User Guide
MSO5000 Series Digital
Oscilloscope
May. 2020
RIGOL TECHNOLOGIES CO., LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MSO5072 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rigol MSO5072

Summary of Contents for Rigol MSO5072

  • Page 1 User Guide MSO5000 Series Digital Oscilloscope May. 2020 RIGOL TECHNOLOGIES CO., LTD.

  • Page 3: Guaranty And Declaration

    Notices RIGOL products are covered by P.R.C. and foreign patents, issued and pending. ⚫ RIGOL reserves the right to modify or change parts of or all the specifications ⚫ and pricing policies at the company’s sole decision. Information in this publication replaces all previously released materials.

  • Page 4: Safety Requirement

    RIGOL Safety Requirement General Safety Summary Please review the following safety precautions carefully before putting the instrument into operation so as to avoid any personal injury or damage to the instrument and any product connected to it. To prevent potential hazards, please follow the instructions specified in this manual to use the instrument properly.
  • Page 5 Do Not Operate with Suspected Failures. If you suspect that any damage may occur to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel.

  • Page 6: Safety Notices And Symbols

    RIGOL Safety Notices and Symbols Safety Notices in this Manual: WARNING Indicates a potentially hazardous situation or practice which, if not avoided, will result in serious injury or death. CAUTION Indicates a potentially hazardous situation or practice which, if not avoided, could result in damage to the product or loss of important data.

  • Page 7: Measurement Category

    RIGOL Measurement Category Measurement Category MSO5000 series digital oscilloscopes can make measurements in Measurement Category I. WARNING This oscilloscope can only be used for measurements within its specified measurement categories. Measurement Category Definitions Measurement category I is for measurements performed on circuits not directly connected to MAINS.

  • Page 8: Working Environment

    RIGOL Working Environment Temperature Operating: 0℃ to +50℃ Non-operating: -30℃ to +70℃ Humidity Operating: Below +30℃: ≤95%RH (without condensation) +30℃ to +40℃: ≤75%RH (without condensation) +40℃ to +50℃: ≤45%RH (without condensation) Non-operating: Below 65℃: ≤95% RH (without condensation) WARNING To avoid short circuit inside the instrument or electric shock, never operate the instrument in a humid environment.

  • Page 9: Care And Cleaning

    RIGOL Pollution Degree 1: No pollution or only dry, nonconductive pollution occurs. The pollution has no effect. For example, a clean room or air-conditioned office environment. Pollution Degree 2: Normally only nonconductive pollution occurs. Temporary conductivity caused by condensation is to be expected. For example, indoor environment.

  • Page 10: Environmental Considerations

    RIGOL Environmental Considerations The following symbol indicates that this product complies with the WEEE Directive 2002/96/EC. Product End-of-Life Handling The equipment may contain substances that could be harmful to the environment or human health. To avoid the release of such substances into the environment and avoid harm to human health, we recommend you to recycle this product appropriately to ensure that most materials are reused or recycled properly.

  • Page 11: Mso5000 Series Overview

    MSO5000 Series Overview MSO5000 series digital oscilloscope is a high-performance oscilloscope model designed based on RIGOL UltraVision II technology. With a 9-inch capacitive multi-touch screen, the MSO5000 series integrates 7 independent instruments into one, delivering super sample bandwidth ratio, extremely high memory depth, and other excellent specifications.

  • Page 12: Document Overview

    RIGOL Document Overview Main Topics of this Manual: Chapter 1 Quick Start Introduces the preparations before using the oscilloscope and provides a basic introduction of the instrument. Chapter 2 To Set the Vertical System Introduces the vertical system functions of the oscilloscope.
  • Page 13 RIGOL Chapter 14 Waveform Recording & Playing Introduces the waveform recording & playing function. Chapter 15 Search and Navigation Function Introduces the navigation function and how to quickly search the relevant events. Chapter 16 Display Control Introduces how to control the display of the oscilloscope.
  • Page 14 No. of No. of No. of Analog Function/Arbitrary Model Analog Digital Bandwidth Waveform Channels Channels Generator Channels MSO5072 70 MHz 2, Opt. MSO5074 70 MHz 2, Opt. MSO5102 100 MHz 2, Opt. MSO5104 100 MHz 2, Opt. MSO5204 200 MHz 2, Opt.
  • Page 15 RIGOL Manuals of this Product: Quick Guide, User Guide, Programming Guide, Data sheet, etc. For the latest version of this manual, download it from the official website of RIGOL (www.rigol.com). MSO5000 User Guide XIII...

  • Page 16: Table Of Contents

    Contents RIGOL Contents Guaranty and Declaration ................. I Safety Requirement ................. II General Safety Summary................II Safety Notices and Symbols ..............IV Measurement Category ................V Ventilation Requirement ................V Working Environment ................VI Care and Cleaning .................. VII Environmental Considerations ..............VIII MSO5000 Series Overview ..............
  • Page 17 Contents RIGOL Pinch & Stretch ................1-23 Drag ..................... 1-24 Rectangle Drawing ................. 1-24 Parameter Setting Method ..............1-26 To Use the Kensington Security Lock ............1-27 To Use the Built-in Help System ............. 1-28 To View the Option Information and the Option Installation ...... 1-29 Chapter 2 To Set the Vertical System ..........
  • Page 18 Contents RIGOL Trigger LEVEL/Threshold Level ..............5-3 Trigger Mode ..................5-4 Trigger Coupling..................5-5 Trigger Holdoff ..................5-6 Noise Rejection ..................5-7 Trigger Type ..................5-8 Edge Trigger ................... 5-9 Pulse Trigger ................. 5-10 Slope Trigger ................. 5-12 Video Trigger................. 5-15 Pattern Trigger ................
  • Page 19 Contents RIGOL Abs ....................6-20 Low Pass ..................6-21 High Pass ..................6-22 Band Pass ..................6-23 Band Stop ..................6-24 AX+B .................... 6-25 Math Operation Label ..............6-26 Auto Measurement ................6-27 Quick Measurement after AUTO............6-27 Measurement Parameter ..............6-30 Measurement Settings ..............
  • Page 20 Contents RIGOL To Select the Digital Channel ..............10-2 To Enable/Disable the Digital Channel ............ 10-2 To Set the Threshold and Calibrate Probe ..........10-3 Auto Arrangement Setting ..............10-4 To Set the Waveform Display Size ............10-4 To Set the Label ................... 10-4 Group Setting ..................
  • Page 21 Contents RIGOL Play Options ..................14-4 Chapter 15 Search and Navigation Function ........15-1 Search Function ................... 15-2 Navigation Function ................15-4 Chapter 16 Display Control ............... 16-1 To Select the Display Type ..............16-2 To Set the Persistence Time ..............16-2 To Set the Waveform Intensity ...............
  • Page 22 Contents RIGOL Disk Management ................18-6 To Select a File Type ..............18-7 To Create a Folder ................. 18-7 To Delete a File or Folder .............. 18-11 To Copy and Paste a File or Folder ..........18-12 To Rename a File or Folder ............18-12 To Clear the Internal Memory Safely ..........
  • Page 23 Contents RIGOL Self-calibration ................20-9 Auto Config ................... 20-9 Print Setting ................20-10 Email ..................20-11 Key Locker .................. 20-12 Quick Operation ................20-13 Screen Saver ................20-16 Self-check ................... 20-17 System Time ................20-18 Chapter 21 Remote Control .............. 21-1 Remote Control via USB ................

  • Page 25: Chapter 1 Quick Start

    Chapter 1 Quick Start RIGOL Chapter 1 Quick Start This chapter introduces the precautions when using the oscilloscope for the first time, the front/rear panels of the oscilloscope, the user interface, touch screen controls, and how to use the built-in help system.

  • Page 26: General Inspection

    The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2． Inspect the instrument In case of any mechanical damage, missing parts, or failure in passing the electrical and mechanical tests, contact your RIGOL sales representative.

  • Page 27: Appearance And Dimensions

    Chapter 1 Quick Start RIGOL Appearance and Dimensions Figure 1-1 Front View Unit: mm Figure 1-2 Vertical View Unit: mm MSO5000 User Guide...

  • Page 28: To Prepare For Use

    Chapter 1 Quick Start RIGOL To Prepare for Use To Adjust the Supporting Legs You can unfold the supporting legs to use them as stands to tilt the instrument upwards for easier operation and observation, as shown in Figure 1-3. You can also fold the supporting legs for easier storage or shipment when the instrument is not in use.

  • Page 29: Turn-On Checkout

    After the self-test, the welcome screen is displayed. To Connect the Probe RIGOL provides the passive probe and the logic probe for MSO5000 series. For MSO5000 Series Datasheet specific probe models, please refer to .
  • Page 30 Chapter 1 Quick Start RIGOL 2. Connect the output terminal of the logic probe to the digital channel input terminal on the front panel of the oscilloscope in the correct direction, as shown in Figure 1-6. Figure 1-6 To Connect the Logic Probe 3.
  • Page 31 Chapter 1 Quick Start RIGOL (b) Incorrect Connection of the Ground Lead Figure 1-7 Ground Lead Connection 5. Repeat the above steps to connect all digital signals. Note: The digital channel input terminal does not support hot plugging. Please do not ⚫...

  • Page 32: Function Inspection

    Chapter 1 Quick Start RIGOL Function Inspection Press Default on the front panel, then a prompt message "Restore default settings?" is displayed. Press OK or tap OK to restore the instrument to its factory default settings. Connect the ground alligator clip of the probe to the "Ground Terminal" as shown in Figure 1-8 below.

  • Page 33: Probe Compensation

    Chapter 1 Quick Start RIGOL WARNING To avoid electric shock when using the probe, please make sure that the insulated wire of the probe is in good condition. Do not touch the metallic part of the probe when the probe is connected to high voltage source.

  • Page 34: Front Panel Overview

    Chapter 1 Quick Start RIGOL Front Panel Overview 9 10 Figure 1-11 Front Panel Table 1-1 Front Panel Description Description Description Capacitive Touch Screen Default Setting Key Function Menu Operation Keys Trigger Control System Dual-channel Function/Arbitrary Waveform Generator Setting Horizontal Control System...

  • Page 35: Rear Panel Overview

    Chapter 1 Quick Start RIGOL Rear Panel Overview Figure 1-12 Rear Panel 1. Handle Rotate the handle upright to carry the instrument easily. Rotate it downward if you do not need to carry it. 2. HDMI Through this interface, you can connect the instrument to an external display equipped with the HDMI interface (e.g.
  • Page 36 Press Online upgrade or enable the touch screen to tap "Online upgrade", then a "System Update Information" window is displayed, requesting you whether to accept or cancel "RIGOL PRODUCT ONLINE UPGRADE SERVICE TERMS". Tap "Accept" to start online upgrade. Tap "Cancel"...

  • Page 37: Front Panel Function Overview

    Chapter 1 Quick Start RIGOL Front Panel Function Overview Vertical 1, 2, 3, 4: indicates the analog channel switch key. The four channels are ⚫ marked by different colors which are also used to mark both the corresponding waveforms of the specified channel on the screen and the channel input connectors.

  • Page 38: Horizontal

    Chapter 1 Quick Start RIGOL Each analog channel is configured with an independent vertical offset adjustment knob. Turn it clockwise to increase the offset, and turn it counterclockwise to decrease the offset. During the modification, the waveform would move up and down. Meanwhile, the offset information in the corresponding status label would change accordingly.

  • Page 39: Trigger

    Chapter 1 Quick Start RIGOL Horizontal SCALE: indicates the horizontal time base knob. You can rotate ⚫ the knob to modify the horizontal time base. Turn it clockwise to decrease the time base, and turn it counterclockwise to increase the time base. During the modification, waveforms of all the channels will be displayed in expanded or compressed form, and the time base message (e.g.

  • Page 40: Navigation Control Key

    Chapter 1 Quick Start RIGOL analysis function, and etc. You can make a quick measurement for 41 waveform parameters. Acquire: Press this key to enter the acquisition setting menu. You can set the time base mode, the acquisition mode, memory depth, and etc.

  • Page 41: Function/Arbitrary Waveform Generator Setting

    Chapter 1 Quick Start RIGOL Function/Arbitrary Waveform Generator Setting Press GI to enable or disable the output of the [GI] connector on the front panel; press GII to enable or disable the output of the [GII] connector on the front panel; and then enter the corresponding Function/Arbitrary Waveform Generator setting interface.

  • Page 42: Touch Lock Key

    Chapter 1 Quick Start RIGOL Touch Lock Key Press this key to disable the touch screen function. Note: By default, the touch screen function of the oscilloscope is always enabled. If you disable the function, press the key again to enable it.

