- Page 1 RIGOL User’s Guide MSO5000 Series Digital Oscilloscope Oct. 2018 RIGOL (SUZHOU) TECHNOLOGIES INC. GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
- Page 2 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 3: Guaranty And Declaration
Notices RIGOL products are covered by P.R.C. and foreign patents, issued and pending. RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company’s sole decision. Information in this publication replaces all previously released materials. -
Page 4: Safety Requirement
RIGOL Safety Requirement General Safety Summary Please review the following safety precautions carefully before putting the instrument into operation so as to avoid any personal injury or damage to the instrument and any product connected to it. To prevent potential hazards, please follow the instructions specified in this manual to use the instrument properly. - Page 5 Do Not Operate With Suspected Failures. If you suspect that any damage may occur to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel.
-
Page 6: Safety Notices And Symbols
RIGOL Safety Notices and Symbols Safety Notices in this Manual: WARNING Indicates a potentially hazardous situation or practice which, if not avoided, will result in serious injury or death. CAUTION Indicates a potentially hazardous situation or practice which, if not avoided, could result in damage to the product or loss of important data. -
Page 7: Measurement Category
RIGOL Measurement Category Measurement Category MSO5000 series digital oscilloscopes can make measurements in Measurement Category I. WARNING This oscilloscope can only be used for measurements within its specified measurement categories. Measurement Category Definitions Measurement category I is for measurements performed on circuits not directly connected to MAINS. -
Page 8: Working Environment
RIGOL Working Environment Temperature Operating: 0℃ to +50℃ Non-operating: -30℃ to +70℃ Humidity Operating: Below +30℃: ≤95%RH (without condensation) +30℃ to +40℃: ≤75%RH (without condensation) +40℃ to +50℃: ≤45%RH (without condensation) Non-operating: Below 65℃: ≤95% RH (without condensation) WARNING To avoid short circuit inside the instrument or electric shock, never operate the instrument in a humid environment. -
Page 9: Care And Cleaning
RIGOL pollution has no effect. For example, a clean room or air-conditioned office environment. Pollution Degree 2: Normally only nonconductive pollution occurs. Temporary conductivity caused by condensation is to be expected. For example, indoor environment. Pollution Degree 3: Conductive pollution or dry nonconductive pollution that becomes conductive due to condensation occurs. -
Page 10: Environmental Considerations
RIGOL Product End-of-Life Handling The equipment may contain substances that could be harmful to the environment or human health. To avoid the release of such substances into the environment and avoid harm to human health, we recommend you to recycle this product appropriately to ensure that most materials are reused or recycled properly. -
Page 11: Mso5000 Series Overview
MSO5000 Series Overview MSO5000 series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multi-touch screen, the MSO5000 series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications. -
Page 12: Document Overview
RIGOL Document Overview Main Topics of this Manual: Chapter 1 Quick Start Introduces the preparations before using the oscilloscope and provides a basic introduction of the instrument. Chapter 2 To Set the Vertical System Introduces the vertical system functions of the oscilloscope. - Page 13 RIGOL Chapter 14 Waveform Recording & Playing Introduces the waveform recording & playing function. Chapter 15 Search and Navigation Function Introduces the navigation function and how to quickly search the relevant events. Chapter 16 Display Control Introduces how to control the display of the oscilloscope.
- Page 14 RIGOL Format Conventions in this Manual: 1. Key The key on the front panel is denoted by the format of "Key Name (Bold) + Text Box" in the manual. For example, Utility denotes the "Utility" key. 2. Menu The menu items are denoted by the format of "Menu Word (Bold) + Character Shading".
- Page 15 RIGOL Manuals of this Product: Quick Guide, User’s Guide, Programming Guide, Data sheet, etc. For the latest version of this manual, download it from the official website of RIGOL (www.rigol.com). MSO5000 User's Guide XIII GlobalTestSupply www. .com nd Quality Products Online at:...
-
Page 16: Table Of Contents
Contents RIGOL Contents Guaranty and Declaration ................. I Safety Requirement ................. II General Safety Summary................II Safety Notices and Symbols ..............IV Measurement Category ................V Ventilation Requirement ................V Working Environment ................VI Care and Cleaning .................. VII Environmental Considerations ..............VII MSO5000 Series Overview .............. - Page 17 Contents RIGOL Pinch & Stretch ................1-22 Drag ..................... 1-23 Rectangle Drawing ................. 1-23 Parameter Setting Method ..............1-25 To Use the Kensington Security Lock ............1-26 To Use the Built-in Help System ............. 1-27 To View the Option Information and the Option Installation ...... 1-28 Chapter 2 To Set the Vertical System ..........
- Page 18 Contents RIGOL Trigger Mode ..................5-4 Trigger Coupling..................5-5 Trigger Holdoff ..................5-6 Noise Rejection ..................5-7 Trigger Type ..................5-7 Edge Trigger ................... 5-8 Pulse Trigger ................... 5-9 Slope Trigger ................. 5-11 Video Trigger................. 5-14 Pattern Trigger ................5-16 Duration Trigger ................
- Page 19 Contents RIGOL Low Pass ..................6-21 High Pass ..................6-22 Band Pass ..................6-23 Band Stop ..................6-24 AX+B .................... 6-25 Math Operation Label ..............6-26 Auto Measurement ................6-27 Quick Measurement after AUTO............6-27 Measurement Parameter ..............6-29 Measurement Settings ..............6-35 Remove the Measurement Result .............
- Page 20 Contents RIGOL To Enable/Disable the Digital Channel ............ 10-2 To Set the Threshold and Calibrate Probe ..........10-3 Auto Arrangement Setting ..............10-4 To Set the Waveform Display Size ............10-4 To Set the Label ................... 10-4 Group Setting ..................10-5 Waveform Color of the Digital Channel ...........
- Page 21 Contents RIGOL Chapter 15 Search and Navigation Function ........15-1 Search Function ................... 15-2 Navigation Function ................15-4 Chapter 16 Display Control ..............16-1 To Select the Display Type ..............16-2 To Set the Persistence Time ..............16-2 To Set the Waveform Intensity ............... 16-3 To Set the Screen Grid ................
- Page 22 Contents RIGOL Disk Management ................18-6 To Select a File Type ..............18-7 To Create a Folder ................. 18-7 To Delete a File or Folder .............. 18-11 To Copy and Paste a File or Folder ..........18-12 To Rename a File or Folder ............18-12 To Clear the Internal Memory Safely ..........
-
Page 23: Chapter 1 Quick Start
Chapter 1 Quick Start RIGOL Chapter 1 Quick Start This chapter introduces the precautions when using the oscilloscope for the first time, the front/rear panels of the oscilloscope, the user interface, touch screen controls, and how to use the built-in help system. -
Page 24: General Inspection
The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2． Inspect the instrument In case of any mechanical damage, missing parts, or failure in passing the electrical and mechanical tests, contact your RIGOL sales representative. -
Page 25: Appearance And Dimensions
Chapter 1 Quick Start RIGOL Appearance and Dimensions Figure 1-1 Front View Unit: mm Figure 1-2 Vertical View Unit: mm MSO5000 User's Guide GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... -
Page 26: To Prepare For Use
Chapter 1 Quick Start RIGOL To Prepare for Use To Adjust the Supporting Legs You can unfold the supporting legs to use them as stands to tilt the instrument upwards for easier operation and observation, as shown in Figure 1-3. You can also fold the supporting legs for easier storage or shipment when the instrument is not in use. -
Page 27: Turn-On Checkout
After the self-test, the welcome screen is displayed. To Connect the Probe RIGOL provides the passive probe and the logic probe for MSO5000 series. For MSO5000 Series Datasheet specific probe models, please refer to . - Page 28 Figure 1-6. 2. Connect the other terminal of the logic probe to the signal terminal under test. RIGOL's MSO5000 series supplies PLA2216 active logic probe option. To apply to different application scenarios, PLA2216 provides two connection methods to PLA2216 Active Logic Probe connect the signal under test.
- Page 29 Chapter 1 Quick Start RIGOL Function Inspection Press Default on the front panel, then a prompt message "Restore default?" is displayed. Press OK or tap OK to restore the instrument to its factory default settings. Connect the ground alligator clip of the probe to the "Ground Terminal" as shown in Figure 1-7 below.
-
Page 30: Function Inspection
Chapter 1 Quick Start RIGOL WARNING To avoid electric shock when using the probe, please make sure that the insulated wire of the probe is in good condition. Do not touch the metallic part of the probe when the probe is connected to high voltage source. -
Page 31: Probe Compensation
Chapter 1 Quick Start RIGOL Front Panel Overview 9 10 Figure 1-10 Front Panel Table 1-1 Front Panel Description Description Description Capacitive Touch Screen Default Setting Key Function Menu Operation Keys Trigger Control System Dual-channel Function/Arbitrary Waveform Generator Setting Horizontal Control System... -
Page 32: Front Panel Overview
Chapter 1 Quick Start RIGOL Rear Panel Overview Figure 1-11 Rear Panel 1. Handle Rotate the handle upright to carry the instrument easily. Rotate it downward if you do not need to carry it. 2. HDMI Through this interface, you can connect the instrument to an external display equipped with the HDMI interface (e.g. -
Page 33: Rear Panel Overview
Press Online upgrade or enable the touch screen to tap "Online upgrade", then a "System Update Information" window is displayed, requesting you whether to accept or cancel "RIGOL TERMS OF ONLINE UPGRADE SERVICE". Tap "Accept" to start online upgrade. Tap "Cancel"... - Page 34 Chapter 1 Quick Start RIGOL Front Panel Function Overview Vertical 1, 2, 3, 4: indicates the analog channel switch key. The four channels are marked by different colors which are also used to mark both the corresponding waveforms of the specified channel on the screen and the channel input connectors.
-
Page 35: Front Panel Function Overview
Chapter 1 Quick Start RIGOL Each analog channel is configured with an independent vertical offset adjustment knob. Turn it clockwise to increase the offset, and turn it counterclockwise to decrease the offset. During the modification, the waveform would move up and down. Meanwhile, the offset information in the corresponding status label would change accordingly. -
Page 36: Horizontal
Chapter 1 Quick Start RIGOL Horizontal SCALE: indicates the horizontal time base knob. You can rotate the knob to modify the horizontal time base. Turn it clockwise to decrease the time base, and turn it counterclockwise to increase the time base. During the modification, waveforms of all the channels will be displayed in expanded or compressed form, and the time base message (e.g. -
Page 37: Trigger
Chapter 1 Quick Start RIGOL analysis function, and etc. You can make a quick measurement for 41 waveform parameters. Acquire: Press this key to enter the acquisition setting menu. You can set the time base mode, the acquisition mode, memory depth, and etc. -
Page 38: Navigation Control Key
Chapter 1 Quick Start RIGOL Function/Arbitrary Waveform Generator Setting Press GI to enable or disable the output of the [GI] connector on the front panel; press GII to enable or disable the output of the [GII] connector on the front panel; and then enter the corresponding Function/Arbitrary Waveform Generator setting interface. -
Page 39: Function/Arbitrary Waveform Generator Setting
Chapter 1 Quick Start RIGOL Touch Lock Key Press this key to disable the touch screen function. Note: By default, the touch screen function of the oscilloscope is always enabled. If you disable the function, press the key again to enable it. -
Page 40: Touch Lock Key
Chapter 1 Quick Start RIGOL User Interface MSO5000 series has a 9-inch WSVGA (1024× 600) LCD, with 256 level gray-scale display. The user interface displays the acquired waveforms, the setting information, and the measurement results. 5 6 7 10 11 12... -
Page 41: User Interface
Chapter 1 Quick Start RIGOL 3. Horizontal Time Base Represents the time length per grid in the horizontal axis of the screen. Use Horizontal SCALE to modify this parameter. The adjustable range of the horizontal time base is different for different models. - Page 42 Chapter 1 Quick Start RIGOL 12. Trigger LEVEL/Threshold Level When CH1-CH4 is selected as the trigger source, you need to set a proper trigger level. When D0-D15 is selected as the trigger source, you need to set a proper ...
