar code: Autostand Triggering Mode Optimizing Decoding Use the following barcodes to optimize your scanner reading performance. -
Page 40: Configuring Predefined Imager Modes
Chapter 4 — Configuring the SG20T Scanner Configuring Predefined Imager Modes When using a 2D model (SG20THP or SG20THC), you can optimize the reading performance of the scanner by adjusting certain parameters. Since there are many parameters that can be adjusted, we recommend using the pre-defined imager settings to quickly set up your imager for optimized reading. -
Page 41: Configuring Your System With Easyset
Chapter 4 — Configuring the SG20T Scanner Configuring Your System with EasySet EasySet is an Intermec configuration application that provides you with two ways to configure your scanner. • Online setup—send configuration commands from EasySet directly to the product. •... -
Page 42: Offline Setup With Easyset
Chapter 4 — Configuring the SG20T Scanner Note: The scanner does not beep when you send configuration commands online from EasySet. Offline Setup with EasySet To configure your scanner offline by scanning bar codes 1 Start EasySet. The first time you start EasySet, the Select product dialog box appears. -
Page 43: Troubleshooting And Maintaining The Sg20T
Troubleshooting and Maintaining the SG20T Use this chapter to solve problems you may have while using the SG20T. This chapter contains these topics: • Troubleshooting the SG20T • Maintaining the SG20T... -
Page 44: Troubleshooting The Sg20T
Outside the U.S.A. and Canada, contact your local Intermec representative. For help, go to www.intermec.com > About Us > Contact Us. Before you call Intermec Product Support, make sure you have the following information: • SG20T firmware version SG20T decode version •... -
Page 45: Problems And Possible Solutions
Chapter 5 — Troubleshooting and Maintaining the SG20T Get decode version To get the firmware version and decode version in EasySet 1 Follow the procedure for an online setup with EasySet (see “Online Setup with EasySet” on page 31). 2 When the scanner is connected to EasySet, open the Configuration modes and utilities folder in EasySet. - Page 46 Chapter 5 — Troubleshooting and Maintaining the SG20T Problems and Possible Solutions (continued) Problem Possible Solution You pull the trigger, the Try these possible solutions: red scanning beam • Make sure that the SG20T is configured for the turns on, but you symbology you are scanning.
-
Page 47: Maintaining The Sg20T
COM port. To upgrade the SG20T firmware 1 Download the latest SG20T firmware update package from the Intermec web site at www.intermec.com. a Go to Support > Downloads. b From the Product Category drop-down list, choose Bar Code Scanners. - Page 48 Chapter 5 — Troubleshooting and Maintaining the SG20T e Click the link to download the firmware upgrade package and save firmware upgrade file (.bin) to your PC. 2 Connect your SG20T to a host PC with the appropriate cable. 3 Start the latest version of EasySet. 4 From the Tools menu, select Upgrade product firmware to start WinFlash.
- Page 49 Chapter 5 — Troubleshooting and Maintaining the SG20T 6 Select the cable and click Next. SG20T Tethered Scanner User’s Guide...
- Page 50 Chapter 5 — Troubleshooting and Maintaining the SG20T 7 Use Browse to browse to the location of the firmware upgrade file (.bin), select the file, and click Open. Click Next. SG20T Tethered Scanner User’s Guide...
- Page 51 Chapter 5 — Troubleshooting and Maintaining the SG20T 8 select the Com port and parameters (if necessary) and deselect the Display help check box. Click Next. 9 Click Start download. SG20T Tethered Scanner User’s Guide...
-
Page 52: Scanner Recovery
This is only possible with a download cable. Please contact your Intermec representative. Cleaning the SG20T Clean the scanner window as often as needed for the environment in which you are using the SG20T. -
Page 53: Specifications And Reading Distances
Specifications and Reading Distances This appendix contains the technical specifications and reading distances for each scanner model. -
Page 54: Specifications
Electrical Specifications x 5V, 1.7 A Electrical rating Typical Power Consumption—Continuous Scanning (5V power supply, ambient lighting, continuous scanning) SG20T1D RS-232 = 120 mA USB = 120 mA Keyboard wedge = 120 mA SG20T2D, SG20T2DHC RS-232 = 340 mA USB = 360 mA... - Page 55 Ambient light 0 to 100 000 lux Artificial light 25 000 lux Scanning Performance SG20T1D Scan angle: 38° Minimum X dimension: 4mils (0.1 mm) SG20T2D, SG20T2DHC Scan angles: 39° horizontal, 25.5° vertical Min. X dimension 1D: 4 mils (0.1 mm) Min.
- Page 56 QR Code GS1 Composite Standard 2 of 5 GS1 DataBar Expanded Sweden Post GS1 DataBar Limited Telepen GS1 DataBar Omni-Directional TLC 39 GS1 DataBar Stacked Bar Code Symbologies for 1D Model (SG20T1D) Codabar GS1 DataBar Limited SG20T Tethered Scanner User’s Guide...
-
Page 57: Reading Distances
Appendix A — Specifications and Reading Distances Bar Code Symbologies for 1D Model (SG20T1D) Code 11 GS1 DataBar Omni-Directional Code 39 Interleaved 2 of 5 Code 93/93i Matrix 2 of 5 Code 128 / GS1-128 EAN/UPC Plessey GS1 Composite Standard 2 of 5... -
Page 58: Sg20T1D
Appendix A — Specifications and Reading Distances SG20T1D 0" 2" 4" 6" 8" 10" 12" 14" 16" 18" 20" 8" 6" EAN/UPC 4" 2" 0" 2" 0.1 mm/4 mils 4" 0.15 mm/6 mils 6" 0.25 mm/10 mils 8" 1 mm/40 mils... -
Page 59: Sg20T2D, Sg20T2Dhc
Appendix A — Specifications and Reading Distances SG20T2D, SG20T2DHC 0" 4" 8" 12" 16" 20" 24" 28" 32" 36" 40" 12" PDF417 10 mils 8" Data Matrix 10 mils 4" 0" 4" 0.125mm/5 mils 8" EAN/UPC 0.5 mm / 20 mils 12"... -
Page 60: Sg20T Tethered Scanner User's Guide
Appendix A — Specifications and Reading Distances SG20THP, SG20THPHC 36" 40" 0" 4" 8" 12" 16" 20" 24" 28" 32" 12" PDF417 15 mils 8" PDF417 10 mils Data Matrix 10 mils 4" 0" 4" 0.125mm/5 mils 8" EAN/UPC 0.5 mm / 20 mils 12"... - Page 62 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2013-2014 Intermec by Honeywell All rights reserved. SG20T Tethered Scanner User’s Guide *DOC-SG20T-UG03* P/N DOC-SG20T-UG03...