  • Page 43: User Interface

    Chapter 1 Quick Start RIGOL User Interface MSO5000 series has a 9-inch WSVGA (1024× 600) LCD, with 256 level gray-scale display. The user interface displays the acquired waveforms, the setting information, and the measurement results. 5 6 7 10 11 12...
  • Page 44 Chapter 1 Quick Start RIGOL 3. Horizontal Time Base Represents the time length per grid in the horizontal axis of the screen. ⚫ Use Horizontal SCALE to modify this parameter. The adjustable range ⚫ of the horizontal time base is different for different models.
  • Page 45 Chapter 1 Quick Start RIGOL 12. Trigger LEVEL/Threshold Level When CH1-CH4 is selected as the trigger source, you need to set a proper ⚫ trigger level. When D0-D15 is selected as the trigger source, you need to set a proper ⚫...
  • Page 46 Chapter 1 Quick Start RIGOL channel is highlighted in red. The digital channels turned off are displayed in gray. 18. CH4 Status Label Displays the status of CH4. ⚫ Displays the vertical scale of CH4. That is, the voltage value per grid of CH4 ⚫...

  • Page 47: Touch Screen Controls

    Chapter 1 Quick Start RIGOL 24. Function Navigation Enable the touch screen and then tap this icon to enable the function navigation. Touch Screen Controls MSO5000 series provides a 9-inch super large capacitive touch screen, which supports multi-touch and gesture operation. It has strong waveform display capability and excellent user experience.

  • Page 48: Drag

    Chapter 1 Quick Start RIGOL Pinching & stretching in the horizontal direction can adjust the horizontal time ⚫ base of the waveform. Pinching & stretching in the vertical direction can adjust the vertical scale of the ⚫ waveform. Figure 1-15 Pinch & Stretch Gesture...
  • Page 49 Chapter 1 Quick Start RIGOL Figure 1-17 Rectangle Drawing Gesture Select "Trigger zone A": ⚫ Draw the region for Trigger zone A; ➢ Open Trigger zone A; ➢ Open the "Zone Trigger" menu. ➢ Select "Trigger zone B": ⚫ Draw the region for Trigger zone B;...

  • Page 50: Parameter Setting Method

    Chapter 1 Quick Start RIGOL Parameter Setting Method You can use the knob or enable the touch screen to set the parameters of MSO5000 series. The common parameter setting methods are as follows: Method 1: For the parameters with the sign...

  • Page 51: To Use The Kensington Security Lock

    Chapter 1 Quick Start RIGOL Method 4: For the parameters without the above signs, press the desired menu softkey to switch between the parameter items. This method is applicable to the parameters with only two available options. The above method is commonly used for the parameter settings of the oscilloscope.

  • Page 52: To Use The Built-In Help System

    Chapter 1 Quick Start RIGOL To Use the Built-in Help System The help system of this oscilloscope provides instructions for all the function keys on the front panel and their corresponding menu keys. The steps for opening the built-in help system are as follows: Press Utility →...

  • Page 53: To View The Option Information And The Option Installation

    Chapter 1 Quick Start RIGOL options to get the corresponding help information. Method 3: Enable the touch screen and tap the desired help option to get the corresponding help information. Help information for other keys and buttons: ⚫ Power key : powers on/off the instrument.
  • Page 54 Then, you can install the option according to the following steps. 1) Obtain an option license (1) Log in to the RIGOL official website (www.rigol.com), click License Activation to enter the "Registered product license code" interface. (2) In the software license registration interface, input the correct key, serial number (press Utility →...

  • Page 55: Chapter 2 To Set The Vertical System

    Chapter 2 To Set the Vertical System RIGOL Chapter 2 To Set the Vertical System MSO5000 series provides two (CH1-CH2, available to be upgraded to 4 channels when installed with the MSO5000-4CH option) or four analog input channels (CH1-CH4), and each channel is equipped with an independent vertical control system.

  • Page 56: To Enable Or Disable The Analog Channel

    Chapter 2 To Set the Vertical System RIGOL To Enable or Disable the Analog Channel Enable the analog channel: Connect a signal to the channel connector of CH1, and then press 1 in the vertical control area (Vertical) on the front panel to enable CH1. Then, the backlight of the channel is illuminated.

  • Page 57: To Adjust The Vertical Scale

    Chapter 2 To Set the Vertical System RIGOL To Adjust the Vertical Scale Vertical scale indicates the voltage value per grid in the vertical axis of the screen. It is often expressed in V/div. While you adjust the vertical scale, the display amplitude of the waveform would enlarge or reduce.

  • Page 58: Vertical Expansion

    Chapter 2 To Set the Vertical System RIGOL Vertical Expansion When changing the vertical scale of the analog channel by rotating the Vertical SCALE knob, you can select to expand or compress the waveform around the "Center" or "GND" (Ground). By default, "GND" is selected under Expand.

  • Page 59: Channel Coupling

    Chapter 2 To Set the Vertical System RIGOL Value Input Field Decrease Increase Channel Coupling The undesired signals can be filtered out by setting the coupling mode. For example, the signal under test is a square waveform with DC offset.

  • Page 60: Probe Ratio

    Table 2-1. Table 2-1 Bandwidth Limit Bandwidth of the Oscilloscope Model Available Bandwidth Limit 70 M and 100 M 20 M (MSO5072/MSO5074/MSO5102/MSO5104) 200 M (MSO5204) 20 M, 100 M 350 M (MSO5354) 20 M, 100 M, 200 M Note: Bandwidth limit can not only reduce the noise, but also can attenuate or eliminate the high frequency components of the signal.

  • Page 61: Input Impedance

    Chapter 2 To Set the Vertical System RIGOL 0.2X 0.2:1 0.5X 0.5:1 1X (default) 10:1 20:1 50:1 100X 100:1 200X 200:1 500X 500:1 1000X 1000:1 2000X 2000:1 5000X 5000:1 10000X 10000:1 20000X 20000:1 50000X 50000:1 Input Impedance To reduce the circuit load between the oscilloscope and the circuit under test, this oscilloscope provides the default 1 MΩ...

  • Page 62: Amplitude Unit

    Chapter 2 To Set the Vertical System RIGOL (a) "Invert" Off (b) "Invert" On Figure 2-1 Waveform Invert Note: When the waveform invert is enabled, the trigger edge or the trigger polarity will change (e.g. Edge trigger, Pulse trigger, or Slope trigger).

  • Page 63: Offset Cal

    Chapter 2 To Set the Vertical System RIGOL Figure 2-2 Zero Offset Press 1 → More → Ch-Ch Skew, rotate the multifunction knob or use the numeric keypad to set the desired delay calibration time. The available range of the delay calibration time is from -100 ns to 100 ns.

  • Page 64: Channel Label

    Chapter 2 To Set the Vertical System RIGOL Channel Label The instrument uses the channel number to mark the corresponding channel by default. For ease of use, you can also set a label for each channel. For example, " ".
  • Page 65 Chapter 2 To Set the Vertical System RIGOL Rotate the multifunction knob : use the delete key to delete or modify the ⚫ characters. To modify the characters, input the desired characters again. Enable the touch screen: use the touch gestures to directly move the cursor to ⚫...

  • Page 67: Chapter 3 To Set The Horizontal System

    Chapter 3 To Set the Horizontal System RIGOL Chapter 3 To Set the Horizontal System Contents in this chapter: To Adjust the Horizontal Time Base ◼ To Adjust the Horizontal Position ◼ Delayed Sweep ◼ MSO5000 User Guide...

  • Page 68: To Adjust The Horizontal Time Base

    Chapter 3 To Set the Horizontal System RIGOL To Adjust the Horizontal Time Base Horizontal time base, also called the horizontal scale, refers to the time of each grid in the horizontal direction of the screen. It is usually expressed in s/div. The adjustable range of the horizontal time base is related to the model type.

  • Page 69: To Adjust The Horizontal Position

    Chapter 3 To Set the Horizontal System RIGOL base, and counterclockwise to increase the horizontal time base. Note: When the delayed sweep is enabled, rotate the Horizontal SCALE knob to adjust the time base for the delayed sweep. The delayed sweep time base displayed in the center of the screen will be changed accordingly, as shown in the following figure.

  • Page 70: Delayed Sweep

    Chapter 3 To Set the Horizontal System RIGOL Note: When the delayed sweep is enabled, rotate the Horizontal POSITION knob to adjust the horizontal position of the delayed sweep (press down the knob to quickly reset it). The horizontal position of the delayed sweep at the upper-right corner of the screen changes accordingly.
  • Page 71 Chapter 3 To Set the Horizontal System RIGOL Waveform before enlargement: The waveform in the area that is not covered by subtransparent blue in the upper part of the screen is the waveform before enlargement. Its horizontal time base (also called main time base) is displayed at the upper-left corner of the screen.

  • Page 73: Chapter 4 To Set The Sample System

    Chapter 4 To Set the Sample System RIGOL Chapter 4 To Set the Sample System Contents in this chapter: Timebase Mode ◼ Acquisition Mode ◼ Sampling Mode ◼ Sample Rate ◼ LA Sample Rate ◼ Memory Depth ◼ LA Memory Depth ◼...

  • Page 74: Timebase Mode

    Chapter 4 To Set the Sample System RIGOL Timebase Mode MSO5000 series supports three available time base modes: YT mode, XY mode, and ROLL mode. By default, the time base mode is YT. Press Acquire → Timebase Mode on the front panel, and then rotate the multifunction knob to select the desired time base mode.
  • Page 75 Chapter 4 To Set the Sample System RIGOL According to sin=A/B or C/D,  is the phase deviation angle between the two channels. The definitions of A, B, C, and D are shown in the above figure. The phase deviation angle is obtained, that is: =arcsin(A/B) or arcsin(C/D)

  • Page 76: Roll Mode

    Chapter 4 To Set the Sample System RIGOL Note: In XY mode, CH1 and CH2 are forced to be enabled; CH3 and CH4 are forced to ⚫ be disabled. The maximum sample rate in XY mode is 2 GSa/s. Generally, a longer sample waveform can ensure better display effect of Lissajous figure.

  • Page 77: Acquisition Mode

    Chapter 4 To Set the Sample System RIGOL Acquisition Mode The acquisition mode is used to control how to generate waveform points from the sample points. MSO5000 supports the following four acquisition modes: Normal, Average, Peak, and High Resolution. By default, the acquisition mode is Normal.

  • Page 78: Peak

    Chapter 4 To Set the Sample System RIGOL Figure 4-2 Waveforms before Averaging Figure 4-3 Waveforms after 128 Times of Averaging Peak In this mode, the oscilloscope acquires the maximum and minimum values of the signal within the sample interval to get the envelope of the signal or the narrow pulse that might be lost.

  • Page 79: High Resolution

    Chapter 4 To Set the Sample System RIGOL High Resolution This mode uses an over-sample technique to average the neighboring points of the sample waveform. This reduces the random noise on the input signal, generates a much smoother waveform on the screen and improves the vertical resolution. This is generally used when the sample rate of the digital converter is greater than the storage rate of the acquisition memory.
  • Page 80 Chapter 4 To Set the Sample System RIGOL Single-channel mode: only one of the four channels (CH1/CH2/CH3/CH4) is enabled. Half-channel mode: either CH1 or CH2 is enabled; and either CH3 or CH4 is enabled. All-channel mode: CH1/CH2 are both enabled or CH3/CH4 are both enabled.

  • Page 81: La Sample Rate

    Chapter 4 To Set the Sample System RIGOL Pulse disappeared LA Sample Rate LA sampling is the process of sampling on the compared digital signals at a certain time interval. LA sample rate is the reciprocal of the time interval. For example, if the LA sample rate is 500 MSa/s, it indicates that the oscilloscope will make data acquisition on the digital signals at an interval of 2 ns.

  • Page 82: La Memory Depth

    Chapter 4 To Set the Sample System RIGOL Trigger Point Pre-sample Delayed Sample Memory Depth Figure 4-4 Memory Depth The following equation shows the relations among memory depth, sample rate, and horizontal time base scale:   MDepth SRate TScale HDivs ——indicates the memory depth.

  • Page 83: Anti-Aliasing

    Chapter 4 To Set the Sample System RIGOL the analog channel, and cannot be set separately. The maximum LA memory depth is 25 Mpts. Anti-Aliasing At a slower sweep speed, the sample rate is reduced, and a dedicated display algorithm can be used to minimize the possibility of aliasing.
  • Page 84 Chapter 4 To Set the Sample System RIGOL it is the screen center. Pressing down the multifunction knob can quickly reset the user-defined reference position to 0. Note: This function is unavailable in YT mode with the delayed sweep being enabled, XY mode, and ROLL mode.

  • Page 85: Chapter 5 To Trigger The Oscilloscope

    Chapter 5 To Trigger the Oscilloscope RIGOL Chapter 5 To Trigger the Oscilloscope As for trigger, you set certain trigger condition according to the requirement and when a waveform in the waveform stream meets this condition, the oscilloscope captures this waveform as well as the neighboring part, and displays them on the screen.

  • Page 86: Trigger Source

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Source In the trigger control area (Trigger) on the front panel, press Menu → Source to select the desired source, or rotate the multi-function knob to select a desired source, then press down the knob to select it. You can also press Source continuously to select the trigger source or enable the touch screen to tap the desired trigger source and select it.