- Page 43 Chapter 1 Quick Start RIGOL channel is highlighted in red. The digital channels turned off are displayed in gray. 18. CH4 Status Label Displays the status of CH4. Displays the vertical scale of CH4. That is, the voltage value per grid of CH4 ...
- Page 44 Chapter 1 Quick Start RIGOL 24. Function Navigation Enable the touch screen and then tap this icon to enable the function navigation. Touch Screen Controls MSO5000 series provides a 9-inch super large capacitive touch screen, which supports multi-touch and gesture operation. It has strong waveform display capability and excellent user experience.
-
Page 45: Touch Screen Controls
Chapter 1 Quick Start RIGOL Pinching & stretching in the horizontal direction can adjust the horizontal time base of the waveform. Pinching & stretching in the vertical direction can adjust the vertical scale of the waveform. Figure 1-14 Pinch & Stretch Gesture... -
Page 46: Drag
Chapter 1 Quick Start RIGOL Select "Trigger zone A": Draw the region for Trigger zone A; Open Trigger zone A; Open the "Zone Trigger" menu. Select "Trigger zone B": Draw the area for Trigger zone B;... - Page 47 Chapter 1 Quick Start RIGOL Parameter Setting Method You can use the knob or enable the touch screen to set the parameters of MSO5000 series. The common parameter setting methods are as follows: Method 1: For the parameters with the sign...
-
Page 48: Parameter Setting Method
Chapter 1 Quick Start RIGOL Method 4: For the parameters without the above signs, press the desired menu softkey to switch between the parameter items. This method is applicable to the parameters with only two available options. The above method is commonly used for the parameter settings of the oscilloscope. -
Page 49: To Use The Kensington Security Lock
Chapter 1 Quick Start RIGOL To Use the Built-in Help System The help system of this oscilloscope provides instructions for all the function keys on the front panel and their corresponding menu keys. The steps for opening the built-in help system are as follows: Press Utility ... -
Page 50: To Use The Built-In Help System
Chapter 1 Quick Start RIGOL options to get the corresponding help information. Method 3: Enable the touch screen and tap the desired help option to get the corresponding help information. Help information for other keys and buttons: Power key : powers on/off the instrument. -
Page 51: To View The Option Information And The Option Installation
Then, you can install the option according to the following steps. 1) Obtain an option license (1) Log in to the RIGOL official website (www.rigol.com), click License Activation to enter the "Registered product license code" interface. (2) In the software license registration interface, input the correct key, serial number (press Utility ... - Page 52 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 53: Chapter 2 To Set The Vertical System
Chapter 2 To Set the Vertical System RIGOL Chapter 2 To Set the Vertical System MSO5000 series provides two (CH1-CH2, available to be upgraded to 4 channels when installed with the MSO5000-4CH option) or four analog input channels (CH1-CH4), and each channel is equipped with an independent vertical control system. -
Page 54: To Enable Or Disable The Analog Channel
Chapter 2 To Set the Vertical System RIGOL To Enable or Disable the Analog Channel Enable the analog channel: Connect a signal to the channel connector of CH1, and then press 1 in the vertical control area (Vertical) on the front panel to enable CH1. Then, the backlight of the channel is illuminated. -
Page 55: To Adjust The Vertical Scale
Chapter 2 To Set the Vertical System RIGOL To Adjust the Vertical Scale Vertical scale indicates the voltage value per grid in the vertical axis of the screen. It is often expressed in V/div. While you adjust the vertical scale, the display amplitude of the waveform would enlarge or reduce. -
Page 56: Vertical Expansion
Chapter 2 To Set the Vertical System RIGOL SCALE to set the vertical scale at 1-2-5 step, i.e. 1 mV/div, 2 mV/div, 5 mV/div, 10 mV/div…10 V/div. Vertical Expansion When changing the vertical scale of the analog channel by rotating the Vertical SCALE knob, you can select to expand or compress the waveform around the "Center"... -
Page 57: Channel Coupling
Chapter 2 To Set the Vertical System RIGOL right side of the Offset input field to decrease or increase the offset. You can also tap the Offset input field to input a specific value with the displayed numeric keypad. Value Input Field Decrease Increase Channel Coupling The undesired signals can be filtered out by setting the coupling mode. -
Page 58: Probe Ratio
Chapter 2 To Set the Vertical System RIGOL rotate the multifunction knob to select the desired bandwidth limit. Press down the knob to select it. By default, it is OFF. When the bandwidth limit is enabled, the character "B" will be displayed in the channel status label at the bottom of the screen, as shown in the figure below. -
Page 59: Input Impedance
Chapter 2 To Set the Vertical System RIGOL 10:1 20:1 50:1 100X 100:1 200X 200:1 500X 500:1 1000X 1000:1 2000X 2000:1 5000X 5000:1 10000X 10000:1 20000X 20000:1 50000X 50000:1 Input Impedance To reduce the circuit load between the oscilloscope and the circuit under test, this oscilloscope provides the default 1 MΩ... -
Page 60: Amplitude Unit
Chapter 2 To Set the Vertical System RIGOL (a) "Invert" Off (b) "Invert" On Figure 2-1 Waveform Invert Note: When the waveform invert is enabled, the trigger edge or the trigger polarity will change (e.g. Edge trigger, Pulse trigger, or Slope trigger). -
Page 61: Offset Cal
Chapter 2 To Set the Vertical System RIGOL Figure 2-2 Zero Offset Press 1 More Ch-Ch Skew, rotate the multifunction knob or use the numeric keypad to set the desired delay calibration time. The available range of the delay calibration time is from -100 ns to 100 ns. -
Page 62: Channel Label
Chapter 2 To Set the Vertical System RIGOL Channel Label The instrument uses the channel number to mark the corresponding channel by default. For ease of use, you can also set a label for each channel. For example, " ". - Page 63 Chapter 2 To Set the Vertical System RIGOL the touch screen to realize it. Rotate the multifunction knob : use the delete key to delete or modify the characters. To modify the characters, input the desired characters again. Enable the touch screen: use the touch gestures to directly move the cursor to ...
- Page 64 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 65: Chapter 3 To Set The Horizontal System
Chapter 3 To Set the Horizontal System RIGOL Chapter 3 To Set the Horizontal System Contents in this chapter: To Adjust the Horizontal Time Base To Adjust the Horizontal Position Delayed Sweep MSO5000 User's Guide GlobalTestSupply www. -
Page 66: To Adjust The Horizontal Time Base
Chapter 3 To Set the Horizontal System RIGOL To Adjust the Horizontal Time Base Horizontal time base, also called the horizontal scale, refers to the time of each grid in the horizontal direction of the screen. It is usually expressed in s/div. The adjustable range of the horizontal time base is related to the model type. -
Page 67: To Adjust The Horizontal Position
Chapter 3 To Set the Horizontal System RIGOL base, and counterclockwise to increase the horizontal time base. Note: When the delayed sweep is enabled, rotate the Horizontal SCALE knob to adjust the time base for the delayed sweep. The delayed sweep time base displayed in the center of the screen will be changed accordingly, as shown in the following figure. -
Page 68: Delayed Sweep
Chapter 3 To Set the Horizontal System RIGOL Note: When the delayed sweep is enabled, rotate the Horizontal POSITION knob to adjust the horizontal position of the delayed sweep (press down the knob to quickly reset it). The horizontal position of the delayed sweep at the upper-right corner of the screen changes accordingly. - Page 69 Chapter 3 To Set the Horizontal System RIGOL Waveform before enlargement: The waveform in the area that is not covered by subtransparent blue in the upper part of the screen is the waveform before enlargement. Its horizontal time base (also called main time base) is displayed at the upper-left corner of the screen.
- Page 70 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 71: Chapter 4 To Set The Sample System
Chapter 4 To Set the Sample System RIGOL Chapter 4 To Set the Sample System Contents in this chapter: Timebase Mode Acquisition Mode Sampling Mode Sample Rate LA Sample Rate Memory Depth LA Memory Depth ... -
Page 72: Timebase Mode
Chapter 4 To Set the Sample System RIGOL Timebase Mode MSO5000 series supports three available time base modes: YT mode, XY mode, and ROLL mode. By default, the time base mode is YT. Press Acquire Timebase Mode on the front panel, and then rotate the multifunction knob to select the desired time base mode. - Page 73 Chapter 4 To Set the Sample System RIGOL According to sin=A/B or C/D, is the phase deviation angle between the two channels. The definitions of A, B, C, and D are shown in the above figure. The phase deviation angle is obtained, that is: =arcsin(A/B) or arcsin(C/D)
-
Page 74: Roll Mode
Chapter 4 To Set the Sample System RIGOL Note: In XY mode, CH1 and CH2 are forced to be enabled; CH3 and CH4 are forced to be disabled. The maximum sample rate in XY mode is 2 GSa/s. Generally, a longer sample waveform can ensure better display effect of Lissajous figure. -
Page 75: Acquisition Mode
Chapter 4 To Set the Sample System RIGOL Acquisition Mode The acquisition mode is used to control how to generate waveform points from the sample points. MSO5000 supports the following three acquisition modes: Normal, Average, and Peak. By default, the acquisition mode is Normal. -
Page 76: Peak
Chapter 4 To Set the Sample System RIGOL Figure 4-2 Waveforms before Averaging Figure 4-3 Waveforms after 128 Times of Averaging Peak In this mode, the oscilloscope acquires the maximum and minimum values of the signal within the sample interval to get the envelope of the signal or the narrow pulse that might be lost. -
Page 77: High Resolution
Chapter 4 To Set the Sample System RIGOL least the same as the sample period. Sampling Mode This oscilloscope only supports the real-time sampling mode. In this mode, the oscilloscope produce the waveform display from samples collected during one trigger event. - Page 78 Chapter 4 To Set the Sample System RIGOL details are lost, and the sample waveform displayed is rather different from the actual waveform of the signal. 2. Waveform Aliasing: when the sample rate is twice lower than the actual signal frequency (Nyquist Frequency), the frequency of the waveform rebuilt from the sample data is smaller than the actual signal frequency.