  • Page 87: Trigger Level/Threshold Level

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger LEVEL/Threshold Level The adjustment of the trigger level/threshold level is related to the type of the trigger source. When the trigger source is selected from CH1 to CH4, rotate the Trigger ⚫...

  • Page 88: Trigger Mode

    Chapter 5 To Trigger the Oscilloscope RIGOL input a specific value with the displayed numeric keypad. Level Input Field Decrease the level Increase the level Trigger Mode The following is the schematic diagram of the acquisition memory. To easily understand the trigger event, we classify the acquisition memory into the pre-trigger buffer and post-trigger buffer.

  • Page 89: Trigger Coupling

    Chapter 5 To Trigger the Oscilloscope RIGOL are forced and acquisitions are made so as to display the waveforms. This trigger mode should be used when the signal level is unknown or the DC should be displayed as well as when forcible trigger is not necessary as the trigger condition always occurs.

  • Page 90: Trigger Holdoff

    Chapter 5 To Trigger the Oscilloscope RIGOL AC: blocks the DC components and attenuates signals. ⚫ LFR: blocks the DC components and rejects the low-frequency components. ⚫ HFR: rejects the high frequency components. ⚫ When "AC" or "LFR" is selected under Coupling, no trigger level lines and trigger icons are displayed.

  • Page 91: Noise Rejection

    Chapter 5 To Trigger the Oscilloscope RIGOL Noise Rejection Noise rejection can reject the high frequency noise in the signal and reduce the possibility of miss-trigger of the oscilloscope. In the trigger control area (Trigger) on the front panel, press Menu to enter the trigger setting menu, then press Noise Reject continuously (for some triggers, Noise Reject is a sub menu under More, at this time, press Menu →...

  • Page 92: Trigger Type

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Type MSO5000 series oscilloscope provides the following trigger types. Edge Trigger ⚫ Pulse Trigger ⚫ Slope Trigger ⚫ Video Trigger ⚫ Pattern Trigger ⚫ Duration Trigger ⚫ Timeout Trigger ⚫ Window Trigger ⚫...

  • Page 93: Edge Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Edge Trigger Triggers on the trigger level/threshold level of the specified edge of the input signal. Trigger Type: Press Menu → Type in the trigger control area (Trigger) on the front panel and rotate the multifunction knob to select "Edge", then press down the knob to...

  • Page 94: Pulse Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Please refer to descriptions in "Trigger LEVEL/Threshold Level". The current trigger level/threshold level value is displayed at the upper-right corner of the screen. Pulse Trigger Triggers on the positive or negative pulse with a specified width. In this mode, the oscilloscope will trigger when the pulse width of the input signal satisfies the specified pulse width condition.
  • Page 95 Chapter 5 To Trigger the Oscilloscope RIGOL Polarity: Press Polarity continuously to select the desired polarity. The polarities available are positive polarity ( ) and negative polarity ( ). Trigger Condition: Press When, then rotate the multifunction knob to select the trigger condition, and then press down the knob to select the trigger condition.

  • Page 96: Slope Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Parameter Setting: Set the trigger parameters (trigger holdoff and noise rejection) under this trigger type. For details, refer to descriptions in "Trigger Holdoff" and "Noise Rejection". Trigger LEVEL/Threshold Level: Rotate the Trigger LEVEL knob to adjust the trigger level or threshold level.
  • Page 97 Chapter 5 To Trigger the Oscilloscope RIGOL Edge Type: Press Slope continuously to select the input signal edge on which the oscilloscope triggers. Rising: triggers on the rising edge of the input signal. ⚫ Falling: triggers on the falling edge of the input signal.
  • Page 98 Chapter 5 To Trigger the Oscilloscope RIGOL to correctly trigger the signal and obtain a stable waveform. Press Level Select (when "<>" is selected as the trigger condition, Level Select is a sub-menu under More), then rotate the multifunction knob to select the desired level type for adjustment, and then press down the knob to select the type.

  • Page 99: Video Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Video Trigger The video signal can include image information and timing information, which adopts different standards and formats. MSO5000 series can trigger on the standard video signal field or line of NTSC (National Television Standards Committee), PAL (Phase Alternating Line), or SECAM (Sequential Couleur A Memoire).
  • Page 100 Chapter 5 To Trigger the Oscilloscope RIGOL 1080p/30Hz Progressive Scan 1125 1080p/25Hz Progressive Scan 1125 1080p/24Hz Progressive Scan 1125 1080i/60Hz Interlaced Scan 1125 1080i/50Hz Interlaced Scan 1125 Sync: Press Sync, then rotate the multifunction knob to select the sync type, and then press down the knob to select the type.

  • Page 101: Pattern Trigger

    In the trigger debugging process of video signals, the frequency in different ⚫ part of the signal can be reflected by a different brightness, as RIGOL digital oscilloscope provides the intensity graded color display function. Experienced users can quickly judge the signal quality and discover abnormalities during the debugging process.
  • Page 102 Chapter 5 To Trigger the Oscilloscope RIGOL Pattern Setting: Press Code, and rotate the multifunction knob to select the pattern of the currently selected channel. Press down the knob to select the pattern. You can also press Code continuously to select the pattern or enable the touch screen to select it.

  • Page 103: Duration Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Note: Only one edge (rising or falling edge) can be specified in the pattern. If one edge item is currently defined and then another edge item is defined in another channel in the pattern, then a prompt message "Invalid input" is displayed. Then the latter defined edge item will be replaced by X.
  • Page 104 Chapter 5 To Trigger the Oscilloscope RIGOL Figure 5-7 Duration Trigger Trigger Type: Press Type, and then rotate the multifunction knob to select "Duration". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below.
  • Page 105 Chapter 5 To Trigger the Oscilloscope RIGOL L: sets the pattern of the channel selected to "L", i.g. the voltage level is lower ⚫ than the trigger level/threshold level of the channel. X: sets the pattern of the channel selected to "X", i.g. this channel is not used as ⚫...

  • Page 106: Timeout Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger LEVEL/Threshold Level: Rotate the Trigger LEVEL knob to adjust the trigger level/threshold level. Refer to "Trigger LEVEL/Threshold Level". The current trigger level/threshold level value is displayed at the upper-right corner of the screen.

  • Page 107: Runt Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL the trigger level. Falling: starts timing when the falling edge of the input signal passes ⚫ through the trigger level. Either: starts timing when either edge of the input signal passes through the ⚫...
  • Page 108 Chapter 5 To Trigger the Oscilloscope RIGOL displayed at the upper-right corner of the screen, as shown in the figure below. You can also press Type continuously to select the trigger type or enable the touch screen to tap the desired trigger type and select it.

  • Page 109: Window Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL the trigger level deviation (the difference between the upper limit and lower limit of the trigger level) remains unchanged. Note: In Runt trigger, pressing Trigger LEVEL can quickly switch the current level adjustment type.
  • Page 110 Chapter 5 To Trigger the Oscilloscope RIGOL Source Selection: Press Source to switch the trigger source and select CH1-CH4. For details, refer to descriptions in "Trigger Source". The current trigger source is displayed at the upper-right corner of the screen.

  • Page 111: Delay Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Note: In Window trigger, pressing Trigger LEVEL can quickly switch the current level adjustment type. Rotate the Trigger LEVEL knob to adjust the corresponding trigger level. During the adjustment of trigger level, two trigger level lines appear on the screen, and they move up and down with the change of the trigger level.
  • Page 112 Chapter 5 To Trigger the Oscilloscope RIGOL Edge A= Edge B= Source A Source B Figure 5-10 Delay Trigger Trigger Type: Press Type, and then use the multifunction knob to select "Delay". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below.

  • Page 113: Setup/Hold Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Source A and Source B is greater than the preset time lower limit. Press Lower to set the delay time lower limit in Delay trigger. <: triggers when the time difference (△T) between the specified edges of ⚫...
  • Page 114 Chapter 5 To Trigger the Oscilloscope RIGOL T1 is the setup time is the hold time Data Source Clock Source The data type is H The edge type is Figure 5-11 Setup/Hold Trigger Trigger Type: Press Type, and then rotate the multifunction knob to select "Setup/Hold".
  • Page 115 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Condition: Press When and rotate the multifunction knob to select the trigger condition of Setup/Hold trigger. Press down the knob to select the trigger condition. You can also press When continuously or enable the touch screen to select it.

  • Page 116: Nth Edge Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Nth Edge Trigger Triggers on the Nth edge that appears after the specified idle time. For example, in the waveform shown in the figure below, the instrument should trigger on the second rising edge after the specified idle time (the time between two neighboring rising edges), and the idle time should be within the range between P and M (P<Idle...

  • Page 117: Rs232 Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL Idle Time: Press Idle to set the idle time before the edge counting in Nth edge trigger. Rotate the multifunction knob or use the pop-up numeric keypad to set the idle time. Edge Count: Press Edges to set the value of "N"...
  • Page 118 Chapter 5 To Trigger the Oscilloscope RIGOL Source: Press Source to open the signal source list and select CH1-CH4 or D0-D15. For details, refer to descriptions in "Trigger Source". The current trigger source is displayed at the upper-right corner of the screen.
  • Page 119 Chapter 5 To Trigger the Oscilloscope RIGOL specifies a clock frequency). Three setting methods are available for baud rate: Press Baud Rate, then set the user-defined baud rate with the displayed ⚫ numeric keypad. Press Baud Rate, then select the preset baud rate from the available options.

  • Page 120: I2C Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL I2C Trigger (Option) I2C is a 2-wire serial bus used to connect the microcontroller and its peripheral device. It is a bus standard widely used in the microelectronic communication control field. The I2C serial bus consists of SCL and SDA. Its transmission rate is determined by SCL, and its transmission data is determined by SDA, as shown in the figure below.
  • Page 121 Chapter 5 To Trigger the Oscilloscope RIGOL high level. Stop: triggers when SDA data transitions from low level to high level while SCL is ⚫ high level. Restart: triggers when another start condition occurs before a stop condition. ⚫ MissedAck: triggers when the SDA data is high level during any acknowledgment ⚫...

  • Page 122: Spi Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL Press Bytes, then rotate the multifunction knob or use the pop-up ➢ numeric keypad to set the length of the data. Its range is from 1 to 5. Press More → Addr Bits, and rotate the multifunction knob to select ➢...
  • Page 123 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Type: Press Type, and then rotate the multifunction knob to select "SPI". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below. You can also press Type continuously to select the trigger type or enable the touch screen to tap the desired trigger type and select it.

  • Page 124: Can Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Mode: In the trigger control area (Trigger) on the front panel, press Mode to quickly switch the current trigger mode. For details, refer to descriptions in "Trigger Mode". Trigger Parameter Setting: Set the trigger parameter (noise rejection) under this trigger type. For details, refer to descriptions in "Noise Rejection".
  • Page 125 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Condition: Press When to select the desired trigger condition. SOF: triggers at the start of a frame. ⚫ EOF: triggers at the end of a frame. ⚫ Remote ID: triggers on the remote frame with the specified ID. Set the following ⚫...
  • Page 126 Chapter 5 To Trigger the Oscilloscope RIGOL Baud Rate: Press More → Baud to set the baud rate. Three setting methods are available for baud rate: Press Baud, then set the user-defined baud rate with the displayed numeric ⚫ keypad.

  • Page 127: Flexray Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL FlexRay Trigger (Option) MSO5000 can trigger on the specified frame, symbol, error, or position of the FlexRay bus. FlexRay is a type of differential serial bus configured with three consecutive segments (i.g. header, payload, and trailer). Its data transmission rate is up to 10 Mb/s.
  • Page 128 Chapter 5 To Trigger the Oscilloscope RIGOL matches the FlexRay bus signal. Then press down the knob to select the baud rate. You can also press Baud continuously or enable the touch screen to select it. The available baud rates are 2.5 Mbps, 5 Mbps, and 10 Mbps.

  • Page 129: Lin Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Mode: In the trigger control area (Trigger) on the front panel, press Mode to quickly switch the current trigger mode. For details, refer to descriptions in "Trigger Mode". Trigger Parameter Setting: Set the trigger parameter (noise rejection) under this trigger type. For details, refer to descriptions in "Noise Rejection".
  • Page 130 Chapter 5 To Trigger the Oscilloscope RIGOL Sync: triggers on the last bit of the sync field. ⚫ ID: triggers when the frame with an ID equal to the selected value is detected. ⚫ Press ID, then rotate the multifunction knob or use the pop-up numeric keypad to set ID.

  • Page 131: I2S Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL One Bit Figure 5-21 Sample Position Press More → Sample Position, then rotate the multifunction knob or use the pop-up numeric keypad to set the sample position. The settable range is from 10% to 90%.
  • Page 132 Chapter 5 To Trigger the Oscilloscope RIGOL Figure 5-22 Sequential Chart of I2S Bus Trigger Type: Press Type, and then rotate the multifunction knob to select "I2S". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below.
  • Page 133 Chapter 5 To Trigger the Oscilloscope RIGOL ≠: triggers when the channel's data do not equal the set data value. Press Data ⚫ to set the data bit. For setting methods, refer to descriptions in "I2C Trigger (Option)". >: triggers when the channel's data are greater than the set data value. Press ⚫...

  • Page 134: Mil-Std-1553 Trigger (Option)

    Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Parameter Setting: Set the trigger parameter (noise rejection) under this trigger type. For details, refer to descriptions in "Noise Rejection". Trigger LEVEL/Threshold Level: Rotate the Trigger LEVEL knob to adjust the trigger level/threshold level. Refer to "Trigger LEVEL/Threshold Level".
  • Page 135 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Type: Press Type, and then rotate the multifunction knob to select "MIL-STD-1553". Press down the knob to select the trigger type. Then, the current trigger setting information is displayed at the upper-right corner of the screen, as shown in the figure below.
  • Page 136 Chapter 5 To Trigger the Oscilloscope RIGOL RTA: triggers on the specified remote terminal address. After this trigger ⚫ condition is selected, press RTA to set the remote terminal address. For setting methods, refer to descriptions in "I2C Trigger (Option)".

  • Page 137: Zone Trigger

    Chapter 5 To Trigger the Oscilloscope RIGOL Polarity: Press More → Polarity to select the desired polarity. The polarities available are positive polarity ( ) and negative polarity ( ). Trigger Mode: In the trigger control area (Trigger) on the front panel, press Mode to quickly switch the current trigger mode.

  • Page 138: Trigger Output Connector

    Chapter 5 To Trigger the Oscilloscope RIGOL Set the conditions for Trigger zone A and Trigger zone B: Press Zone A or Zone B, rotate the multifunction knob to select "Intersect" or "Not intersect", then press down the knob to select it. You can also press Zone A or Zone B continuously to select the condition, or enable the touch screen to tap the desired condition and select it.
  • Page 139 Chapter 5 To Trigger the Oscilloscope RIGOL Trigger Output Connector Figure 5-24 Trigger Output Connector Press Utility → System → AUX Out to select "TrigOut”. A signal which reflects the current capture rate of the oscilloscope can be output from the [TRIG OUT] connector each time a trigger is generated by the oscilloscope.

  • Page 141: Chapter 6 Operations And Measurements

    Chapter 6 Operations and Measurements RIGOL Chapter 6 Operations and Measurements MSO5000 can perform math operations, auto measurements, and cursor measurements on sampled and displayed data. Contents in this chapter: Math Operation ◼ Auto Measurement ◼ Cursor Measurement ◼ MSO5000 User Guide...

  • Page 142: Math Operation

    Chapter 6 Operations and Measurements RIGOL Math Operation Press Math in the vertical control area (Vertical) on the front panel to open the math operation menu. You can also tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then tap the "Math" icon to open the math operation menu.

  • Page 143: Subtraction

    Chapter 6 Operations and Measurements RIGOL or enable the touch screen to select the channel. The available channels for Source A and Source B are CH1-CH4 and Ref1-Ref10. Note: The available channels for Math2 are CH1-CH4, Ref1-Ref10 or Math1. The available channels for Math3 are CH1-CH4, Ref1-Ref10, Math1 or Math2.

  • Page 144: Multiplication

    Chapter 6 Operations and Measurements RIGOL Note: The available channels for Math2 are CH1-CH4, Ref1-Ref10 or Math1. The available channels for Math3 are CH1-CH4, Ref1-Ref10, Math1 or Math2. The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected.

  • Page 145: Division

    Chapter 6 Operations and Measurements RIGOL The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected. Press Offset to set the vertical offset of the operation results. For setting ⚫...

  • Page 146: Fft

    Chapter 6 Operations and Measurements RIGOL The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected. Press Offset to set the vertical offset of the operation results. For setting ⚫...
  • Page 147 Chapter 6 Operations and Measurements RIGOL the following figure. Of which, FFT resolution is the quotient of the sample rate and the number of FFT points. If the number of FFT points is a fixed value (65535 at most), then the lower the sample rate, the higher the resolution.
  • Page 148 Chapter 6 Operations and Measurements RIGOL descriptions in "Parameter Setting Method". Press More → Peak Search to enter the peak search menu. ⚫ Press Peak Search continuously to enable or disable the peak search function. When enabled, the peak search results are displayed on the screen, as shown in the figure below.
  • Page 149 Chapter 6 Operations and Measurements RIGOL Similar to the frequencies. situation when Wide band random noise with no window is relatively slow change of waveform applied. spectrum. Blackman-Harris Best amplitude Single frequency signal, searching for resolution higher order harmonics. Poorest...

  • Page 150: And" Operation

    Chapter 6 Operations and Measurements RIGOL "AND" Operation Performs logic "AND" operation on the waveform voltage values of the specified sources point by point and displays the results. In operation, when the voltage value of the source channel is greater than the threshold of the corresponding channel, it is regarded as logic "1";...

  • Page 151: Or" Operation

    Chapter 6 Operations and Measurements RIGOL Press Offset, and then rotate the multifunction knob to adjust the vertical ⚫ offset of the operation results. You can also enable the touch screen and use the "Drag" gesture to adjust the vertical offset.

  • Page 152: Xor" Operation

    Chapter 6 Operations and Measurements RIGOL If Source A (or Source B) selects CH2, press More → Thre.CH2 to set the ➢ threshold of Source A (or Source B) in logic operation. For setting methods, refer to descriptions in "Parameter Setting Method".

  • Page 153: Not" Operation

    Chapter 6 Operations and Measurements RIGOL function. Press SourceA and SourceB respectively, and rotate the multifunction knob ⚫ to select the channel for Source A and Source B. Then press down the knob to select the channel. You can also press SourceA and SourceB continuously or enable the touch screen to select the channel.
  • Page 154 Chapter 6 Operations and Measurements RIGOL Table 6-5 Logic "NOT" Operation Press Math → Math1 → Operator to select "!A": Press Operation continuously to enable or disable the "NOT" operation ⚫ function. Press SourceA, and rotate the multifunction knob to select the channel for ⚫...

  • Page 155: Intg

    Chapter 6 Operations and Measurements RIGOL Intg Calculates the integral of the selected source. For example, you can use integral to measure the area under a waveform or the pulse energy. Press Math → Math1 → Operator to select "Intg": Press Operation continuously to enable or disable the "Intg"...

  • Page 156: Diff

    Chapter 6 Operations and Measurements RIGOL Diff Calculates the discrete time derivative of the selected source. For example, you can use differentiate to measure the instantaneous slope of a waveform. Press Math → Math1 → Operator to select "Diff": Press Operation continuously to enable or disable the "Diff" operation function.

  • Page 157: Sqrt

    Chapter 6 Operations and Measurements RIGOL Because differentiation is very sensitive to noise, it is helpful to set acquisition mode to "Average". Sqrt Calculates the square root of the selected source point by point and displays the results. Press Math → Math1 → Operator to select "Sqrt": Press Operation continuously to enable or disable the "Sqrt"...

  • Page 158: Lg (Base 10 Exponential)

    Chapter 6 Operations and Measurements RIGOL Lg (Base 10 Exponential) Calculates the base 10 exponential of the selected source point by point and displays the results. Press Math → Math1 → Operator to select "Lg": Press Operation continuously to enable or disable the "Lg" operation function.

  • Page 159: Exp

    Chapter 6 Operations and Measurements RIGOL Press Operation continuously to enable or disable the "Ln" operation function. ⚫ Press SourceA, and rotate the multifunction knob to select the channel for ⚫ Source A. Then press down the knob to select the channel. You can also press SourceA continuously or enable the touch screen to select the channel.

  • Page 160: Abs

    Chapter 6 Operations and Measurements RIGOL The available channels for Math3 are CH1-CH4, Ref1-Ref10, Math1 or Math2. The available channels for Math4 are CH1-CH4, Ref1-Ref10, Math1, Math2 or Math3. Only the channels that have been enabled currently can be selected.

  • Page 161: Low Pass

    Chapter 6 Operations and Measurements RIGOL Press Scale to set the vertical scale of the operation results. For setting methods, ⚫ refer to the descriptions in "Parameter Setting Method". You can also enable the touch screen and use the "Pinch & Stretch" gesture to adjust the vertical scale.

  • Page 162: High Pass

    Chapter 6 Operations and Measurements RIGOL Press ωc to set the upper limit frequency. For setting methods, refer to ⚫ descriptions in "Parameter Setting Method". Press More → AutoSetting to adjust the vertical scale and offset of the ⚫ operation results to an optimal value based on the current configuration, so as to better observe.

  • Page 163: Band Pass

    Chapter 6 Operations and Measurements RIGOL operation results to an optimal value based on the current configuration, so as to better observe. Press More → Invert to enable or disable the inverted display function of the ⚫ waveform. Press More → Label to set the label for math operation results. For details, ⚫...

  • Page 164: Band Stop

    Chapter 6 Operations and Measurements RIGOL to descriptions in "Parameter Setting Method". Press More → Invert to enable or disable the inverted display function of the ⚫ waveform. Press More → Label to set the label for math operation results. For details, ⚫...

  • Page 165: Ax+B

    Chapter 6 Operations and Measurements RIGOL Press More → Invert to enable or disable the inverted display function of the ⚫ waveform. Press More → Label to set the label for math operation results. For details, ⚫ refer to descriptions in "Math Operation Label".

  • Page 166: Math Operation Label

    Chapter 6 Operations and Measurements RIGOL Press More → Label to set the label for math operation results. For details, ⚫ refer to descriptions in "Math Operation Label". Press More → Color Grade to enable or disable the color grade display of the ⚫...

  • Page 167: Auto Measurement

    Chapter 6 Operations and Measurements RIGOL Auto Measurement MSO5000 provides auto measurements for 41 waveform parameters, as well as the statistics and analysis of the measurement results. Quick Measurement after AUTO When the oscilloscope is correctly connected and has detected a valid input signal, press AUTO to enable the waveform auto setting function and open the auto setting function menu.
  • Page 168 Chapter 6 Operations and Measurements RIGOL If you lock the Auto function and then exit the auto setting function menu, you can press Utility → More → Auto Config to enter the auto setting function menu again to unlock the Auto function.
  • Page 169 Chapter 6 Operations and Measurements RIGOL Note: The waveform auto setting function requires that the frequency of the signal should be greater than or equal to 35 Hz, the amplitude greater than or equal to 5 mV. If not meeting the conditions, the waveform auto setting function may be invalid.

  • Page 170: Measurement Parameter

    Chapter 6 Operations and Measurements RIGOL Measurement Parameter Press Measure on the front panel to enter the measurement setting menu. You can set the measurement source, enable or disable the all measurement function, the statistical analysis function, and etc. You can also quickly make measurements for 41 waveform parameters.
  • Page 171 Chapter 6 Operations and Measurements RIGOL 6． -Width: indicates the time between the threshold middle value of a falling edge to the threshold middle value of the next rising edge. 7． +Duty: indicates the ratio of the positive pulse width to the period.
  • Page 172 Chapter 6 Operations and Measurements RIGOL Rising Edge Count = n Threshold Upper Limit Threshold Lower Limit 4． Falling Edge Count: The number of falling edges that fall from above the threshold upper limit to below the threshold lower limit.
  • Page 173 Chapter 6 Operations and Measurements RIGOL 3． Delay A →B : indicates the time difference between the threshold middle values of the rising edge of Source A and the falling edge of Source B. Negative delay indicates that the rising edge of Source A occurred after the falling edge of Source B.
  • Page 174 Chapter 6 Operations and Measurements RIGOL Note: Source A and Source B can be any channel among CH1-CH4, Math1-Math4, or ⚫ D0-D15. You can press Measure → Add to enter the sub-menu to set the parameters. The default threshold middle value is 50%. You can press Measure → Setting ⚫...
  • Page 175 Chapter 6 Operations and Measurements RIGOL gating area. The formula is shown as follows: ∑ Average Wherein, is the measurement result of the i th point, and n is the number of points being measured. 11. VRMS: indicates the root mean square value on the whole waveform or in the gating area.

  • Page 176: Measurement Settings

    Chapter 6 Operations and Measurements RIGOL reference is negative. The area measured is the algebraic sum of the whole period area. Measurement Settings 1． Measurement Category Press Measure → Add → Category to select "Horizontal", "Vertical", or "Other". Meanwhile, the specific measurement parameters are displayed on the screen, as shown in the figure below.
  • Page 177 Chapter 6 Operations and Measurements RIGOL parameters. When you rotate the multifunction knob to switch from the ⚫ measurement parameter area to the measurement category area, you need to press down the knob to select the desired measurement category. In the measurement category area, rotate the multifunction knob ⚫...
  • Page 178 Chapter 6 Operations and Measurements RIGOL Press Type to select "Threshold", "Range", or "Amp Method". ⚫ Select "Threshold", and then make the following settings: ➢ --Press Source to select the desired channel for measurement (CH1-CH4 or Math1-Math4). --Press Upper to select "Upper(%)" or "Upper(Abs)" first, and then press the key to set the upper limit of the measurement.