-
Page 79: La Sample Rate
Chapter 4 To Set the Sample System RIGOL acquisition on the digital signals at an interval of 2 ns. The maximum LA sample rate of the oscilloscope is 1 GSa/s, and its display value is related to the sample rate of the current analog channel. -
Page 80: La Memory Depth
Chapter 4 To Set the Sample System RIGOL ensure a higher sample rate. Press Acquire Mem Depth, then rotate the multifunction knob to switch to the desired memory depth, and then press down the knob to select the option. You can also press the Mem Depth key continuously or enable the touch screen to select the memory depth. -
Page 81: Anti-Aliasing
Chapter 4 To Set the Sample System RIGOL Horizontal SCALE knob. In YT mode, press Acquire More Expand and then rotate the multifunction knob to select the desired reference position. Press down the knob to select it. You can also press Expand continuously to select it or enable the touch screen to tap the desired reference. - Page 82 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 83: Chapter 5 To Trigger The Oscilloscope
Chapter 5 To Trigger the Oscilloscope RIGOL Chapter 5 To Trigger the Oscilloscope As for trigger, you set certain trigger condition according to the requirement and when a waveform in the waveform stream meets this condition, the oscilloscope captures this waveform as well as the neighboring part, and displays them on the screen. -
Page 84: Trigger Source
Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Source In the trigger control area (Trigger) on the front panel, press Menu Source to select the desired source, or rotate the multi-function knob to select a desired source, then press down the knob to select it. You can also press Source continuously to select the trigger source or enable the touch screen to tap the desired trigger source and select it. -
Page 85: Trigger Level/Threshold Level
Chapter 5 To Trigger the Oscilloscope RIGOL Trigger LEVEL/Threshold Level The adjustment of the trigger level/threshold level is related to the type of the trigger source. When the trigger source is selected from CH1 to CH4, rotate the Trigger ... -
Page 86: Trigger Mode
Chapter 5 To Trigger the Oscilloscope RIGOL input a specific value with the displayed numeric keypad. Level Input Field Decrease the level Increase the level Trigger Mode The following is the schematic diagram of the acquisition memory. To easily understand the trigger event, we classify the acquisition memory into the pre-trigger buffer and post-trigger buffer. -
Page 87: Trigger Coupling
Chapter 5 To Trigger the Oscilloscope RIGOL are forced and acquisitions are made so as to display the waveforms. This trigger mode should be used when the signal level is unknown or the DC should be displayed as well as when forcible trigger is not necessary as the trigger condition always occurs. -
Page 88: Trigger Holdoff
Chapter 5 To Trigger the Oscilloscope RIGOL AC: blocks the DC components and attenuates signals. LFR: blocks the DC components and rejects the low-frequency components. HFR: rejects the high frequency components. When "AC" or "LFR" is selected under Coupling, no trigger level lines and trigger icons are displayed. -
Page 89: Noise Rejection
Chapter 5 To Trigger the Oscilloscope RIGOL Noise Rejection Noise rejection can reject the high frequency noise in the signal and reduce the possibility of miss-trigger of the oscilloscope. In the trigger control area (Trigger) on the front panel, press Menu to enter the trigger setting menu, then press Noise Reject continuously (for some triggers, Noise Reject is a sub menu under More, at this time, press Menu ... -
Page 90: Trigger Type
Chapter 5 To Trigger the Oscilloscope RIGOL Edge Trigger Triggers on the trigger level/threshold level of the specified edge of the input signal. Trigger Type: Press Menu Type in the trigger control area (Trigger) on the front panel and rotate the multifunction knob to select "Edge", then press down the knob to... -
Page 91: Edge Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL Please refer to descriptions in "Trigger LEVEL/Threshold Level". The current trigger level/threshold level value is displayed at the upper-right corner of the screen. Pulse Trigger Triggers on the positive or negative pulse with a specified width. In this mode, the oscilloscope will trigger when the pulse width of the input signal satisfies the specified pulse width condition. -
Page 92: Pulse Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL Polarity: Press Polarity continuously to select the desired polarity. The polarities available are positive polarity ( ) and negative polarity ( ). Trigger Condition: Press When, then rotate the multifunction knob to select the trigger condition, and then press down the knob to select the trigger condition. - Page 93 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Parameter Setting: Set the trigger parameters (trigger holdoff and noise rejection) under this trigger type. For details, refer to descriptions in "Trigger Holdoff" and "Noise Rejection". Trigger LEVEL/Threshold Level: Rotate the Trigger LEVEL knob to adjust the trigger level or threshold level.
-
Page 94: Slope Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL Edge Type: Press Slope continuously to select the input signal edge on which the oscilloscope triggers. Rising: triggers on the rising edge of the input signal. Falling: triggers on the falling edge of the input signal. - Page 95 Chapter 5 To Trigger the Oscilloscope RIGOL to correctly trigger the signal and obtain a stable waveform. Press Level Select (when "<>" is selected as the trigger condition, Level Select is a sub-menu under More), then rotate the multifunction knob to select the desired level type for adjustment, and then press down the knob to select the type.
- Page 96 Chapter 5 To Trigger the Oscilloscope RIGOL Video Trigger The video signal can include image information and timing information, which adopts different standards and formats. MSO5000 series can trigger on the standard video signal field or line of NTSC (National Television Standards Committee), PAL (Phase Alternating Line), or SECAM (Sequential Couleur A Memoire).
-
Page 97: Video Trigger
In the trigger debugging process of video signals, the frequency in different part of the signal can be reflected by a different brightness, as RIGOL digital oscilloscope provides the intensity graded color display function. Experienced users can quickly judge the signal quality and discover abnormalities during the debugging process. - Page 98 Chapter 5 To Trigger the Oscilloscope RIGOL Pattern Trigger Identifies a trigger condition by searching for a specified pattern. This pattern is a logical "AND" combination of channels. Each channel can be set to H (high), L (low), or X (don't care). A rising or falling edge (you can only specify a single edge) can be specified for one channel included in the pattern.
-
Page 99: Pattern Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL a part of the pattern. When all channels in the pattern are set to "X", the oscilloscope will not trigger. Rising: sets the pattern to the rising edge ( ) of the channel selected. - Page 100 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Mode: In the trigger control area (Trigger) on the front panel, press Mode to quickly switch the current trigger mode. For details, refer to descriptions in "Trigger Mode". Trigger Parameter Setting: Set the trigger parameters (trigger holdoff and noise rejection) under this trigger type.
-
Page 101: Duration Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL figure below. You can also press Type continuously to select the trigger type or enable the touch screen to tap the desired trigger type and select it. Source Selection: Press Source to open the signal source list and select CH1-CH4 or D0-D15. For details, refer to descriptions in "Trigger Source". - Page 102 Chapter 5 To Trigger the Oscilloscope RIGOL ><: triggers when the duration of the pattern is greater than the upper limit of the preset time and smaller than the lower limit of the preset time. Press Upper to set the upper limit of the duration of the pattern, and the range is from 800 ps to 10 s.
-
Page 103: Timeout Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Type: Press Type, and then rotate the multifunction knob to select "Timeout". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below. - Page 104 Chapter 5 To Trigger the Oscilloscope RIGOL Runt Trigger This trigger mode is used to trigger pulses that pass through one trigger level but fail to pass through another trigger level, as shown in the figure below. Positive Runt Pulse...
-
Page 105: Runt Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL <>: triggers when the runt pulse width is greater than the lower limit and smaller than the upper limit of pulse width. Press Upper to set the maximum pulse width of Runt trigger. Press Lower to set the minimum pulse width of Runt trigger. - Page 106 Chapter 5 To Trigger the Oscilloscope RIGOL type. For details, refer to descriptions in "Trigger Holdoff" and "Noise Rejection". Window Trigger Window trigger provides a high trigger level and a low trigger level. The instrument triggers when the input signal passes through the high trigger level or the low trigger level.
-
Page 107: Window Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL the specified trigger level range is equal to the window time. When this type is selected, press Time and rotate the multifunction knob to set the window time. You can also use the numeric keypad to set it. Its available range is from 8 ns to 10 s. - Page 108 Chapter 5 To Trigger the Oscilloscope RIGOL Delay Trigger In Delay trigger, you need to set Source A and Source B. The oscilloscope triggers when the time difference (△T) between the specified edges of Source A (Edge A) and Source B (Edge B) meets the preset time limit, as shown in the figure below.
-
Page 109: Delay Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL Edge B: Press EdgeB continuously to select the trigger edge type of Source B in Delay trigger. It can be set to "Rising" or "Falling" Trigger Condition: Press When to set the time limit condition of Delay trigger. - Page 110 Chapter 5 To Trigger the Oscilloscope RIGOL Setup/Hold Trigger In Setup/Hold trigger, you need to set the clock source and data source. The setup time starts when the data signal passes the trigger level and ends at the coming of the specified clock edge;...
-
Page 111: Setup/Hold Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL source (trigger source) is displayed at the upper-right corner of the screen. Note: Only when we select the channel (that has been input with signals) as the trigger source, can we obtain a stable trigger. - Page 112 Chapter 5 To Trigger the Oscilloscope RIGOL Nth Edge Trigger Triggers on the Nth edge that appears after the specified idle time. For example, in the waveform shown in the figure below, the instrument should trigger on the second rising edge after the specified idle time (the time between two neighboring rising edges), and the idle time should be within the range between P and M (P<Idle...
-
Page 113: Nth Edge Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL Idle Time: Press Idle to set the idle time before the edge counting in Nth edge trigger. Rotate the multifunction knob or use the pop-up numeric keypad to set the idle time. Edge Count: Press Edges to set the value of "N"... -
Page 114: Rs232 Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL Source: Press Source to open the signal source list and select CH1-CH4 or D0-D15. For details, refer to descriptions in "Trigger Source". The current trigger source is displayed at the upper-right corner of the screen. - Page 115 Chapter 5 To Trigger the Oscilloscope RIGOL specifies a clock frequency). Three setting methods are available for baud rate: Press Baud Rate, then set the user-defined baud rate with the displayed numeric keypad. Press Baud Rate, then select the preset baud rate from the available options.
- Page 116 Chapter 5 To Trigger the Oscilloscope RIGOL I2C Trigger (Option) I2C is a 2-wire serial bus used to connect the microcontroller and its peripheral device. It is a bus standard widely used in the microelectronic communication control field. The I2C serial bus consists of SCL and SDA. Its transmission rate is determined by SCL, and its transmission data is determined by SDA, as shown in the figure below.
-
Page 117: I2C Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL high level. Stop: triggers when SDA data transitions from low level to high level while SCL is high level. Restart: triggers when another start condition occurs before a stop condition. MissedAck: triggers when the SDA data is high level during any acknowledgment ... - Page 118 Chapter 5 To Trigger the Oscilloscope RIGOL Press Bytes, then rotate the multifunction knob or use the pop-up numeric keypad to set the length of the data. Its range is from 1 to 5. Press More Addr Bits, and rotate the multifunction knob to select ...
-
Page 119: Spi Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Type: Press Type, and then rotate the multifunction knob to select "SPI". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below. You can also press Type continuously to select the trigger type or enable the touch screen to tap the desired trigger type and select it. - Page 120 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Mode: In the trigger control area (Trigger) on the front panel, press Mode to quickly switch the current trigger mode. For details, refer to descriptions in "Trigger Mode". Trigger Parameter Setting: Set the trigger parameter (noise rejection) under this trigger type. For details, refer to descriptions in "Noise Rejection".
-
Page 121: Can Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Condition: Press When to select the desired trigger condition. SOF: triggers at the start of a frame. EOF: triggers at the end of a frame. Remote ID: triggers on the remote frame with the specified ID. Set the following ... - Page 122 Chapter 5 To Trigger the Oscilloscope RIGOL Baud Rate: Press More Baud to set the baud rate. Three setting methods are available for baud rate: Press Baud, then set the user-defined baud rate with the displayed numeric keypad.
- Page 123 Chapter 5 To Trigger the Oscilloscope RIGOL FlexRay Trigger (Option) MSO5000 can trigger on the specified frame, symbol, error, or position of the FlexRay bus. FlexRay is a type of differential serial bus configured with three consecutive segments (i.g. header, payload, and trailer). Its data transmission rate is up to 10 Mb/s.
-
Page 124: Flexray Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL matches the FlexRay bus signal. Then press down the knob to select the baud rate. You can also press Baud continuously or enable the touch screen to select it. The available baud rates are 2.5 Mbps, 5 Mbps, and 10 Mbps. - Page 125 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Mode: In the trigger control area (Trigger) on the front panel, press Mode to quickly switch the current trigger mode. For details, refer to descriptions in "Trigger Mode". Trigger Parameter Setting: Set the trigger parameter (noise rejection) under this trigger type. For details, refer to descriptions in "Noise Rejection".
-
Page 126: Lin Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL Sync: triggers on the last bit of the sync field. ID: triggers when the frame with an ID equal to the selected value is detected. Press ID, then rotate the multifunction knob or use the pop-up numeric keypad to set ID. - Page 127 Chapter 5 To Trigger the Oscilloscope RIGOL One Bit Figure 5-21 Sample Position Press More Sample Position, then rotate the multifunction knob or use the pop-up numeric keypad to set the sample position. The settable range is from 10% to 90%.
-
Page 128: I2S Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL Figure 5-22 Sequential Chart of I2S Bus Trigger Type: Press Type, and then rotate the multifunction knob to select "I2S". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below. - Page 129 Chapter 5 To Trigger the Oscilloscope RIGOL ≠: triggers when the channel's data do not equal the set data value. Press Data to set the data bit. For setting methods, refer to descriptions in "I2C Trigger (Option)". >: triggers when the channel's data are greater than the set data value. Press ...
- Page 130 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Parameter Setting: Set the trigger parameter (noise rejection) under this trigger type. For details, refer to descriptions in "Noise Rejection". Trigger LEVEL/Threshold Level: Rotate the Trigger LEVEL knob to adjust the trigger level/threshold level. Refer to "Trigger LEVEL/Threshold Level".
-
Page 131: Mil-Std-1553 Trigger (Option)
Chapter 5 To Trigger the Oscilloscope RIGOL ≠: triggers when the channel's data word does not equal the set data word. Press Min to set the lower limit of the data word. For setting methods, refer to descriptions in "I2C Trigger (Option)". - Page 132 Chapter 5 To Trigger the Oscilloscope RIGOL limit of the trigger level) remains unchanged. Note: In MIL-STD-1553 trigger, pressing Trigger LEVEL can quickly switch the current level adjustment type. Rotate the Trigger LEVEL knob to adjust the corresponding trigger level.