  • Page 179: Remove The Measurement Result

    Chapter 6 Operations and Measurements RIGOL Modifying the threshold will affect the measurement results of ⚫ the time, delay and phase parameters. If you select "Manual" under Amp Method, the measurement ⚫ results of other parameters may be affected. "Histogram" and "Max-Min" are the internal measurement ⚫...

  • Page 180: All Measurement

    Chapter 6 Operations and Measurements RIGOL Press Measure → Statistic to enter the sub-menu of "Statistic". Press Statistic to enable or disable the statistical function. ⚫ Press Reset Stat. to clear the history statistics data and makes statistics again. ⚫...
  • Page 181 Chapter 6 Operations and Measurements RIGOL X Cursor (Cursor A) X Cursor (Cursor B) Y Cursor (Cursor A) Y Cursor (Cursor B) X Cursor ⚫ X cursor is a vertical solid/dotted line that is used to make horizontal adjustments. It can be used to measure time (s), frequency (Hz), phase (°), and ratio (%).

  • Page 182: Manual Mode

    Chapter 6 Operations and Measurements RIGOL Note: When the Time Base Mode is set to "XY", the XY cursor measurement mode is valid. Manual Mode In this mode, you can adjust the cursor manually to measure the value of the waveforms of the specified source at the current cursor.
  • Page 183 Chapter 6 Operations and Measurements RIGOL channels are None, CH1-CH4, LA, and Math1-Math4. Note: Only channels currently enabled can be selected. ⚫ When "LA" is selected under Source, Select is grayed out and disabled. By ⚫ default, "X" is selected under Select.
  • Page 184 Chapter 6 Operations and Measurements RIGOL 5. Set the Horizontal/Vertical Measurement Unit When "X" is selected under Select, you can set the horizontal measurement ⚫ unit. When the source can be Math1-Math4, this menu is grayed out and disabled. Press More → Hori. Unit, and rotate the multifunction knob to select the horizontal measurement unit.
  • Page 185 Chapter 6 Operations and Measurements RIGOL The available units include "Source" and "Percent(%)". Source: measures the amplitude at Y Cursor (taking the channel ➢ ground point as the reference). The measurement results include AY, BY, and △Y (its unit is consistent with that of the current source).

  • Page 186: Track Mode

    Chapter 6 Operations and Measurements RIGOL Track Mode In this mode, you can adjust the two pairs of cursors (Cursor A and Cursor B) to measure the X and Y values on two different sources respectively. The points being measured on Cursor A and Cursor B are marked by respectively.
  • Page 187 Chapter 6 Operations and Measurements RIGOL 2. Select the Track Axis Press Track to select "X" or "Y" as the current track axis. The default is "X". X: tracks X Cursor and measures the value at X Cursor. ⚫ Y: tracks Y Cursor and measures the time of the first point at the left side of ⚫...

  • Page 188: Xy Mode

    Chapter 6 Operations and Measurements RIGOL Track Measurement (before Horizontal Expansion): Track Measurement (after Horizontal Expansion): XY Mode XY mode is only available when the horizontal time base mode is "XY" (refer to "Timebase Mode"). In this mode, two pairs of cursors will appear. You can adjust the cursor positions to measure the X and Y values at the crossing points of the two pairs of cursors.
  • Page 189 Chapter 6 Operations and Measurements RIGOL △X: indicates the horizontal spacing between Cursor A and Cursor B. ⚫ △Y: indicates the vertical spacing between Cursor A and Cursor B. ⚫ 1. Adjust Cursor Position Press AX and rotate the multifunction knob to adjust the X value at ⚫...

  • Page 190: Measure Mode

    Chapter 6 Operations and Measurements RIGOL Measure Mode Press Mode to select "Measure". In this mode, the cursor position for measurement is displayed. Press Indicator continuously to enable or disable the indicator. If it is enabled, one or multiple cursors are displayed on the screen. Before enabling the indicator, you need to enable at least one parameter for auto measurement.

  • Page 191: Chapter 7 Digital Voltmeter (Dvm) And Frequency Counter

    Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Chapter 7 Digital Voltmeter (DVM) and Frequency Counter MSO5000 series oscilloscope provides a built-in digital voltmeter (DVM) and frequency counter, which enable you to perform an accurate measurement, improving user experience in counter and frequency measurement.

  • Page 192: Digital Voltmeter (Dvm)

    Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Digital Voltmeter (DVM) The built-in DVM of this oscilloscope provides 3-digit voltage measurements on any analog channel. DVM measurements are asynchronous from the oscilloscope’s acquisition system and are always acquiring. Press Measure → Analyze → DVM to open the DVM setting menu, or enable the...

  • Page 193: To Select Measurement Mode

    Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Note: Even if the analog channel (CH1-CH4) is not enabled, you can still perform the DVM measurement. To Select Measurement Mode Press Mode in the "DVM" setting menu, then rotate the multifunction knob select the desired mode, and then press down the knob to select the mode.

  • Page 194: Frequency Counter

    Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL Frequency Counter The frequency counter analysis function provides frequency, period, or edge event counter measurements on any analog channel. Press Measure → Analyze → Counter to open the frequency counter setting menu, or enable the touch screen and then tap the function navigation icon the lower-left corner of the screen to open the function navigation.

  • Page 195: To Set Resolution

    Chapter 7 Digital Voltmeter (DVM) and Frequency Counter RIGOL select the desired measurement item, and then press down the knob to select the item. You can also press Measure continuously or enable the touch screen to tap the desired measurement item and select it.

  • Page 197: Chapter 8 Power Analysis (Option)

    Chapter 8 Power Analysis (Option) RIGOL Chapter 8 Power Analysis (Option) MSO5000 series oscilloscope provides an optional power analysis function, which can help you easily analyze the efficiency and reliability of the switch-mode power supplies. With the power analysis function, you can analyze the power quality and output ripple noise of the input power.

  • Page 198: Power Quality

    Chapter 8 Power Analysis (Option) RIGOL Power Quality By analyzing the power quality, you can test the quality of AC input lines. The specific measurement parameters for power quality analysis include V_RMS, I_RMS, real power, apparent power, reactive power, power factor, reference frequency, phase angle, impedance, voltage crest factor, and current crest factor.
  • Page 199 Chapter 8 Power Analysis (Option) RIGOL numeric keypad to set the middle value. The middle value is limited by the settings of the upper limit and lower limit. Press Lower, then rotate the multifunction knob or use the pop-up ➢...

  • Page 200: Ripple

    Chapter 8 Power Analysis (Option) RIGOL Figure 8-1 Connection Diagram of Power Quality Analysis Ripple Power ripple is an important parameter for evaluating DC power supply, which indicates the ripple quantity of the output DC voltage. The ripple analysis can measure the current value, average value, minimum value, maximum value, standard deviation, and count value of the ripples on the power output terminal.
  • Page 201 Chapter 8 Power Analysis (Option) RIGOL the figure below. You can also enable the touch screen to tap the icon at the right-upper corner of the statistical results window to close it. View the Connection Diagram ⚫ Press Tips, and then the connection diagram of the ripple analysis is displayed on the screen.

  • Page 203: Chapter 9 Histogram Analysis

    Chapter 9 Histogram Analysis RIGOL Chapter 9 Histogram Analysis MSO5000 series oscilloscope supports the standard histogram analysis function, enabling you to judge the trend of waveforms, and quickly locate the potential problems of the signal. Contents in this chapter: To Enable or Disable the Histogram Function ◼...

  • Page 204: To Enable Or Disable The Histogram Function

    Chapter 9 Histogram Analysis RIGOL To Enable or Disable the Histogram Function The histogram analysis function supported by the MSO5000 series is available to provide a statistical view of waveforms or measurement results. It can be classified into horizontal histogram, vertical histogram, and measurement histogram. With the...

  • Page 205: To Select The Histogram Source

    Chapter 9 Histogram Analysis RIGOL To Select the Histogram Source If "Horizontal" or "Vertical" is selected under Type, you need to set the source (CH1-CH4). Press Source, then rotate the multifunction knob to select the desired source, and then press down the knob to select the source. You can also press Source continuously or enable the touch screen to select it.

  • Page 206: To Reset

    Chapter 9 Histogram Analysis RIGOL Sum: indicates the sum of all bins (buckets) in the histogram. ⚫ Peaks: indicates the maximum number of hits in any single bin. ⚫ Max: indicates the maximum value within the histogram range. ⚫ Min: indicates the minimum value within the histogram range.

  • Page 207: Chapter 10 Digital Channel

    Chapter 10 Digital Channel RIGOL Chapter 10 Digital Channel MSO5000 series oscilloscope has an standard configuration of the logic analyzer (LA) function, and it has 16 digital channels. The default channel label is D15-D0. The oscilloscope compares the voltages acquired in each sample with the preset logic threshold.

  • Page 208: To Select The Digital Channel

    Chapter 10 Digital Channel RIGOL To Select the Digital Channel Press LA on the front panel to enter the LA setting menu. Press Select to open the channel menu, and rotate the multifunction knob to select the channel. You can also press Select continuously or enable the touch screen to select it.

  • Page 209: To Set The Threshold And Calibrate Probe

    Chapter 10 Digital Channel RIGOL Enable/disable a single digital channel ⚫ Press Dx On/Off to open the channel selection list. Rotate the multifunction knob to select a channel, and then press down the knob to enable or disable it. You can also press Dx On/Off continuously to switch to select any channel, and press down the multifunction knob to enable or disable the channel.

  • Page 210: Auto Arrangement Setting

    Chapter 10 Digital Channel RIGOL at the right side of the threshold field, and then the threshold selection list is displayed. Tap to select the preset threshold. Or tap the threshold input field and input the value with the pop-up numeric keypad.

  • Page 211: Group Setting

    Chapter 10 Digital Channel RIGOL Press Display continuously to enable or disable the display of the channel label. If it is enabled, the label will be displayed at the left side of the waveform. Select a specified digital channel ⚫...

  • Page 212: Waveform Color Of The Digital Channel

    Chapter 10 Digital Channel RIGOL Note: You can only ungroup the digital channel group. ⚫ If no group is set, the Ungroup menu and the Group On/Off menu are ⚫ grayed out and disabled. Waveform Color of the Digital Channel When the digital channel is enabled, its corresponding waveforms and label are displayed on the screen.

  • Page 213: Chapter 11 Protocol Decoding

    Chapter 11 Protocol Decoding RIGOL Chapter 11 Protocol Decoding You can use the protocol analysis to discover errors, debug hardware, and accelerate development easily, ensuring you to accomplish the projects with high speed and good quality. Protocol decoding is the basis of protocol analysis. Only protocol analyses with correct protocol decoding are acceptable, and only correct protocol decoding can identify more error information.

  • Page 214: Parallel Decoding

    Chapter 11 Protocol Decoding RIGOL Parallel Decoding Parallel bus consists of clock line and data line. As shown in the figure below, CLK is the clock line, whereas Bit0 and Bit1 are the 0 bit and 1st bit on the data line respectively.
  • Page 215 Chapter 11 Protocol Decoding RIGOL Falling : samples the channel data on the falling edge of the clock. Both : samples the channel data on both the rising edge and the falling edge of the clock. Set the threshold ⚫...
  • Page 216 Chapter 11 Protocol Decoding RIGOL D8-D15 8 0 (default) Bit0 to Bit7 are set to D8 to D15 (default) respectively. Width is set automatically, and you cannot modify them. D0-D15 16 0 (default) Bit0 to Bit15 are set to D0 to (default) D15 respectively.
  • Page 217 Chapter 11 Protocol Decoding RIGOL Polarity ⚫ Press Polarity continuously to select Positive or Negative as the polarity for data decoding. 4． Display-related setting Press Display to enter the display setting menu. Set the display format ⚫ Press Format, rotate the multifunction knob to select the display format of the bus data.
  • Page 218 Chapter 11 Protocol Decoding RIGOL Line Number Time Decode Name Decoded Data Event Table Parallel Bus Figure 11-2 Parallel Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.

  • Page 219: Rs232 Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL details in the "Packets" view. Export: If you select "Packets", you can export time and the ➢ corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.
  • Page 220 Chapter 11 Protocol Decoding RIGOL Figure 11-4 Schematic Diagram of Negative Logic In RS232, baud rate is used to represent the transmission rate (namely bits per second) of the data. You need to set the start bit, data bits, check bit (optional), and stop bit for each frame of data.
  • Page 221 Chapter 11 Protocol Decoding RIGOL 4． Source setting Press Sources to enter the source setting menu. Set the Tx source and the threshold ⚫ Press Tx and rotate the multifunction knob to select the desired ➢ channel, and then press down the knob. You can also press Tx continuously or enable the touch screen to select it.
  • Page 222 Chapter 11 Protocol Decoding RIGOL is an odd number. For example, when 0x55 (01010101) is sent, "1" should be added to the check bit. Stop Bit ⚫ Press Stop Bit and rotate the multifunction knob to set the stop bits after each frame of data.
  • Page 223 Chapter 11 Protocol Decoding RIGOL Adjust the vertical position of the bus ⚫ Press Position, and then rotate the multifunction knob to adjust the vertical display position of the bus. Set the label display ⚫ Press Label to enable or disable the label display of the RS232 decoding bus.
  • Page 224 Chapter 11 Protocol Decoding RIGOL the top of the event table to select it. If you select "Packets", the decoded data (TX and/or RX), time, and error information (TX and/or RX) are displayed in the event table. If you select "Details", the detailed data in the specified row will be displayed in the event table.
  • Page 225 Chapter 11 Protocol Decoding RIGOL EOF Error ⚫ This error is generated when the EOF condition is not met. For example, if the Stop Bit is set to 1.5, but the actual stop bits is less than 1.5 bits, then...