-
Page 133: Zone Trigger
Chapter 5 To Trigger the Oscilloscope RIGOL both Trigger zone A and Trigger zone B are disabled, then the zone trigger function is disabled. At this time, you must enable either of them to re-enable the zone trigger. Note: If the zone trigger function is enabled, "XY Mode", "ROLL Mode", and "Average"... - Page 134 Chapter 5 To Trigger the Oscilloscope RIGOL If you enable both Trigger zone A and Trigger zone B, then perform the "A&&B" operation, and it will become the final trigger condition. Trigger Output Connector The trigger output connector ([TRIG OUT]) on the rear panel of MSO5000 series can output trigger signals (hardware trigger) determined by the current setting.
-
Page 135: Trigger Output Connector
Chapter 6 Operations and Measurements RIGOL Chapter 6 Operations and Measurements MSO5000 can perform math operations, auto measurements, and cursor measurements on sampled and displayed data. Contents in this chapter: Math Operation Auto Measurement Cursor Measurement MSO5000 User's Guide GlobalTestSupply www. - Page 136 Chapter 6 Operations and Measurements RIGOL Math Operation Press Math in the vertical control area (Vertical) on the front panel to open the math operation menu. You can also tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then tap the "Math" icon to open the math operation menu.
-
Page 137: Chapter 6 Operations And Measurements
Chapter 6 Operations and Measurements RIGOL or enable the touch screen to select the channel. The available channels for SourceA and SourceB are CH1-CH4 and Ref1-Ref10. Note: The available channels for Math2 are CH1-CH4, Ref1-Ref10 or Math1. The available channels for Math3 are CH1-CH4, Ref1-Ref10, Math1 or Math2. -
Page 138: Math Operation
Chapter 6 Operations and Measurements RIGOL Note: The available channels for Math2 are CH1-CH4, Ref1-Ref10 or Math1. The available channels for Math3 are CH1-CH4, Ref1-Ref10, Math1 or Math2. The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected. -
Page 139: Subtraction
Chapter 6 Operations and Measurements RIGOL The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected. Press Offset to set the vertical offset of the operation results. For setting ... -
Page 140: Multiplication
Chapter 6 Operations and Measurements RIGOL The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected. Press Offset to set the vertical offset of the operation results. For setting ... -
Page 141: Division
Chapter 6 Operations and Measurements RIGOL frequency, and resolution are displayed at the bottom of the screen, as shown in the following figure. Of which, FFT resolution is the quotient of the sample rate and the number of FFT points. If the number of FFT points is a fixed value (65535 at most), then the lower the sample rate, the higher the resolution. -
Page 142: Fft
Chapter 6 Operations and Measurements RIGOL the frequency at the right side of the screen. Press End to set the stop frequency of the frequency-domain waveform. For setting methods, refer to descriptions in "Parameter Setting Method". Press More Peak Search to enter the peak search menu. - Page 143 Chapter 6 Operations and Measurements RIGOL Table 6-1 Window Function Window Waveforms Applicable to the Characteristics Function Window Function Rectangular Best frequency Transient or short pulse, the signal resolution levels before and after the Poorest multiplication are basically the same.
- Page 144 Chapter 6 Operations and Measurements RIGOL FFT shortcut operation: Enable the touch screen, and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then, tap the "FFT" icon to open the FFT menu. This oscilloscope supports 4 FFTs: FFT1, FFT2, FFT3, and FFT4.
- Page 145 Chapter 6 Operations and Measurements RIGOL threshold of Source A (or Source B) in logic operation. For setting methods, refer to descriptions in "Parameter Setting Method". The thresholds of the digital channels (D0-D15) are respectively set in the LA module.
-
Page 146: And" Operation
Chapter 6 Operations and Measurements RIGOL to select the channel for SourceA and Source B. Then press down the knob to select the channel. You can also press SourceA and SourceB continuously or enable the touch screen to select the channel. -
Page 147: Or" Operation
Chapter 6 Operations and Measurements RIGOL Table 6-4 Logic "XOR" Operation Press Math Math1 Operator to select "A^B": Press Operation continuously to enable or disable the "XOR" operation function. Press SourceA and SourceB respectively, and rotate the multifunction knob ... -
Page 148: Xor" Operation
Chapter 6 Operations and Measurements RIGOL "NOT" Operation Performs logic "NOT" operation on the waveform voltage values of the specified sources point by point and displays the results. In operation, when the voltage value of the source channel is greater than the threshold of the corresponding channel, it is regarded as logic "1";... - Page 149 Chapter 6 Operations and Measurements RIGOL Press More Sensitivity to set the sensitivity of the digital signal converted from the analog signal on the source. For setting methods, refer to descriptions in "Parameter Setting Method". Press More Label to set the label for math operation results. For details, ...
-
Page 150: Not" Operation
Chapter 6 Operations and Measurements RIGOL Diff Calculates the discrete time derivative of the selected source. For example, you can use differentiate to measure the instantaneous slope of a waveform. Press Math Math1 Operator to select "Diff": Press Operation continuously to enable or disable the "Diff" operation function. -
Page 151: Intg
Chapter 6 Operations and Measurements RIGOL Because differentiation is very sensitive to noise, it is helpful to set acquisition mode to "Average". Sqrt Calculates the square root of the selected source point by point and displays the results. Press Math Math1 Operator to select "Sqrt": Press Operation continuously to enable or disable the "Sqrt"... -
Page 152: Diff
Chapter 6 Operations and Measurements RIGOL Lg (Base 10 Exponential) Calculates the base 10 exponential of the selected source point by point and displays the results. Press Math Math1 Operator to select "Lg": Press Operation continuously to enable or disable the "Lg" operation function. -
Page 153: Sqrt
Chapter 6 Operations and Measurements RIGOL Press Operation continuously to enable or disable the "Ln" operation function. Press SourceA, and rotate the multifunction knob to select the channel for SourceA. Then press down the knob to select the channel. You can also press SourceA continuously or enable the touch screen to select the channel. -
Page 154: Lg (Base 10 Exponential)
Chapter 6 Operations and Measurements RIGOL The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected. Press Offset to set the vertical offset of the operation results. For setting ... -
Page 155: Exp
Chapter 6 Operations and Measurements RIGOL the touch screen and use the "Pinch & Stretch" gesture to adjust the vertical scale. Press AutoScale to adjust the vertical scale and offset of the operation results to an optimal value based on the current configuration, so as to better observe. -
Page 156: Abs
Chapter 6 Operations and Measurements RIGOL results to an optimal value based on the current configuration, so as to better observe. Press More Invert to enable or disable the inverted display function of the waveform. Press More Label to set the label for math operation results. For details, ... -
Page 157: Low Pass
Chapter 6 Operations and Measurements RIGOL waveform. Press More Label to set the label for math operation results. For details, refer to descriptions in "Math Operation Label". Press More Color Grade to enable or disable the color grade display of the ... -
Page 158: High Pass
Chapter 6 Operations and Measurements RIGOL refer to descriptions in "Math Operation Label". Press More Color Grade to enable or disable the color grade display of the operation results. When enabled, different colors are displayed on the screen to indicate the times of data acquisition or acquisition probability. -
Page 159: Band Pass
Chapter 6 Operations and Measurements RIGOL operation results. When enabled, different colors are displayed on the screen to indicate the times of data acquisition or acquisition probability. Press More Reset Color Grade to clear the color grade display and display ... -
Page 160: Band Stop
Chapter 6 Operations and Measurements RIGOL Press More Reset Color Grade to clear the color grade display and display the color grade again. Math Operation Label Press Label to enter the label setting menu. Press Display continuously to enable or disable the label display of the ... -
Page 161: Ax+B
Chapter 6 Operations and Measurements RIGOL Auto Measurement MSO5000 provides auto measurements for 41 waveform parameters, as well as the statistics and analysis of the measurement results. Quick Measurement after AUTO When the oscilloscope is correctly connected and has detected a valid input signal, press AUTO to enable the waveform auto setting function and open the auto setting function menu. -
Page 162: Math Operation Label
Chapter 6 Operations and Measurements RIGOL If you lock the Auto function and then exit the auto setting function menu, you can press Utility More Auto Config to enter the auto setting function menu again to unlock the Auto function. -
Page 163: Auto Measurement
Chapter 6 Operations and Measurements RIGOL Measurement Parameter Press Measure on the front panel to enter the measurement setting menu. You can set the measurement source, enable or disable the all measurement function, the statistical analysis function, and etc. You can also quickly make measurements for 41 waveform parameters. - Page 164 Chapter 6 Operations and Measurements RIGOL 6． -Width: indicates the time between the threshold middle value of a falling edge to the threshold middle value of the next rising edge. 7． +Duty: indicates the ratio of the positive pulse width to the period.
-
Page 165: Measurement Parameter
Chapter 6 Operations and Measurements RIGOL Rising Edge Count = n Threshold Upper Limit Threshold Lower Limit 4． Falling Edge Count: The number of falling edges that fall from above the threshold upper limit to below the threshold lower limit. - Page 166 Chapter 6 Operations and Measurements RIGOL indicates that the falling edge of Source A occurred after that of Source B. 3． Delay A →B : indicates the time difference between the threshold middle values of the rising edge of Source A and the falling edge of Source B. Negative delay indicates that the rising edge of Source A occurred after the falling edge of Source B.
- Page 167 Chapter 6 Operations and Measurements RIGOL Note: Source A and Source B can be any channel among CH1-CH4, Math1-Math4, or D0-D15. You can press Measure Add to enter the sub-menu to set the parameters. The default threshold middle value is 50%. You can press Measure Setting ...
- Page 168 Chapter 6 Operations and Measurements RIGOL gating area. The formula is shown as follows: ∑ Average Wherein, is the measurement result of the i th point, and n is the number of points being measured. 11. VRMS: indicates the root mean square value on the whole waveform or in the gating area.
- Page 169 Chapter 6 Operations and Measurements RIGOL reference is negative. The area measured is the algebraic sum of the whole period area. Measurement Settings 1． Measurement Category Press Measure Add Category to select "Horizontal", "Vertical", or "Other". Meanwhile, the specific measurement parameters are displayed on the screen, as shown in the figure below.
- Page 170 Chapter 6 Operations and Measurements RIGOL parameters. When you rotate the multifunction knob to switch from the measurement parameter area to the measurement category area, you need to press down the knob to select the desired measurement category. In the measurement category area, rotate the multifunction knob ...
-
Page 171: Measurement Settings
Chapter 6 Operations and Measurements RIGOL Normal: executes measurement of up to 1 Mpts. Precision: executes measurement of up to 500 Mpts, improving the resolution of measurement results. Note, in this mode, the refresh rate of the waveforms may be reduced. - Page 172 Chapter 6 Operations and Measurements RIGOL Modifying the threshold will affect the measurement results of the time, delay and phase parameters. If you select "Manual" under Amp Method, the measurement results of other parameters may be affected. "Histogram" and "Max-Min" are the internal measurement ...
- Page 173 Chapter 6 Operations and Measurements RIGOL Press Measure Statistic to enter the sub-menu of "Statistic". Press Statistic to enable or disable the statistical function. Press Reset Stat. to clear the history statistics data and makes statistics again. ...
-
Page 174: Remove The Measurement Result
Chapter 6 Operations and Measurements RIGOL X Cursor (Cursor A) X Cursor (Cursor B) Y Cursor (Cursor A) Y Cursor (Cursor B) X Cursor X cursor is a vertical solid/dotted line that is used to make horizontal adjustments. It can be used to measure time (s), frequency (Hz), phase (°), and ratio (%). -
Page 175: All Measurement
Chapter 6 Operations and Measurements RIGOL Note: When the Time Base Mode is set to "XY", the XY cursor measurement mode is valid. Manual Mode In this mode, you can adjust the cursor manually to measure the value of the waveforms of the specified source at the current cursor. - Page 176 Chapter 6 Operations and Measurements RIGOL channels are None, CH1-CH4, LA, and Math1-Math4. Note: Only channels currently enabled can be selected. When "LA" is selected under Source, Select is grayed out and disabled. By default, "X" is selected under Select.