  • Page 226: I2C Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL I2C Decoding (Option) I2C serial bus consists of the clock line (SCL) and the data line (SDA). SCL: samples SDA on the rising or falling edge of the clock. SDA: indicates the data channel. Figure 11-5 I2C Serial Bus In the decode setting menu, press Decode1 →...
  • Page 227 Chapter 11 Protocol Decoding RIGOL Press Exchange to select "SCL/SDA" or "SDA/SCL" to exchange the sources of the current clock channel and data channel. 4． Specify whether the address information includes the "R/W" bit For I2C bus, each frame of data starts with the address information. The address information includes the read address and the write address.
  • Page 228 Chapter 11 Protocol Decoding RIGOL Line Number Time R/W Bit Address Decoded Data Event Table I2C Bus Figure 11-6 I2C Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
  • Page 229 Chapter 11 Protocol Decoding RIGOL time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time, the corresponding ➢ decoded data, and etc. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.

  • Page 230: Spi Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL The detected ACK is 1 SPI Decoding (Option) SPI bus is based on the master-slave configuration and usually consists of chip select line (CS), clock line (SCLK), and data line (SDA). Wherein, the data lines include the master input/slave output (MISO) data line and master output/slave input (MOSI) data line.
  • Page 231 Chapter 11 Protocol Decoding RIGOL 2． Quickly apply SPI trigger settings to SPI decoding Press Copy Trig to copy the SPI trigger settings and apply them to SPI decoding function (set the corresponding SPI decoding parameters automatically). For analog channels, the threshold level settings will also be copied.
  • Page 232 Chapter 11 Protocol Decoding RIGOL You can also press MISO continuously or enable the touch screen to select it. The available channels include OFF, analog channels (CH1-CH4), and digital channels (D0-D15). When you select an analog channel (CH1-CH4), press Threshold below the MISO menu, then...
  • Page 233 Chapter 11 Protocol Decoding RIGOL Adjust the vertical position of the bus ⚫ Press Position, and then rotate the multifunction knob to adjust the vertical display position of the bus. Set the label display ⚫ Press Label to enable or disable the label display of the SPI decoding bus.
  • Page 234 Chapter 11 Protocol Decoding RIGOL Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.

  • Page 235: Lin Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL LIN Decoding (Option) The oscilloscope samples the LIN signal, and judges each data point to be logic "1" or logic "0" according to the preset threshold level. The LIN decoding is required to specify the LIN signal protocol version.
  • Page 236 Chapter 11 Protocol Decoding RIGOL Set the parity bit ⚫ Press Parity bit continuously to select whether the data contain the parity bit. Set the protocol version ⚫ Press Version and rotate the multifunction knob to select a protocol version that matches the LIN bus signal. Then, press down the knob to select it.
  • Page 237 Chapter 11 Protocol Decoding RIGOL Line Number Time Frame ID Decoded Data CRC Error Event Table LIN Bus Figure 11-9 LIN Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
  • Page 238 Chapter 11 Protocol Decoding RIGOL time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the ➢ corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.
  • Page 239 Chapter 11 Protocol Decoding RIGOL Parity Error Checksum Error ⚫ If the checksum error is detected, CRC is displayed in red, as shown in the figure below. Checksum Error Sync Error ⚫ If the sync error is detected, SYNC is displayed in red, as shown in the figure below.

  • Page 240: Can Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL Sync Error CAN Decoding (Option) The oscilloscope samples the CAN signal at the specified sample position. The oscilloscope will also judge each data point (logic "1" or logic "0") according to the preset threshold level. You need to specify the CAN signal type and sample position for CAN decoding.
  • Page 241 Chapter 11 Protocol Decoding RIGOL clock channel, a dotted line displaying the current threshold level is displayed on the screen. The dotted line disappears in about 2 s after you stop modifying the threshold. 4. Signal setting Press Settings to enter the signal setting menu.
  • Page 242 Chapter 11 Protocol Decoding RIGOL Press Sample Position, then rotate the multifunction knob or use the pop-up numeric keypad to set the sample position. The settable range is from 10% to 90%. 5. Display-related Setting Press Display to enter the display setting menu.
  • Page 243 Chapter 11 Protocol Decoding RIGOL Line Number Time Frame ID DLC Decoded Data Event Table CAN Bus Figure 11-11 CAN Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
  • Page 244 Chapter 11 Protocol Decoding RIGOL data, it indicates that the decoded data are not fully displayed. At this time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the ➢...

  • Page 245: Flexray Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL FlexRay Decoding (Option) FlexRay is a type of differential serial bus configured with three consecutive segments (i.g. header, payload, and trailer). The oscilloscope samples the FlexRay signal at the specified sample position and judges each data point as logic "1" or logic "0"...
  • Page 246 Chapter 11 Protocol Decoding RIGOL desired baud rate. Set the signal type ⚫ Press Signal and rotate the multifunction knob to select a signal type that matches the actual FlexRay bus signal. Press down the knob to select it. You can also press Signal continuously or enable the touch screen to select it.
  • Page 247 Chapter 11 Protocol Decoding RIGOL Event table ⚫ Press Event Table to enter the event table setting menu. The event table displays the detailed decoding information in time order in the form of a table, so as to better observe the long decoded data. The decoding information includes the decoded data, the corresponding line number, time, frame ID, and Payload Length (PL).
  • Page 248 Chapter 11 Protocol Decoding RIGOL Set the view type: Press View, then rotate the multifunction knob ➢ to select the form of the event table to be viewed. Press down the knob to select it. You can also press View continuously or enable the touch screen to select it.

  • Page 249: I2S Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL TSS Sync Frame Frame ID PL HCRC CYC Data TCRC I2S Decoding (Option) The oscilloscope samples the I2S signal and judges each data point as logic "1" or logic "0" according to the preset threshold level. I2S decoding is required to specify the serial clock, channel signal, and the data's source channel.
  • Page 250 Chapter 11 Protocol Decoding RIGOL "Falling( )" as the desired clock edge. Set the WS source and the threshold ⚫ Press WS and rotate the multifunction knob to select the desired ➢ channel, and then press down the knob to select it. You can also press WS continuously or enable the touch screen to select it.
  • Page 251 Chapter 11 Protocol Decoding RIGOL Set the WS Low ⚫ Press WS Low continuously to select "Left" or "Right". Endian ⚫ Press Endian to select "LSB" or "MSB". By default, it is "LSB". Polarity setting ⚫ Press Data Polarity continuously to select Positive or Negative the polarity for data decoding.
  • Page 252 Chapter 11 Protocol Decoding RIGOL Line Number Time Left Channel Data Right Channel Event Table I2S Bus Figure 11-14 I2S Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.

  • Page 253: 1553B Decoding (Option)

    Chapter 11 Protocol Decoding RIGOL time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the ➢ corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.
  • Page 254 Chapter 11 Protocol Decoding RIGOL about 2 s after you stop modifying the threshold. 4. Display-related setting Press Display to enter the display setting menu. Set the display format ⚫ Press Format, rotate the multifunction knob to select the display format of the bus data.
  • Page 255 Chapter 11 Protocol Decoding RIGOL Line Number Time Word Type Data Error Event Table 1553B Bus Figure 11-15 1553B Decoding Event Table Note: When you adjust the horizontal time base, the waveform displayed ⚫ on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed.
  • Page 256 Chapter 11 Protocol Decoding RIGOL time, you can view the details in the "Packets" view. Export: If you select "Packets", you can export time and the ➢ corresponding decoded data. Press Export, the save setting menu is displayed. You can export the data table of the packets to the internal or external USB storage device (when detected) in CSV format.

  • Page 257: Chapter 12 Reference Waveform

    Chapter 12 Reference Waveform RIGOL Chapter 12 Reference Waveform MSO5000 series oscilloscope provides 10 reference waveform positions (Ref1-Ref10). In the actual test process, you can compare the signal waveform with the reference waveform to locate the failure. Contents in this chapter: To Enable Ref Function ◼...

  • Page 258: To Enable Ref Function

    Chapter 12 Reference Waveform RIGOL To Enable Ref Function Press Ref on the front panel to enable the reference waveform function, or enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then, tap the "Ref" icon to enable the reference waveform function.

  • Page 259: To Save To Internal Memory

    Chapter 12 Reference Waveform RIGOL Press VOffset, then rotate the multifunction knob or use the pop-up ⚫ numeric keypad to set the vertical offset of the reference waveform. You can also enable the touch screen and use the "Drag" gesture to adjust the vertical offset.

  • Page 260: To Reset The Reference Waveform

    Chapter 12 Reference Waveform RIGOL To Reset the Reference Waveform Press More → Reset, and the reference waveform is restored to the position where the source channel waveform is located when the SaveToRef operation was executed. Color Setting MSO5000 series oscilloscope provides five colors (gray, green, blue, red, and orange) to mark the reference waveforms of different channels in order to distinguish the reference waveforms of different reference waveform channels.

  • Page 261: To Export To Internal Or External Memory

    Chapter 12 Reference Waveform RIGOL To Export to Internal or External Memory You can also save the current reference waveform to the internal memory or external USB storage device. The file format of the reference waveform is ".ref", ".bin", or ".csv".

  • Page 263: Chapter 13 Pass/Fail Test

    Chapter 13 Pass/Fail Test RIGOL Chapter 13 Pass/Fail Test During the product design and manufacturing process, you usually need to monitor the variations of the signal or judge whether the product is up to standard. The pass/fail test function of MSO5000 series oscilloscope can accomplish this task perfectly.

  • Page 264: To Enable Or Disable The Pass/Fail Test Function

    Chapter 13 Pass/Fail Test RIGOL To Enable or Disable the Pass/Fail Test Function Press Utility → PassFail to open the pass/fail test setting menu, or enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation.

  • Page 265: To Create A Mask

    Chapter 13 Pass/Fail Test RIGOL To Create a Mask Press Mask → Create to self-define the mask of the pass/fail test. Press Range and rotate the multifunction knob to select the mask range. Press down the knob to select it. You can also press Range continuously or enable the touch screen to select it.

  • Page 266: To Set The Output Form Of The Test Results

    Chapter 13 Pass/Fail Test RIGOL them to the current pass/fail test function. To Set the Output Form of the Test Results Press Option to enter the "Option" menu. You can set what the oscilloscope will execute when test results are detected according to your needs.

  • Page 267: To Enable Or Disable The Display Of The Statistics Of The Test Results

    Chapter 13 Pass/Fail Test RIGOL To Enable or Disable the Display of the Statistics of the Test Results Press Information continuously to enable or disable the display of the statistics of the test results. You can also enable the touch screen to tap the icon at the right-upper corner of the statistics window to close it.

  • Page 269: Chapter 14 Waveform Recording & Playing

    Chapter 14 Waveform Recording & Playing RIGOL Chapter 14 Waveform Recording & Playing Waveform recording & playing function can play the recorded waveforms of the analog input channels (CH1-CH4) and the digital channels (D0-D15), enabling you to analyze the waveforms better.

  • Page 270: Common Settings

    Chapter 14 Waveform Recording & Playing RIGOL Common Settings Press Utility → Record to enter the waveform recording function setting menu. You can also enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then, tap the "Record"...

  • Page 271: Record Options

    Chapter 14 Waveform Recording & Playing RIGOL 4. Set Transition Press Jump To continuously to select to jump to the recorded end frame Last) or the recorded start frame ( First). For settings of the start and end frames, refer to descriptions in "Play Options".

  • Page 272: Play Options

    Chapter 14 Waveform Recording & Playing RIGOL Memory Depth = Sample Rate x Horizontal Time Base x Number of Grids in the Horizontal Direction. Therefore, the maximum number of frames of waveform recording is also related to the "Sample Rate" and "Horizontal Time Base". This oscilloscope provides ceaseless recording for a maximum of 450,000 frames of real-time waveforms.
  • Page 273 Chapter 14 Waveform Recording & Playing RIGOL 5. End Frame Press End Frame, then rotate the multifunction knob or use the pop-up numeric keypad to set the end frame of playback. The default is the number of frames of the recorded waveforms.

  • Page 275: Chapter 15 Search And Navigation Function

    Chapter 15 Search and Navigation Function RIGOL Chapter 15 Search and Navigation Function The search function allows you to search for relevant events based on the search condition that you set. The navigation function includes the recording & playing navigation, time navigation, and event navigation.