-
Page 177: Manual Mode
Chapter 6 Operations and Measurements RIGOL 5. Set the Horizontal/Vertical Measurement Unit When "X" is selected under Select, you can set the horizontal measurement unit. When the source can be Math1-Math4, this menu is grayed out and disabled. Press More Hori. Unit, and rotate the multifunction knob to select the horizontal measurement unit. - Page 178 Chapter 6 Operations and Measurements RIGOL The available units include "Source" and "Percent(%)". Source: measures the amplitude at Y Cursor (taking the channel ground point as the reference). The measurement results include AY, BY, and △Y (its unit is consistent with that of the current source).
- Page 179 Chapter 6 Operations and Measurements RIGOL Track Mode In this mode, you can adjust the two pairs of cursors (Cursor A and Cursor B) to measure the X and Y values on two different sources respectively. The points being measured on Cursor A and Cursor B are marked by respectively.
- Page 180 Chapter 6 Operations and Measurements RIGOL Press Track to select "X" or "Y" as the current track axis. The default is "X". X: tracks X Cursor and measures the value at X Cursor. Y: tracks Y Cursor and measures the time of the first point at the left side of ...
-
Page 181: Track Mode
Chapter 6 Operations and Measurements RIGOL Track Measurement (before Horizontal Expansion): Track Measurement (after Horizontal Expansion): XY Mode XY mode is only available when the horizontal time base mode is "XY" (refer to "Timebase Mode"). In this mode, two pairs of cursors will appear. You can adjust the cursor positions to measure the X and Y values at the crossing points of the two pairs of cursors. - Page 182 Chapter 6 Operations and Measurements RIGOL △X: indicates the horizontal spacing between Cursor A and Cursor B. △Y: indicates the vertical spacing between Cursor A and Cursor B. 1. Adjust Cursor Position Press AX and rotate the multifunction knob to adjust the X value at ...
-
Page 183: Xy Mode
Chapter 6 Operations and Measurements RIGOL Measure Mode Press Mode to select "Measure". In this mode, the cursor position for measurement is displayed. Press Indicator continuously to enable or disable the indicator. If it is enabled, one or multiple cursors are displayed on the screen. Before enabling the indicator, you need to enable at least one parameter for auto measurement. - Page 184 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 185: Measure Mode
Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Chapter 7 Digital Voltmeter (DVM) and Frequency Counter MSO5000 series oscilloscope provides a built-in digital voltmeter (DVM) and frequency counter, which enable you to perform an accurate measurement, improving user experience in counter and frequency measurement. - Page 186 Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Digital Voltmeter (DVM) The built-in DVM of this oscilloscope provides 3-digit voltage measurements on any analog channel. DVM measurements are asynchronous from the oscilloscope’s acquisition system and are always acquiring. Press Measure Analyze DVM to open the DVM setting menu, or enable the...
-
Page 187: Chapter 7 Digital Voltmeter (Dvm) And Frequency Counter
Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Note: Even if the analog channel (CH1-CH4) is not enabled, you can still perform the DVM measurement. To Select Measurement Mode Press Mode in the "DVM" setting menu, then rotate the multifunction knob select the desired mode, and then press down the knob to select the mode. -
Page 188: Digital Voltmeter (Dvm)
Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Frequency Counter The frequency counter analysis function provides frequency, period, or edge event counter measurements on any analog channel. Press Measure Analyze Counter to open the frequency counter setting menu, or enable the touch screen and then tap the function navigation icon the lower-left corner of the screen to open the function navigation. -
Page 189: To Select Measurement Mode
Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL item. You can also press Measure continuously or enable the touch screen to tap the desired measurement item and select it. To Set Resolution For Period and Frequency measurements, you need to set the readout resolution. -
Page 190: Frequency Counter
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... -
Page 191: To Set Resolution
Chapter 8 Power Analysis (Option) RIGOL Chapter 8 Power Analysis (Option) MSO5000 series oscilloscope provides an optional power analysis function, which can help you easily analyze the efficiency and reliability of the switch-mode power supplies. With the power analysis function, you can analyze the power quality and output ripple noise of the input power. - Page 192 Chapter 8 Power Analysis (Option) RIGOL Power Quality By analyzing the power quality, you can test the quality of AC input lines. The specific measurement parameters for power quality analysis include V_RMS, I_RMS, real power, apparent power, reactive power, power factor, reference frequency, phase angle, impedance, voltage crest factor, and current crest factor.
-
Page 193: Chapter 8 Power Analysis (Option)
Chapter 8 Power Analysis (Option) RIGOL settings of the upper limit and lower limit. Press Lower, then rotate the multifunction knob or use the pop-up numeric keypad to set the lower limit. Increasing the lower limit to the current middle value will automatically increase the middle value and upper limit to keep them higher than the lower limit. -
Page 194: Power Quality
Chapter 8 Power Analysis (Option) RIGOL Figure 8-1 Connection Diagram of Power Quality Analysis Ripple Power ripple is an important parameter for evaluating DC power supply, which indicates the ripple quantity of the output DC voltage. The ripple analysis can measure the current value, average value, minimum value, maximum value, standard deviation, and count value of the ripples on the power output terminal. - Page 195 Chapter 8 Power Analysis (Option) RIGOL the figure below. You can also enable the touch screen to tap the icon at the right-upper corner of the statistical results window to close it. View the Connection Diagram Press Tips, and then the connection diagram of the ripple analysis is displayed on the screen.
-
Page 196: Ripple
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... - Page 197 Chapter 9 Histogram Analysis RIGOL Chapter 9 Histogram Analysis MSO5000 series oscilloscope supports the standard histogram analysis function, enabling you to judge the trend of waveforms, and quickly locate the potential problems of the signal. Contents in this chapter: To Enable or Disable the Histogram Function ...
- Page 198 Chapter 9 Histogram Analysis RIGOL To Enable or Disable the Histogram Function The histogram analysis function supported by the MSO5000 series is available to provide a statistical view of waveforms or measurement results. It can be classified into horizontal histogram, vertical histogram, and measurement histogram. With the...
-
Page 199: Chapter 9 Histogram Analysis
Chapter 9 Histogram Analysis RIGOL To Select the Histogram Source If "Horizontal" or "Vertical" is selected under Type, you need to set the source (CH1-CH4). Press Source, then rotate the multifunction knob to select the desired source, and then press down the knob to select the source. You can also press Source continuously or enable the touch screen to select it. -
Page 200: To Enable Or Disable The Histogram Function
Chapter 9 Histogram Analysis RIGOL Sum: indicates the sum of all bins (buckets) in the histogram. Peaks: indicates the maximum number of hits in any single bin. Max: indicates the maximum value within the histogram range. Min: indicates the minimum value within the histogram range. -
Page 201: To Select The Histogram Source
Chapter 10 Digital Channel RIGOL Chapter 10 Digital Channel MSO5000 series oscilloscope has an standard configuration of the logic analyzer (LA) function, and it has 16 digital channels. The default channel label is D15-D0. The oscilloscope compares the voltages acquired in each sample with the preset logic threshold. -
Page 202: To Reset
Chapter 10 Digital Channel RIGOL To Select the Digital Channel Press LA on the front panel to enter the LA setting menu. Press Select to open the channel menu, and rotate the multifunction knob to select the channel. You can also press Select continuously or enable the touch screen to select it. -
Page 203: Chapter 10 Digital Channel
Chapter 10 Digital Channel RIGOL Enable/disable a single digital channel Press Dx On/Off to open the channel selection list. Rotate the multifunction knob to select a channel, and then press down the knob to enable or disable it. You can also press Dx On/Off continuously to switch to select any channel, and press down the multifunction knob to enable or disable the channel. -
Page 204: To Select The Digital Channel
Chapter 10 Digital Channel RIGOL displayed. Tap to select the preset threshold. Or tap the threshold input field and input the value with the pop-up numeric keypad. Probe Calibration When the probe is connected to the oscilloscope for the first time or the temperature change is more than 5 degrees, you are recommended to calibrate the probe zero using the calibration function. -
Page 205: To Set The Threshold And Calibrate Probe
Chapter 10 Digital Channel RIGOL Select a specified digital channel Press Select and rotate the multifunction knob to select the desired digital channel that needs a label. You can also press Select continuously or enable the touch screen to select the channel. Select any channel from D0-D15. -
Page 206: Auto Arrangement Setting
Chapter 10 Digital Channel RIGOL If no group is set, the Ungroup menu and the Group On/Off menu are grayed out and disabled. Waveform Color of the Digital Channel When the digital channel is enabled, its corresponding waveforms and label are displayed on the screen. -
Page 207: Group Setting
Chapter 11 Protocol Decoding RIGOL Chapter 11 Protocol Decoding You can use the protocol analysis to discover errors, debug hardware, and accelerate development easily, ensuring you to accomplish the projects with high speed and good quality. Protocol decoding is the basis of protocol analysis. Only protocol analyses with correct protocol decoding are acceptable, and only correct protocol decoding can identify more error information. -
Page 208: Waveform Color Of The Digital Channel
Chapter 11 Protocol Decoding RIGOL Parallel Decoding Parallel bus consists of clock line and data line. As shown in the figure below, CLK is the clock line, whereas Bit0 and Bit1 are the 0 bit and 1st bit on the data line respectively. -
Page 209: Chapter 11 Protocol Decoding
Chapter 11 Protocol Decoding RIGOL Falling : samples the channel data on the falling edge of the clock. Both : samples the channel data on both the rising edge and the falling edge of the clock. Set the threshold ... -
Page 210: Parallel Decoding
Chapter 11 Protocol Decoding RIGOL D8-D15 8 0 (default) Bit0 to Bit7 are set to D15 to D8 (default) respectively. Width is set automatically, and you cannot modify them. D0-D15 16 0 (default) Bit0 to Bit15 are set to D15 to (default) D0 respectively. - Page 211 Chapter 11 Protocol Decoding RIGOL Press Endian continuously to select "Normal" or "Invert" as the endian of the bus. Polarity Press Polarity continuously to select Positive or Negative as the polarity for data decoding. 4． Display-related setting Press Display to enter the display setting menu.
- Page 212 Chapter 11 Protocol Decoding RIGOL Line Number Time Decode Name Decoded data Event Table Parallel Bus Figure 11-2 Parallel Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
- Page 213 Chapter 11 Protocol Decoding RIGOL details in the "Packets" view. Export: If you select "Packets", you can export time and the corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.
- Page 214 Chapter 11 Protocol Decoding RIGOL Figure 11-4 Schematic Diagram of Negative Logic In RS232, baud rate is used to represent the transmission rate (namely bits per second) of the data. You need to set the start bit, data bits, check bit (optional), and stop bit for each frame of data.
-
Page 215: Rs232 Decoding (Option)
Chapter 11 Protocol Decoding RIGOL 4． Source setting Press Sources to enter the source setting menu. Set the Tx source and the threshold Press Tx and rotate the multifunction knob to select the desired channel, and then press down the knob. You can also press Tx continuously or enable the touch screen to select it. - Page 216 Chapter 11 Protocol Decoding RIGOL is an odd number. For example, when 0x55 (01010101) is sent, "1" should be added to the check bit. Stop Bit Press Stop Bit and rotate the multifunction knob to set the stop bits after each frame of data.
- Page 217 Chapter 11 Protocol Decoding RIGOL Adjust the vertical position of the bus Press Position, and then rotate the multifunction knob to adjust the vertical display position of the bus. Set the label display Press Label to enable or disable the label display of the RS232 decoding bus.
- Page 218 Chapter 11 Protocol Decoding RIGOL the top of the event table to select it. If you select "Packets", the time and decoded data are displayed in the event table; if you select "Details", the detailed data in the specified row will be displayed in the event table; if you select "Payload", all data in the specified column will be displayed in the event table.
- Page 219 Chapter 11 Protocol Decoding RIGOL EOF Error This error is generated when the EOF condition is not met. For example, if the Stop Bit is set to 1.5, but the actual stop bits is less than 1.5 bits, then...
- Page 220 Chapter 11 Protocol Decoding RIGOL I2C Decoding (Option) The oscilloscope samples the LIN signal, and judges each data point to be logic "1" or logic "0" according to the preset threshold level. I2C serial bus consists of the clock line (SCLK) and the data line (SDA).
- Page 221 Chapter 11 Protocol Decoding RIGOL Exchange sources Press Exchange to select "SCL/SDA" or "SDA/SCL" to exchange the sources of the current clock channel and data channel. 4． Specify whether the address information includes the "R/W" bit For I2C bus, each frame of data starts with the address information. The address information includes the read address and the write address.
-
Page 222: I2C Decoding (Option)
Chapter 11 Protocol Decoding RIGOL Line Number Time R/W Bit Address Decoded data Event Table I2C Bus Figure 11-6 I2C Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed. - Page 223 Chapter 11 Protocol Decoding RIGOL data, it indicates that the decoded data are not fully displayed. At this time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time, the corresponding ...
- Page 224 Chapter 11 Protocol Decoding RIGOL The detected ACK is 1 SPI Decoding (Option) SPI bus is based on the master-slave configuration and usually consists of chip select line (CS), clock line (SCLK), and data line (SDA). Wherein, the data lines include the master input/slave output (MISO) data line and master output/slave input (MOSI) data line.
- Page 225 Chapter 11 Protocol Decoding RIGOL 2． Quickly apply SPI trigger settings to SPI decoding Press Copy Trig to copy the SPI trigger settings and apply them to SPI decoding function (set the corresponding SPI decoding parameters automatically). For analog channels, the threshold level settings will also be copied.
-
Page 226: Spi Decoding (Option)
Chapter 11 Protocol Decoding RIGOL You can also press MISO continuously or enable the touch screen to select it. The available channels include OFF, analog channels (CH1-CH4), and digital channels (D0-D15). When you select an analog channel (CH1-CH4), press Threshold below the MISO menu, then... - Page 227 Chapter 11 Protocol Decoding RIGOL Adjust the vertical position of the bus Press Position, and then rotate the multifunction knob to adjust the vertical display position of the bus. Set the label display Press Label to enable or disable the label display of the SPI decoding bus.
- Page 228 Chapter 11 Protocol Decoding RIGOL Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
- Page 229 Chapter 11 Protocol Decoding RIGOL LIN Decoding (Option) The oscilloscope samples the LIN signal, and judges each data point to be logic "1" or logic "0" according to the preset threshold level. The LIN decoding is required to specify the LIN signal protocol version.
- Page 230 Chapter 11 Protocol Decoding RIGOL Press Parity bit continuously to select whether the data contain the parity bit. Set the protocol version Press Version and rotate the multifunction knob to select a protocol version that matches the LIN bus signal. Then, press down the knob to select it.
-
Page 231: Lin Decoding (Option)
Chapter 11 Protocol Decoding RIGOL Line Number Time Frame ID Decoded Data CRC Error Event Table LIN Bus Figure 11-9 LIN Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed. - Page 232 Chapter 11 Protocol Decoding RIGOL time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.
- Page 233 Chapter 11 Protocol Decoding RIGOL Parity Error Checksum Error If the checksum error is detected, CRC is displayed in red, as shown in the figure below. Checksum Error Sync Error If the sync error is detected, SYNC is displayed in red, as shown in the figure below.
- Page 234 Chapter 11 Protocol Decoding RIGOL Sync Error CAN Decoding (Option) The oscilloscope samples the CAN signal at the specified sample position. The oscilloscope will also judge each data point (logic "1" or logic "0") according to the preset threshold level. You need to specify the CAN signal type and sample position for CAN decoding.
- Page 235 Chapter 11 Protocol Decoding RIGOL clock channel, a dotted line displaying the current threshold level is displayed on the screen. The dotted line disappears in about 2 s after you stop modifying the threshold. 4. Signal setting Press Settings to enter the signal setting menu.
-
Page 236: Can Decoding (Option)
Chapter 11 Protocol Decoding RIGOL Press Sample Position, then rotate the multifunction knob or use the pop-up numeric keypad to set the sample position. The settable range is from 10% to 90%. 5. Display-related Setting Press Display to enter the display setting menu. - Page 237 Chapter 11 Protocol Decoding RIGOL Line Number Time Frame ID DLC Decoded Data Event Table CAN Bus Figure 11-11 CAN Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
- Page 238 Chapter 11 Protocol Decoding RIGOL time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.
- Page 239 Chapter 11 Protocol Decoding RIGOL FlexRay Decoding (Option) FlexRay is a type of differential serial bus configured with three consecutive segments (i.g. header, payload, and trailer). The oscilloscope samples the FlexRay signal at the specified sample position and judges each data point as logic "1" or logic "0"...
- Page 240 Chapter 11 Protocol Decoding RIGOL desired baud rate. Set the signal type Press Signal and rotate the multifunction knob to select a signal type that matches the actual FlexRay bus signal. Press down the knob to select it. You can also press Signal continuously or enable the touch screen to select it.
-
Page 241: Flexray Decoding (Option)
Chapter 11 Protocol Decoding RIGOL Event table Press Event Table to enter the event table setting menu. The event table displays the detailed decoding information in time order in the form of a table, so as to better observe the long decoded data. The decoding information includes the decoded data, the corresponding line number, time, frame ID, and Payload Length (PL). - Page 242 Chapter 11 Protocol Decoding RIGOL formats include "Hex", "Dec", "Bin", and "ASC". Set the view type: Press View, then rotate the multifunction knob to select the form of the event table to be viewed. Press down the knob to select it. You can also press View continuously or enable the touch screen to select it.
- Page 243 Chapter 11 Protocol Decoding RIGOL TSS Sync Frame Frame PL HCRC CYC Data TCRC I2S Decoding (Option) The oscilloscope samples the I2S signal and judges each data point as logic "1" or logic "0" according to the preset threshold level. I2S decoding is required to specify the serial clock, channel signal, and the data's source channel.
- Page 244 Chapter 11 Protocol Decoding RIGOL "Falling( )" as the desired clock edge. Set the WS source and the threshold Press WS and rotate the multifunction knob to select the desired channel, and then press down the knob to select it. You can also press WS continuously or enable the touch screen to select it.
-
Page 245: I2S Decoding (Option)
Chapter 11 Protocol Decoding RIGOL Press WS Low continuously to select "Left" or "Right". Endian Press Endian to select "LSB" or "MSB". By default, it is "LSB". Polarity setting Press Data Polarity continuously to select Positive or Negative the polarity for data decoding. - Page 246 Chapter 11 Protocol Decoding RIGOL Line Number Time Left Channel Data Right Channel Event Table I2S Bus Figure 11-14 I2S Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
- Page 247 Chapter 11 Protocol Decoding RIGOL displayed in the event table. If "…" appears in the specified column of data, it indicates that the decoded data are not fully displayed. At this time, you can view the details in the "Packets" view.
- Page 248 Chapter 11 Protocol Decoding RIGOL threshold level is displayed on the screen. The dotted line disappears in about 2 s after you stop modifying the threshold. 4. Display-related setting Press Display to enter the display setting menu. Set the display format ...
-
Page 249: 1553B Decoding (Option)
Chapter 11 Protocol Decoding RIGOL Line Number Time Word Type Data Error Event Table 1553B Bus Figure 11-15 1553B Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed. - Page 250 Chapter 11 Protocol Decoding RIGOL data, it indicates that the decoded data are not fully displayed. At this time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the ...
- Page 251 Chapter 12 Reference Waveform RIGOL Chapter 12 Reference Waveform MSO5000 series oscilloscope provides 10 reference waveform positions (Ref1-Ref10). In the actual test process, you can compare the signal waveform with the reference waveform to locate the failure. Contents in this chapter: To Enable Ref Function ...
- Page 252 Chapter 12 Reference Waveform RIGOL To Enable Ref Function Press Ref on the front panel to enable the reference waveform function, or enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then, tap the "Ref" icon to enable the reference waveform function.
-
Page 253: Chapter 12 Reference Waveform
Chapter 12 Reference Waveform RIGOL Press VOffset, then rotate the multifunction knob or use the pop-up numeric keypad to set the vertical offset of the reference waveform. You can also enable the touch screen and use the "Drag" gesture to adjust the vertical offset. -
Page 254: To Enable Ref Function
Chapter 12 Reference Waveform RIGOL To Reset the Reference Waveform Press More Reset, and the reference waveform is restored to the position where the source channel waveform is located when the SaveToRef operation was executed. Color Setting MSO5000 series oscilloscope provides five colors (gray, green, blue, red, and orange) to mark the reference waveforms of different channels in order to distinguish the reference waveforms of different reference waveform channels. -
Page 255: To Save To Internal Memory
Chapter 12 Reference Waveform RIGOL To Export to Internal or External Memory You can also save the current reference waveform to the internal memory or external USB storage device. The file format of the reference waveform is ".ref", ".bin", or ".csv". -
Page 256: To Reset The Reference Waveform
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... -
Page 257: To Export To Internal Or External Memory
Chapter 13 Pass/Fail Test RIGOL Chapter 13 Pass/Fail Test During the product design and manufacturing process, you usually need to monitor the variations of the signal or judge whether the product is up to standard. The pass/fail test function of MSO5000 series oscilloscope can accomplish this task perfectly. - Page 258 Chapter 13 Pass/Fail Test RIGOL To Enable or Disable the Pass/Fail Test Function Press Utility PassFail to open the pass/fail test setting menu, or enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation.
-
Page 259: Chapter 13 Pass/Fail Test
Chapter 13 Pass/Fail Test RIGOL To Create a Mask Press Mask Create to self-define the mask of the pass/fail test. Press Range and rotate the multifunction knob to select the mask range. Press down the knob to select it. You can also press Range continuously or enable the touch screen to select it. -
Page 260: To Enable Or Disable The Pass/Fail Test Function
Chapter 13 Pass/Fail Test RIGOL them to the current pass/fail test function. To Set the Output Form of the Test Results Press Option to enter the "Option" menu. You can set what the oscilloscope will execute when test results are detected according to your needs. -
Page 261: To Create A Mask
Chapter 13 Pass/Fail Test RIGOL To Enable or Disable the Display of the Statistics of the Test Results Press Information continuously to enable or disable the display of the statistics of the test results. You can also enable the touch screen to tap the icon at the right-upper corner of the statistics window to close it. -
Page 262: To Set The Output Form Of The Test Results
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... -
Page 263: To Enable Or Disable The Display Of The Statistics Of The Test Results
Chapter 14 Waveform Recording & Playing RIGOL Chapter 14 Waveform Recording & Playing Waveform recording & playing function can play the recorded waveforms of the analog input channels (CH1-CH4) and the digital channels (D0-D15), enabling you to analyze the waveforms better. - Page 264 Chapter 14 Waveform Recording & Playing RIGOL Common Settings Press Utility Record to enter the waveform recording function setting menu. You can also enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then, tap the "Record"...
-
Page 265: Chapter 14 Waveform Recording & Playing
Chapter 14 Waveform Recording & Playing RIGOL 4. Set Transition Press Jump To continuously to select to jump to the recorded end frame Last) or the recorded start frame ( First). For settings of the start and end frames, refer to descriptions in "Play Options". -
Page 266: Common Settings
Chapter 14 Waveform Recording & Playing RIGOL Memory Depth = Sample Rate x Horizontal Time Base x Number of Grids in the Horizontal Direction. Therefore, the maximum number of frames of waveform recording is also related to the "Sample Rate" and "Horizontal Time Base". This oscilloscope provides ceaseless recording for a maximum of 450,000 frames of real-time waveforms. -
Page 267: Record Options
Chapter 14 Waveform Recording & Playing RIGOL 5. End Frame Press End Frame, then rotate the multifunction knob or use the pop-up numeric keypad to set the end frame of playback. The default is the number of frames of the recorded waveforms. -
Page 268: Play Options
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... - Page 269 Chapter 15 Search and Navigation Function RIGOL Chapter 15 Search and Navigation Function The search function allows you to search for relevant events based on the search condition that you set. The navigation function includes the recording & playing navigation, time navigation, and event navigation.