  • Page 276: Search Function

    Chapter 15 Search and Navigation Function RIGOL Search Function The search function enables you to search the channel edge, Pulse trigger, Runt trigger, Slope trigger, RS232 trigger, I2C trigger, or SPI trigger. Press Search on the front panel to enable the search setting menu. You can also enable the touch screen...
  • Page 277 Chapter 15 Search and Navigation Function RIGOL knob or use the pop-up numeric keypad to set the thresholds of SCL and SDA. SPI: Press Type to select "SPI" as the search type. For SPI Setup menu ⚫ settings, refer to descriptions in "SPI Trigger (Option)". Press Threshold to enter the threshold setting menu.

  • Page 278: Navigation Function

    Chapter 15 Search and Navigation Function RIGOL navigation combination keys to make navigations at a step of 1. For details, refer to descriptions in "Navigation Function". 6. Save You can save the event mark data to the internal memory or external USB storage device in "*.csv"...
  • Page 279 Chapter 15 Search and Navigation Function RIGOL the event mark table. Press to navigate to the previous event (the serial number in the mark table decreases); press to navigate to the next event (the serial number in the mark table increases); the key is disabled in the event navigation.

  • Page 281: Chapter 16 Display Control

    Chapter 16 Display Control RIGOL Chapter 16 Display Control In the display control setting menu, you can set the parameters such as the waveform display type, persistence time, intensity, grid type, grid brightness, and etc. Contents in this chapter: To Select the Display Type ◼...

  • Page 282: To Select The Display Type

    Chapter 16 Display Control RIGOL To Select the Display Type Press Display to enter the display control setting menu. Press Type continuously to set the waveform display mode to "Vector" or "Dots". Vector display: indicates that the sample points are connected by lines and ⚫...

  • Page 283: To Set The Waveform Intensity

    Chapter 16 Display Control RIGOL To Set the Waveform Intensity Press Intensity, then rotate the multifunction knob at a small step value or use the pop-up numeric keypad to set the waveform intensity. Note that in the non-menu operation mode, you can also rotate the multifunction knob to adjust the waveform brightness of the channel.

  • Page 284: Scale

    Chapter 16 Display Control RIGOL range available is from 1% to 100%. Scale Press Show Scale continuously to enable or disable the scale display on the screen. By default, it is set to "OFF". Note: When the digital channel is enabled, the scale in the vertical direction is hidden automatically.

  • Page 285: Chapter 17 Function/Arbitrary Waveform Generator (Option)

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Chapter 17 Function/Arbitrary Waveform Generator (Option) MSO5000 series has an optional built-in dual-channel, 25 MHz signal source, which integrates the signal source and the oscilloscope into one, providing great convenience for engineers who need to use the signal source and oscilloscope at the same time.

  • Page 286: To Output Basic Waveforms

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL To Output Basic Waveforms Press GI on the front panel or enable the touch screen to tap the GI label at the bottom of the screen to enable/disable the output of the [GI] connector on the front panel, and enter the Function/Arbitrary Waveform Generator setting interface.

  • Page 287: To Output Square

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL continuously to select it. Also, you can enable the touch screen to select it. Rotate the multifunction knob or use the pop-up numeric keypad to set the offset or low level value of the current signal. When Impedance is set to "HighZ", the available range is from (-2.5 V+currently set amplitude value/2) to (2.5 V-...

  • Page 288: To Output Ramp

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL To Output Ramp Press Wave, rotate the multifunction knob to select "Ramp". Press down the knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the ramp waveform. For setting methods, refer to descriptions in "To Output Sine".

  • Page 289: To Output Dc

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Press Settings → Duty Cycle, then rotate the multifunction knob or use the pop-up numeric keypad to set the duty cycle of the current pulse signal. Its settable range is from 10% to 90%.

  • Page 290: Sinc

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL offset or low level value of the current signal. 3. Set the impedance Press Impedance continuously to set the output impedance of the Function/Arbitrary Waveform Generator. It can be set to "HighZ" or "50Ω".

  • Page 291: Exp.fall

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Exp.Fall Press Wave, rotate the multifunction knob to select "Exp.Fall". Press down the knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the Exp.Fall waveform (as shown in the figure below).

  • Page 292: Gauss

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Gauss Press Wave, rotate the multifunction knob to select "Gauss". Press down the knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the Gauss waveform (as shown in the figure below).

  • Page 293: Haversine

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Haversine Press Wave, rotate the multifunction knob to select "Haversine". Press down the knob to select it. You can also press Wave continuously or enable the touch screen to select it. At this time, you can set the parameters for the Haversine waveform (as shown in the figure below).

  • Page 294: To Create The Waveform

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Set the waveform range ⚫ Press Region continuously to set the waveform in the "Cursor" or "Screen" region for load. When "Cursor" is selected, press Cursor A or Cursor B and rotate the multifunction knob to adjust the positions of the two cursors respectively;...
  • Page 295 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL select "Offset" or "Low Level". You can also press Offset or Low Level continuously to select it. Also, you can enable the touch screen to select it. Rotate the multifunction knob or use the pop-up numeric keypad to set the offset or low level value of the current signal.

  • Page 296: To Edit Waveforms

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL waveforms and output the edited waveforms. Save the arbitrary waveform ⚫ Press Save to enter the file saving interface. Please refer to descriptions in "Store and Load" to save the currently edited waveform file to the internal or external memory in "*.arb"...

  • Page 297: Modulation

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL waveform. Edit Points ⚫ Press Edit Points to enter the point editing menu. You can specify the voltage value for each waveform point to define the waveforms. Current Point ➢ Press PointX, then rotate the multifunction knob or use the pop-up numeric keypad to select the points to be edited.
  • Page 298 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Press Settings → Type, and rotate the multifunction knob to select "Modulation", and then press down the knob to select it. You can also press Type continuously or enable the touch screen to select it.
  • Page 299 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL 3. Set the Modulation Depth The modulation depth refers to the strength of the AM and is expressed in percentage. Press AM Depth, then rotate the multifunction knob or use the pop-up numeric keypad to set the AM depth of the modulating waveform. The available range is from 0% to 120%.

  • Page 300: Fsk

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Press Deviation, then rotate the multifunction knob or use the pop-up numeric keypad to set the frequency deviation of modulating waveform from the carrier frequency. The available range of the frequency deviation is from 1 Hz to...
  • Page 301 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL enable the touch screen to select it. 1. Set the Sweep Type Press Sweep Type, and rotate the multifunction knob to select the desired sweep type, and then press down the knob to select it. You can also press Sweep Type continuously or enable the touch screen to select it.
  • Page 302 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL the range is from 0 s to 500 s. End Keep ⚫ End keep indicates the time that the output signal continues outputting at the "End Freq" after the Function/Arbitrary Waveform Generator sweeps from "Start Freq"...

  • Page 303: Burst

    Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL Burst The built-in Function/Arbitrary Waveform Generator of MSO5000 series oscilloscope supports outputting the burst waveforms with a specified number of cycles. It supports using internal and manual trigger sources to control the output of the burst waveforms.
  • Page 304 Chapter 17 Function/Arbitrary Waveform Generator (Option) RIGOL also press Trig Source continuously or enable the touch screen to select it. The available trigger sources include Internal and Manual. For the Infinite burst type, the Trig Source menu is disabled and grayed out.

  • Page 305: Chapter 18 Store And Load

    Chapter 18 Store and Load RIGOL Chapter 18 Store and Load You can save the current settings, waveforms, screen image, and parameters of the oscilloscope in internal memory or external storage device (such as USB storage device) in various formats and load the stored settings or waveforms when needed.

  • Page 306: Storage System

    Chapter 18 Store and Load RIGOL Storage System Press Storage on the front panel to enter the store and load setting interface. It provides one USB HOST interface on the front panel, which can all be connected to the USB storage device for external storage. The USB storage devices connected are marked as "Removable USB Disk(D)", "Removable USB Disk(E)", "Removable USB...
  • Page 307 Chapter 18 Store and Load RIGOL 2. Wave Press Save Wave to enter the waveform storage setting interface. Save the main setting information (e.g. "On/Off" state of the channel, vertical scale, and horizontal time base) and waveform data of all enabled channels (analog channel and digital channel) to the external memory.

  • Page 308: Load Type

    Chapter 18 Store and Load RIGOL Load Type This oscilloscope provides two load types: waveform load and setup load. The descriptions of each load type are as follows. 1. Waveform Load Press Load Wave to load the waveforms from the internal memory or the external USB disk.
  • Page 309 Chapter 18 Store and Load RIGOL overwritten and asking you whether to continue or not. 6) Press Save to save the set setup file to the selected folder in "*stp" format. After saving the reference waveform, press Ref → More → Export to enter the disk management interface of reference waveform file storage.

  • Page 310: External Storage And Load

    Chapter 18 Store and Load RIGOL External Storage and Load Before external storage and recall, ensure that the USB disk is properly connected. The external memory supports image saving, waveform saving, setup saving, waveform loading, and setup loading. 1. Save the Specified Type of File in the External USB Storage Device...

  • Page 311: To Select A File Type

    Chapter 18 Store and Load RIGOL Figure 18-1 Disk Management Interface Execute the following operations through the disk management menu: To Select a File Type ⚫ To Create a Folder ⚫ To Delete a File or Folder ⚫ To Copy and Paste a File or Folder ⚫...
  • Page 312 Chapter 18 Store and Load RIGOL Figure 18-2 To Create a Folder This oscilloscope supports Chinese/English input method. The length of the folder name is limited to 22 bytes (one Chinese character occupies two bytes). The following part introduces how to input a folder name using Chinese/English input method.
  • Page 313 Chapter 18 Store and Load RIGOL 1. Select English Input Method If the current input method is "En/中/繁", please go to Step 2. If the current input method is "中/繁/En" or "繁/En/中", rotate the multifunction knob select the input switch key and press the knob continuously to switch to "En/中/繁".
  • Page 314 Chapter 18 Store and Load RIGOL 6. After finishing the input, rotate the multifunction knob and press OK. The oscilloscope will create a folder or a specified type of file with this name under the current directory. Simplified Chinese (or Traditional Chinese) Input Method For example, create a folder with the name "文件名".

  • Page 315: To Delete A File Or Folder

    Chapter 18 Store and Load RIGOL then "文" is input in the "Name Input Area". If the Chinese character is not found in the current page, press to go to the next page until you find the desired character. 4. Input the Other Characters Refer to Step 3 and use the same method to input the remaining Chinese characters "件名"...

  • Page 316: To Copy And Paste A File Or Folder

    Chapter 18 Store and Load RIGOL Delete a File or Folder from the External Memory Press Storage → Disk and rotate the multifunction knob to select the external memory. Press down the knob to open it. Rotate the multifunction knob to select the file or the folder to be deleted.

  • Page 317: To Clear The Internal Memory Safely

    Chapter 18 Store and Load RIGOL To Clear the Internal Memory Safely Press Storage → Disk, rotate the multifunction knob to select the internal memory "Local Disk(C)". Press SecurityClear, and then a prompt message for confirming security clear is displayed.
  • Page 318 Chapter 18 Store and Load RIGOL Channel Coupling BW Limit Attenuation Input Impedance 1 MΩ Invert Fine Channel Unit Display Label Ch-Ch Skew Offset Cal Acquire Acquisition Mode Normal Memory Depth Auto Anti-Aliasing Trigger Trigger Type Edge Trigger Source Selection...
  • Page 319 Chapter 18 Store and Load RIGOL Output Frequency 1 kHz Amplitude 500 mV Offset Start Phase 0° Setting Type Impedance HighZ Cursor Mode Manual Select Source 100 mV -100 mV Vertical Unit Source Hori. Unit Region Main Track AX Source BX Source -1 μs...
  • Page 320 Chapter 18 Store and Load RIGOL Save Setup File Type *.stp Window Show Load Wave File Type *.wfm Load Setup File Type *.stp Disk File Type Utility Sound PassFail Enable Source Operate Stop Range Screen X Mask 0.24 div Y Mask 0.48 div...
  • Page 321 Chapter 18 Store and Load RIGOL Jump To First Save First System Power On Default AUX Out TrigOut Key Locker Unlocked HDMI Output HDMI Resolution 1280x720 SelfCal Window Open Auto Config Peak to Peak Overlay Coupling Printer Copies Paper Size...
  • Page 322 Chapter 18 Store and Load RIGOL SourceB Offset Scale 500 mV A× B Operation SourceA SourceB Offset Scale 500 mU A÷B Operation SourceA SourceB Offset Scale 500 mU Operation Source Offset 0 dBV Scale 2 dB Unit dBm/dBV Start-End Start Freq...
  • Page 323 Chapter 18 Store and Load RIGOL SourceA SourceB Wave Size Medium Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Sensitivity 0.3 Div Operation SourceA SourceB Wave Size Medium Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Sensitivity 0.3 Div Operation SourceA Wave Size Medium Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Sensitivity 0.3 Div...
  • Page 324 Chapter 18 Store and Load RIGOL Offset Scale 500 mU Invert Operation Source Offset Scale 500 mU Invert Operation Source Offset Scale 500 mU Invert Operation Source Offset Scale 500 mU Invert Operation Source Offset Scale 500 mU Invert Low Pass...
  • Page 325 Chapter 18 Store and Load RIGOL Offset Scale 500 mV ωc1 40 MHz ωc2 80 MHz Invert Band Stop Operation Source Offset Scale 500 mV ωc1 40 MHz ωc2 80 MHz Invert AX+B Operation Source Offset Scale 500 mV Invert...
  • Page 326 Chapter 18 Store and Load RIGOL Bus Status Baud 9.6 kbps Threshold Polarity Endian Data 8 bits Stop Bit 1 bit Parity None Package Separator 0(NUT) Bus Status Clock SCL Thre SDA Thre Exchange SCL/SDA Without Bus Status Mode Timeout Timeout 1 μs...
  • Page 327 Chapter 18 Store and Load RIGOL Signal CAN_L Baud 1 Mbps Sample Position FlexRay Bus Status Source Threshold Channel Selection Baud 10 Mbps Signal Sample Position Bus Status SCLK SCLK Thre SCLK Edge Rising SCLK Thre Data Data Thre Word Size...