- Page 270 Chapter 15 Search and Navigation Function RIGOL Search Function The search function enables you to search the channel edge, Pulse trigger, Runt trigger, Slope trigger, RS232 trigger, I2C trigger, or SPI trigger. Press Search on the front panel to enable the search setting menu. You can also enable the touch screen...
-
Page 271: Chapter 15 Search And Navigation Function
Chapter 15 Search and Navigation Function RIGOL and SDA. SPI: Press Type to select "SPI" as the search type. For SPI Set menu settings, refer to descriptions in "SPI Trigger (Option)". Press Threshold to enter the threshold setting menu. Rotate the multifunction... -
Page 272: Search Function
Chapter 15 Search and Navigation Function RIGOL to descriptions in "Navigation Function". 6. Save You can save the event mark data to the internal memory or external USB storage device in "*.csv" format. Press More Save to enter the file saving interface. Please refer to descriptions in "Store and Load"... - Page 273 Chapter 15 Search and Navigation Function RIGOL number in the mark table decreases); press to navigate to the next event (the serial number in the mark table increases); the key is disabled in the event navigation. MSO5000 User's Guide 15-5 GlobalTestSupply www.
-
Page 274: Navigation Function
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... - Page 275 Chapter 16 Display Control RIGOL Chapter 16 Display Control In the display control setting menu, you can set the parameters such as the waveform display type, persistence time, intensity, grid type, grid brightness, and etc. Contents in this chapter: To Select the Display Type ...
- Page 276 Chapter 16 Display Control RIGOL To Select the Display Type Press Display to enter the display control setting menu. Press Type continuously to set the waveform display mode to "Vector" or "Dots". Vector display: indicates that the sample points are connected by lines and ...
-
Page 277: Chapter 16 Display Control
Chapter 16 Display Control RIGOL To Set the Waveform Intensity Press Intensity, then rotate the multifunction knob at a small step value or use the pop-up numeric keypad to set the waveform intensity. Note that in the non-menu operation mode, you can also rotate the multifunction knob to adjust the waveform brightness of the channel. -
Page 278: To Select The Display Type
Chapter 16 Display Control RIGOL To Set the Grid Brightness Press Brightness, then rotate the multifunction knob at a small step value or use the pop-up numeric keypad to set the grid intensity. The default is 20%, and the range available is from 1% to 100%. -
Page 279: To Set The Waveform Intensity
The file types include "*.png", "*.bmp", "*.jpg", and "*.tif". If you select "Text" under Screen Saver, press Text, and then the filename input interface is displayed, e.g. inputting "RIGOL Scope". For details, refer to descriptions in "To Create a Folder". 2. Set the Wait Time... -
Page 280: To Set The Grid Brightness
GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... - Page 281 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Chapter 17 Function/Arbitrary Waveform Generator (Option) MSO5000 series has an optional built-in dual-channel, 25 MHz signal source, which integrates the signal source and the oscilloscope into one, providing great convenience for engineers who need to use the signal source and oscilloscope at the same time.
- Page 282 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL To Output Basic Waveforms Press GI on the front panel or enable the touch screen to tap the GI label at the bottom of the screen to enable/disable the output of the [GI] connector on the front panel, and enter the Function/Arbitrary Waveform Generator setting interface.
-
Page 283: Chapter 17 Function/Arbitrary Waveform Generator (Option)
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL continuously to select it. Also, you can enable the touch screen to select it. Rotate the multifunction knob or use the pop-up numeric keypad to set the offset or low level value of the current signal. When Impedance is set to "HighZ", the available range is from (-2.5 V+currently set amplitude value/2) to (2.5 V-... -
Page 284: To Output Basic Waveforms
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL To Output Ramp Press Wave, rotate the multifunction knob to select "Ramp". Press down the knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the ramp waveform. For setting methods, refer to descriptions in "To Output Sine". -
Page 285: To Output Square
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Press Settings Duty Cycle, then rotate the multifunction knob or use the pop-up numeric keypad to set the duty cycle of the current pulse signal. Its settable range is from 10% to 90%. -
Page 286: To Output Ramp
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL offset or low level value of the current signal. 3. Set the impedance Press Impedance continuously to set the output impedance of the Function/Arbitrary Waveform Generator. It can be set to "HighZ" or "50Ω". -
Page 287: To Output Dc
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Exp.Fall Press Wave, rotate the multifunction knob to select "Exp.Fall". Press down the knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the Exp.Fall waveform (as shown in the figure below). -
Page 288: Sinc
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the Gauss waveform (as shown in the figure below). For setting methods, refer to descriptions in "To Output Sine". -
Page 289: Exp.fall
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Figure 17-9 Haversine To Output the Arbitrary Waveform MSO5000 series oscilloscope allows you to define the arbitrary waveform and save it to the internal or external memory. The user-defined waveform can contain 1 to 16,384 data points (i.g. -
Page 290: Gauss
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL 2. Load the Waveform Press Load Stored to enter the waveform loading interface. In the disk management interface, select the waveform from the internal memory or the external memory. The waveform file is suffixed with "*.arb". Then, press Load to load the selected waveform. -
Page 291: Haversine
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL maximum number of editable points supported by the system is 16,384 (16 kpts). Linear interpolation Press Linear Interp to enable or disable the linear interpolation between the defined points of the waveform. -
Page 292: To Create The Waveform
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL To Edit Waveforms You can edit the waveforms in the current volatile memory. Press Edit to enter the waveform editing menu. Set the frequency or period First select Frequency or Period, then rotate the multifunction knob select "Frequency"... - Page 293 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Voltage Press Voltage, then rotate the multifunction knob or use the pop-up numeric keypad to set the voltage value of the current point. Its available range is from -2.5 V to +2.5 V.
-
Page 294: To Edit Waveforms
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL AM (Amplitude Modulation), namely the amplitude of the carrier waveform changes with the amplitude of the modulating waveform, as shown in the figure below. Modulating Signal Carrier Signal Modulated Waveform Figure 17-10 Amplitude Modulation 1. -
Page 295: Modulation
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL FM (Frequency Modulation), namely the frequency of the carrier waveform changes with that of the modulating waveform, as shown in the figure below. Modulating Signal Carrier Signal Modulating Waveform Figure 17-11 Frequency Modulation 1. - Page 296 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL been early used in information transmission. Its advantages lie in good performance in anti-noise and anti-attenuation, and it has been widely used in low and medium rate of data transmission. 1. Set the Modulation Polarity Press Polarity continuously to select "Positive"...
- Page 297 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL 2. Sweep Settings Press Settings to enter the sweep setting menu. Set start frequency and end frequency Start frequency and end frequency indicate the upper and lower limits of the sweep frequency. The Function/Arbitrary Waveform Generator always sweeps from the start frequency to the end frequency, and then returns back to the start frequency.
-
Page 298: Fsk
Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL When the sweep type is set to "Step", this menu is enabled and can be settable. Press Step number, then rotate the multifunction knob use the pop-up numeric keypad to set the step value. By default, it is 2. Its available range is from 2 to 1000. - Page 299 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL 1. Set the Burst Type Press Burst Type, and rotate the multifunction knob to select the desired burst type, and then press down the knob to select it. You can also press Burst Type continuously or enable the touch screen to select it.
- Page 300 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Press Burst Period, then rotate the multifunction knob or use the pop-up numeric keypad to set the desired burst period. Its available range is from 1 ms to 500 s. By default, it is 10 ms.
-
Page 301: Burst
Chapter 18 Store and Load RIGOL Chapter 18 Store and Load You can save the current settings, waveforms, screen image, and parameters of the oscilloscope in internal memory or external storage device (such as USB storage device) in various formats and load the stored settings or waveforms when needed. - Page 302 Chapter 18 Store and Load RIGOL Storage System Press Storage on the front panel to enter the store and load setting interface. It provides one USB HOST interfaces on the front panel and one USB HOST interface on the rear panel, which can all be connected to the USB storage device for external storage.
-
Page 303: Chapter 18 Store And Load
Chapter 18 Store and Load RIGOL 2. Wave Press Save Wave to enter the waveform storage setting interface. Save the main setting information (e.g. "On/Off" state of the channel, vertical scale, and horizontal time base) and waveform data of all enabled channels (analog channel and digital channel) to the external memory. -
Page 304: Storage System
Chapter 18 Store and Load RIGOL Press Load Wave to load the waveforms from the internal memory or the external USB disk. The default file type is "*.wfm", and no other options are available. Load the file from the memory, then press Load to load the selected file. -
Page 305: Load Type
Chapter 18 Store and Load RIGOL After saving the reference waveform, press Ref More Export to enter the disk management interface of reference waveform file storage. Press Utility PassFail to enable the pass/fail test function. Then press Mask ... -
Page 306: Internal Storage And Load
Chapter 18 Store and Load RIGOL External Storage and Load Before external storage and recall, ensure that the USB disk is properly connected. The external memory supports image saving, waveform saving, setup saving, waveform loading, and setup loading. 1. Save the Specified Type of File in the External USB Storage Device... - Page 307 Chapter 18 Store and Load RIGOL Figure 18-1 Disk Management Interface Execute the following operations through the disk management menu: To Select a File Type To Create a Folder To Delete a File or Folder To Copy and Paste a File or Folder ...
-
Page 308: External Storage And Load
Chapter 18 Store and Load RIGOL Figure 18-2 To Create a Folder This oscilloscope supports Chinese/English input method. The length of the folder name is limited to 10 bytes (one Chinese character occupies two bytes). The following part introduces how to input a folder name using Chinese/English input method. -
Page 309: To Select A File Type
Chapter 18 Store and Load RIGOL 1. Select English Input Method If the current input method is "En/中/繁", please go to Step 2. If the current input method is "中/繁/En" or "繁/En/中", rotate the multifunction knob select the input switch key and press the knob continuously to switch to "En/中/繁". - Page 310 Chapter 18 Store and Load RIGOL 6. After finishing the input, rotate the multifunction knob and press OK. The oscilloscope will create a folder or a specified type of file with this name under the current directory. Simplified Chinese (or Traditional Chinese) Input Method For example, create a folder with the name "文件名".
- Page 311 Chapter 18 Store and Load RIGOL then "文" is input in the "Name Input Area". If the Chinese character is not found in the current page, press to go to the next page until you find the desired character. 4. Input the Other Characters Refer to Step 3 and use the same method to input the remaining Chinese characters "件名"...
- Page 312 Chapter 18 Store and Load RIGOL Delete a File or Folder from the External Memory Press Storage Disk and rotate the multifunction knob to select the external memory. Press down the knob to open it. Rotate the multifunction knob to select the file or the folder to be deleted.
-
Page 313: To Delete A File Or Folder
Chapter 18 Store and Load RIGOL To Clear the Internal Memory Safely Press Storage Disk, rotate the multifunction knob to select the internal memory "Local Disk(C)". Press SecurityClear, and then a prompt message for confirming security clear is displayed. -
Page 314: To Copy And Paste A File Or Folder
Chapter 18 Store and Load RIGOL Channel Coupling BW Limit Attenuation Input Impedance 1 MΩ Invert Fine Channel Unit Display Label Ch-Ch Skew Offset Cal Acquire Acquisition Mode Normal Memory Depth Auto Anti-Aliasing Trigger Trigger Type Edge Trigger Source Selection... -
Page 315: To Clear The Internal Memory Safely
Chapter 18 Store and Load RIGOL Wave Sine Output Frequency 1 kHz Amplitude Offset Start Phase 0° Setting Type Impedance HighZ Cursor Mode Manual Select Source 100 mV -100 mV Vertical Unit Source Hori. Unit Region Main Track AX Source BX Source -1 μs... - Page 316 Chapter 18 Store and Load RIGOL Window Show Save Setup File Type *.stp Window Show Load Wave File Type *.wfm Load Setup File Type *.stp Disk File Type Utility Sound PassFail Enable Source Operate Stop Range Screen X Mask 0.24 div Y Mask 0.48 div...
- Page 317 Chapter 18 Store and Load RIGOL Current Jump To First Save First System Power On Default Power Status Switch On AUX Out TrigOut Key Locker Unlocked HDMI Output HDMI Resolution 1280x720 SelfCal Window Open Auto Config Peak to Peak Overlay...
- Page 318 Chapter 18 Store and Load RIGOL Operation SourceA SourceB Offset Scale 10 uV A× B Operation SourceA SourceB Offset Scale 500 uU Operation SourceA SourceB Offset Scale 500 mU Operation Source Offset 0 dB Scale 1 dB Unit dB/dBV Start-End...
- Page 319 Chapter 18 Store and Load RIGOL A||B Operation SourceA SourceB Wave Size Medium Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Sensitivity 0.3 Div Operation SourceA SourceB Wave Size Medium Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Sensitivity 0.3 Div Operation SourceA Wave Size Medium Thre.CH1 Thre.CH2 Thre.CH3...
- Page 320 Chapter 18 Store and Load RIGOL Operation Source Offset Scale 100 mU Invert Operation Source Offset Scale Invert Operation Source Offset Scale Invert Operation Source Offset Scale Invert Operation Source Offset Scale 20 mV Invert Low Pass Operation Source Offset...
- Page 321 Chapter 18 Store and Load RIGOL Operation Source Offset Scale 20 mV ωc1 6.25 MHz ωc1 12.5 MHz Invert Band Stop Operation Source Offset Scale 20 mV ωc1 6.25 MHz ωc1 12.5 MHz Invert AX+B Operation Source Offset Scale 20 mV...
- Page 322 Chapter 18 Store and Load RIGOL Clock RS232 Bus Status Baud 9.6 kbps Threshold Polarity Endian Data 8 bits Stop Bit 1 bit Parity None Package Separator 0(NUT) Bus Status Clock SCL Thre SDA Thre Exchange SCL/SDA Without Bus Status...
- Page 323 Chapter 18 Store and Load RIGOL Source Threshold Signal CAN_L Baud 1 Mbps Sample Position FlexRay Bus Status Source Threshold Channel Selection Baud 10 Mbps Signal Sample Position Bus Status SCLK SCLK Thre SCLK Edge Rising SCLK Thre Data Data Thre...
- Page 324 Chapter 18 Store and Load RIGOL Note : It is only available for the model installed with the MSO5000-AWG option. Note : PLA2216 active logic probe option is required to be ordered. 18-24 MSO5000 User's Guide GlobalTestSupply www. .com nd Quality Products Online at:...
- Page 325 Chapter 19 System Utility Function Setting RIGOL Chapter 19 System Utility Function Setting In the system function setting menu, you can set the parameters for the remote interface and the system-related parameters. Contents in this chapter: Remote Interface Configuration ...
- Page 326 Remote Interface Configuration MSO5000 series can communicate with the PC via the USB, LAN, or GPIB (requiring to work with RIGOL's USB-GPIB interface converter) interface. Before using the remote interfaces, configure the corresponding interface according to the introductions in the following section.
-
Page 327: Chapter 19 System Utility Function Setting
Chapter 19 System Utility Function Setting RIGOL Invalid IP! IP lost! Please wait... IP Configuration Type The configuration type of the IP address can be DHCP, Auto IP, or Static IP. For different IP configuration types, the configurations for IP address and other network parameters are different. -
Page 328: Remote Interface Configuration
Chapter 19 System Utility Function Setting RIGOL input the desired IP address. This setting will be saved to the non-volatile memory; if "Power On" is set to "Last", then DHCP and Auto IP are disabled at the next power-on. The oscilloscope will load the preset IP address automatically. - Page 329 Chapter 19 System Utility Function Setting RIGOL When the three IP configuration types are all turned on, the priority of the parameter configuration from high to low is "DHCP", "Auto IP", and "Static IP". The three IP configuration types cannot be all turned off at the same time.
- Page 330 Chapter 19 System Utility Function Setting RIGOL To Set the GPIB Address Before using the GPIB bus to control the oscilloscope, use the USB-GPIB interface converter (an option that requires to be ordered separately) to extend the GPIB interface, and then use the GPIB cable to connect the instrument to the PC. Press Utility ...
-
Page 331: To Set Mdns
Chapter 19 System Utility Function Setting RIGOL System-related Beeper When the beeper is enabled, you can hear the sound of the beeper when you perform the following operations: Press a key or a menu key on the front panel ... -
Page 332: To Set The Gpib Address
Chapter 19 System Utility Function Setting RIGOL Aux Output You can set the type of the signal output from the [TRIG OUT] connector on the rear panel. Press Utility System, and then press the AUX Out key continuously to select "TrigOut"... -
Page 333: System-Related
Chapter 19 System Utility Function Setting RIGOL Self-calibration The self-calibration program can quickly make the oscilloscope to work in an optimal state to get the precise measurement results. You can perform self-calibration at any time, especially when the changes of the ambient temperature reach or above 5℃. -
Page 334: Aux Output
Chapter 19 System Utility Function Setting RIGOL For detailed settings, refer to descriptions in "Quick Measurement after AUTO". Print Setting Connect the oscilloscope to the local area network via the network cable. The MSO5000 series supports printing the whole screen to the USB printer or network printer. -
Page 335: Self-Calibration
Chapter 19 System Utility Function Setting RIGOL operation. Copies Press Copies, then rotate the multifunction knob to set the number of copies to be printed or use the pop-up numeric keypad to set it. The settable range is from 1 to 99. -
Page 336: Print Setting
Chapter 19 System Utility Function Setting RIGOL is from 0 65535. Set the user name Press UserName to set the user name of the server. For detailed setting methods for the user name, refer to descriptions in "To Create a Folder". -
Page 337: Email
Chapter 19 System Utility Function Setting RIGOL Quick Operation You can set the shortcut functions for the Quick key on the front panel. Press Utility More Quick settings to enter the quick key setting menu. You can also enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. -
Page 338: Key Locker
Chapter 19 System Utility Function Setting RIGOL Press Data Source continuously to select "Memory" or "Screen" as the source of the saved waveform. Format Press Format and then rotate the multifunction knob to select the waveform format. Press down the knob to select it. You can also press Format continuously to select or enable the touch screen to tap the format. -
Page 339: Quick Operation
Chapter 19 System Utility Function Setting RIGOL Operation Type Press Operation and then rotate the multifunction knob to select "Stat Reset". Press down the knob to select it. You can also press Operation continuously to select among the options, or enable the touch screen to tap the desired operation type. - Page 340 Chapter 19 System Utility Function Setting RIGOL Group". Press down the knob to select it. You can also press Operation continuously to select among the options, or enable the touch screen to tap the desired operation type. Set the Group parameter: press Group and then rotate the multifunction knob to select "Save Image", "Save Wave", or "Save Setup".
- Page 341 The press SINGLE to switch to the next touch screen test interface, as shown in the figure below. At this time, you can pinch or stretch the RIGOL logo on the screen to zoom it out or in to check whether the gestures work normally.
-
Page 342: Self-Check
Chapter 19 System Utility Function Setting RIGOL (4) Set "day": Press Day, rotate the multifunction knob directly to set it or use the pop-up numeric keypad to input the numeric value to set it. (5) Set "Hour": Press Hour, rotate the multifunction knob directly to set it or use the pop-up numeric keypad to input the numeric value to set it. -
Page 343: System Time
Remote Control via LAN Remote Control via GPIB This chapter will illustrate how to use RIGOL's Ultra Sigma software to remotely control the oscilloscope via various interfaces. CAUTION Before setting up communication, please turn off the instrument to avoid causing damage to the communication interfaces. - Page 344 Chapter 20 Remote Control RIGOL Remote Control via USB 1. Connect the device Use a USB cable to connect the oscilloscope (USB DEVICE interface) with the PC (USB HOST interface). 2. Install the USB driver This oscilloscope is a USB-TMC device. After you connect the oscilloscope to the PC properly and power it on for the first time (the oscilloscope will be automatically configured with the USB interface).
-
Page 345: Chapter 20 Remote Control
Chapter 20 Remote Control RIGOL MSO5000 User's Guide 20-3 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co... -
Page 346: Remote Control Via Usb
PC via the USB interface. You can also click to search for the resource. 4. View the device resource The searched instrument resource will be under the directory of "RIGOL Online Resource", with the model of the instrument and the USB interface information being displayed as follows. - Page 347 Chapter 20 Remote Control RIGOL 5. Control the instrument remotely Right-click the resource name "MSO5354 (USB0::0x1AB1::0x3514::MSO53541234567890::INSTR)" and select "SCPI Panel Control" to turn on the remote command control panel, through which you can send commands and read data. MSO5000 User's Guide...
- Page 348 Click to add it. 4. View the device resource The resources found will appear under the "RIGOL Online Resource" directory. For example, MSO5354 (TCPIP::172.16.3.14::INSTR). 5. Control the instrument remotely Right-click the resource name "MSO5354 (TCPIP::172.16.3.14::INSTR)" and select "SCPI Panel Control"...
- Page 349 Chapter 20 Remote Control RIGOL Remote Control via GPIB 1. Connect the device Use the USB-GPIB interface converter to extend the GPIB interface for the oscilloscope, and then use the GPIB cable to connect the oscilloscope to the PC to realize remote control.
-
Page 350: Remote Control Via Lan
5. View the device resource The searched instrument resource will be under the directory of "RIGOL Online Resource", as shown in the following figure. 6. Control the instrument remotely Right-click the resource name "MSO5354 (GPIB0::18::INSTR)", and select "SCPI... -
Page 351: Remote Control Via Gpib
The commonly encountered failures of the oscilloscope and their solutions are listed below. If the following problems occur, locate and resolve the problems according to the following steps. If the problems still persist, contact RIGOL and provide your instrument information to us. - Page 352 (3) Check whether there is a strong magnetic field around the instrument. If the instrument is close to the strong magnetic field (e.g. a magnet), please move the instrument away from the magnet field. (4) If the problem still persists, please contact RIGOL. 21-2 MSO5000 User's Guide GlobalTestSupply www.
-
Page 353: Chapter 21 Troubleshooting
Chapter 22 Appendix RIGOL Chapter 22 Appendix Appendix A: Accessories and Options Order Information Order No. Model MSO5354 (350 MHz, 8 GSa/s, 200 Mpts, 4+16 CH MSO) MSO5354 MSO5204 (200 MHz, 8 GSa/s, 200 Mpts, 4+16 CH MSO) MSO5204 MSO5104 (100 MHz, 8 GSa/s, 200 Mpts, 4+16 CH MSO) - Page 354 Measurement Application Option Dual-channel 25 MHz Arbitrary Waveform Generator MSO5000-AWG Built-in Power Analysis MSO5000-PWR Note: For all the mainframes, accessories, and options, please contact the local office of RIGOL. 22-2 MSO5000 User's Guide GlobalTestSupply www. .com nd Quality Products Online at:...
-
Page 355: Chapter 22 Appendix
If a product proves defective within the warranty period, RIGOL guarantees free replacement or repair for the defective product. To get repair service, please contact with your nearest RIGOL sales or service office. There is no other warranty, expressed or implied, except such as is expressly set forth herein or other applicable warranty card. - Page 356 GlobalTestSupply www. .com nd Quality Products Online at: sales@GlobalTestSupply.co...
-
Page 357: Appendix B: Warranty
Index RIGOL Index +Duty ........6-29 Hanning ........6-9 +Rate ........6-33 Haversine ......... 17-9 +Width ........6-28 Horizontal Expansion ....4-10 Acquisition Mode ......4-5 Horizontal Position ...... 3-3 AM ........17-14 I2C Decoding ......11-14 Anti-Aliasing ......4-10 I2C Trigger ....... - Page 358 Index RIGOL Pulse Width Setting....5-10 Trigger LEVEL/Threshold Level ..5-3 Qualifier ........5-22 Trigger Mode ......5-4 Ramp ........17-4 Trigger Position ......5-24 -Rate ........6-33 tVmax ........6-29 Rectangular ....... 6-9 tVmin ........6-29 Rise Time ........ 6-28 Vamp ......
Need help?
Do you have a question about the MS05000-4CH and is the answer not in the manual?
Questions and answers