  • Page 329: Chapter 19 Bode Plot

    Chapter 19 Bode Plot RIGOL Chapter 19 Bode Plot A Bode plot is a graph that maps the frequency response of the system. In the switch power supply and operational amplifier's circuit feedback network, the Bode plot provides a curve displaying the variation of gain and phase with the frequency for a loop analysis.

  • Page 330: To Enable The Bode Function

    Chapter 19 Bode Plot RIGOL To Enable the Bode Function You can also enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Then, tap the "Bode" icon to open the "Bode" setting menu. You can also tap Measure →...

  • Page 331: Parameter Setting

    Chapter 19 Bode Plot RIGOL Parameter Setting The oscilloscope will perform a test on the loop based on the parameter settings in the current bode menu and draw the Bode plot. Press Para Setting to set the following parameters. Source Outputs the sweep signal.

  • Page 332: Sweep Type

    Chapter 19 Bode Plot RIGOL Variant Amplitude StartFreq: indicates the start frequency of the sine wave. The default is 10 ⚫ Hz, and the range available is from 10 Hz to 25 MHz. StopFreq: indicates the stop frequency of the sine wave. The default is 100 ⚫...

  • Page 333: Out

    Chapter 19 Bode Plot RIGOL it. The available input channels include CH1-CH4. Indicates the channel that connects the feedback output signal. Before selecting the output source, connect the signal under test to the analog channel output terminal of the oscilloscope. Press Out and rotate the multifunction knob to select the desired channel, and then press down the knob to select it.

  • Page 334: Chart

    Chapter 19 Bode Plot RIGOL 1. Frequency: indicates the X-axis value of the cursor in the bode plot. 2. Gain: indicates the Y-axis value of the crossover point between the cursor and the purple curve. 3. Phase: indicates the Y-axis value of the crossover point between the cursor and the green curve.

  • Page 335: Display

    Chapter 19 Bode Plot RIGOL Display Press Display continuously to enable or disable the display of the bode plot window. If "Wave" is selected as the display type, turning on or off the Display menu indicates showing or hiding the display of the Bode Wave window. If "Chart" is selected as the display type, turning on or off the Display menu indicates showing or hiding the display of the chart display window.
  • Page 336 Chapter 19 Bode Plot RIGOL the upper-right corner of the Tips window to close the window. 19-8 MSO5000 User Guide...

  • Page 337: Chapter 20 System Utility Function Setting

    Chapter 20 System Utility Function Setting RIGOL Chapter 20 System Utility Function Setting In the system function setting menu, you can set the parameters for the remote interface and the system-related parameters. Contents in this chapter: Remote Interface Configuration ◼...

  • Page 338: Remote Interface Configuration

    Remote Interface Configuration MSO5000 series can communicate with the PC via the USB, LAN, or GPIB (requiring to work with RIGOL's USB-GPIB interface converter) interface. Before using the remote interfaces, configure the corresponding interface according to the introductions in the following section.
  • Page 339 Chapter 20 System Utility Function Setting RIGOL Invalid IP! ⚫ IP lost! ⚫ Please wait... ⚫ IP Configuration Type The configuration type of the IP address can be DHCP, Auto IP, or Static IP. For different IP configuration types, the configurations for IP address and other network parameters are different.
  • Page 340 Chapter 20 System Utility Function Setting RIGOL memory; if "Power On" is set to "Last", then DHCP and Auto IP are disabled at the next power-on. The oscilloscope will load the preset IP address automatically. 2. Set the Subnet Mask The format of the subnet mask is nnn.nnn.nnn.nnn;...

  • Page 341: To Set Mdns

    Chapter 20 System Utility Function Setting RIGOL When the three IP configuration types are all turned on, the priority of the ⚫ parameter configuration from high to low is "DHCP", "Auto IP", and "Static IP". The three IP configuration types cannot be all turned off at the same time.

  • Page 342: Usb Connection

    Chapter 20 System Utility Function Setting RIGOL Press HDMI to enter the HDMI setting menu. Press Output continuously to enable or disable the video output. ⚫ ON: You can connect the instrument to an external display via this interface ➢...

  • Page 343: System-Related

    Chapter 20 System Utility Function Setting RIGOL System-related Beeper When the beeper is enabled, you can hear the sound of the beeper when you perform the following operations: Press a key or a menu key on the front panel ⚫...

  • Page 344: Aux Output

    Chapter 20 System Utility Function Setting RIGOL Aux Output You can set the type of the signal output from the [TRIG OUT] connector on the rear panel. Press Utility → System, and then press the AUX Out key continuously to select "TrigOut"...

  • Page 345: Self-Calibration

    Chapter 20 System Utility Function Setting RIGOL Self-calibration The self-calibration program can quickly make the oscilloscope to work in an optimal state to get the precise measurement results. You can perform self-calibration at any time, especially when the changes of the ambient temperature reach or above 5℃.

  • Page 346: Print Setting

    Chapter 20 System Utility Function Setting RIGOL For detailed settings, refer to descriptions in "Quick Measurement after AUTO". Print Setting Connect the oscilloscope to the local area network via the network cable. The MSO5000 series supports printing the whole screen to the USB printer or network printer.

  • Page 347: Email

    Chapter 20 System Utility Function Setting RIGOL After the printer parameters are set, press Print to execute the print operation. Copies ⚫ Press Copies, then rotate the multifunction knob to set the number of copies to be printed or use the pop-up numeric keypad to set it. The settable range is from 1 to 99.

  • Page 348: Key Locker

    Chapter 20 System Utility Function Setting RIGOL Press Port to set the protocol port in the pop-up numeric keypad. Its range is from 1 65535. Set the user name ⚫ Press UserName to set the user name of the server. For detailed setting methods for the user name, refer to descriptions in "To Create a Folder".

  • Page 349: Quick Operation

    Chapter 20 System Utility Function Setting RIGOL Quick Operation You can set the shortcut functions for the Quick key on the front panel. Press Utility → More → Quick settings to enter the quick key setting menu. You can also enable the touch screen and then tap the function navigation icon at the lower-left corner of the screen to open the function navigation.
  • Page 350 Chapter 20 System Utility Function Setting RIGOL Data Source ⚫ Press Data Source continuously to select "Memory" or "Screen" as the source of the saved waveform. Format ⚫ Press Format and then rotate the multifunction knob to select the waveform format. Press down the knob to select it. You can also press Format continuously to select or enable the touch screen to tap the format.
  • Page 351 Chapter 20 System Utility Function Setting RIGOL Operation Type ⚫ Press Operation and then rotate the multifunction knob to select "Stat Reset". Press down the knob to select it. You can also press Operation continuously to select among the options, or enable the touch screen to tap the desired operation type.
  • Page 352 The file types include "*.png", "*.bmp", "*.jpg", and "*.tif". If you select "Text" under Screen Saver, press Text, and then the ⚫ filename input interface is displayed, e.g. inputting "RIGOL Scope". For details, refer to descriptions in "To Create a Folder". 2. Set the Wait Time...

  • Page 353: Self-Check

    The press SINGLE to switch to the next touch screen test interface, as shown in the figure below. At this time, you can pinch or stretch the RIGOL logo on the screen to zoom it out or in to check whether the gestures work normally. Press...

  • Page 354: System Time

    Chapter 20 System Utility Function Setting RIGOL RUN/STOP for three consecutive times to exit the touch screen test interface. System Time The system time is displayed at the lower-right side of the screen in "hh:mm (hour:minute)" format. When you save the waveform, the output file will contain the time information.
  • Page 355 Chapter 20 System Utility Function Setting RIGOL the screen will be updated. MSO5000 User Guide 20-19...

  • Page 357: Chapter 21 Remote Control

    Remote Control via LAN ◼ Remote Control via GPIB ◼ This chapter will illustrate how to use RIGOL's Ultra Sigma software to remotely control the oscilloscope via various interfaces. CAUTION Before setting up communication, please turn off the instrument to avoid causing damage to the communication interfaces.

  • Page 358: Remote Control Via Usb

    Chapter 21 Remote Control RIGOL Remote Control via USB 1. Connect the device Use a USB cable to connect the oscilloscope (USB DEVICE interface) with the PC (USB HOST interface). 2. Install the USB driver This oscilloscope is a USB-TMC device. After you connect the oscilloscope to the PC properly and power it on for the first time (the oscilloscope will be automatically configured with the USB interface).
  • Page 359 Chapter 21 Remote Control RIGOL MSO5000 User Guide 21-3...
  • Page 360 PC via the USB interface. You can also click to search for the resource. 4. View the device resource The searched instrument resource will be under the directory of "RIGOL Online Resource", with the model of the instrument and the USB interface information being displayed as follows.
  • Page 361 Chapter 21 Remote Control RIGOL 5. Control the instrument remotely Right-click the resource name "MSO5354 (USB0::0x1AB1::0x3514::MSO53541234567890::INSTR)" and select "SCPI Panel Control" to turn on the remote command control panel, through which you can send commands and read data. MSO5000 User Guide...

  • Page 362: Remote Control Via Lan

    Click to add it. 4. View the device resource The resources found will appear under the "RIGOL Online Resource" directory. For example, MSO5354 (TCPIP::172.16.3.14::INSTR). 5. Control the instrument remotely Right-click the resource name "MSO5354 (TCPIP::172.16.3.14::INSTR)" and select "SCPI Panel Control"...

  • Page 363: Remote Control Via Gpib

    Chapter 21 Remote Control RIGOL Remote Control via GPIB 1. Connect the device Use the USB-GPIB interface converter to extend the GPIB interface for the oscilloscope, and then use the GPIB cable to connect the oscilloscope to the PC to realize remote control.
  • Page 364 5. View the device resource The searched instrument resource will be under the directory of "RIGOL Online Resource", as shown in the following figure. 6. Control the instrument remotely Right-click the resource name "MSO5354 (GPIB0::18::INSTR)", and select "SCPI...

  • Page 365: Chapter 22 Troubleshooting

    The commonly encountered failures of the oscilloscope and their solutions are listed below. If the following problems occur, locate and resolve the problems according to the following steps. If the problems still persist, contact RIGOL and provide your instrument information to us.
  • Page 366 (3) Check whether there is a strong magnetic field around the instrument. If the instrument is close to the strong magnetic field (e.g. a magnet), please move the instrument away from the magnet field. (4) If the problem still persists, please contact RIGOL. 22-2 MSO5000 User Guide...

  • Page 367: Chapter 23 Appendix

    MSO5102 (100 MHz, 8 GSa/s, 100 Mpts, 2+16 CH MSO) MSO5102 MSO5074 (70 MHz, 8 GSa/s, 100 Mpts, 4+16 CH MSO) MSO5074 MSO5072 (70 MHz, 8 GSa/s, 100 Mpts, 2+16 CH MSO) MSO5072 Standard Accessories Power Cord Conforming to the Standard of the Destination Country...
  • Page 368 MIL-STD-1553 Serial Bus Trigger and Analysis (MIL-STD-1553) MSO5000-AERO Measurement Application Option Dual-channel 25 MHz Arbitrary Waveform Generator MSO5000-AWG Built-in Power Analysis MSO5000-PWR Note: For all the mainframes, accessories, and options, please contact the local office of RIGOL. 23-2 MSO5000 User Guide...

  • Page 369: Appendix B: Warranty

    If a product proves defective within the warranty period, RIGOL guarantees free replacement or repair for the defective product. To get repair service, please contact with your nearest RIGOL sales or service office. There is no other warranty, expressed or implied, except such as is expressly set forth herein or other applicable warranty card.

  • Page 371: Index

    Index RIGOL Index +Duty ........6-31 Hanning ........6-9 +Rate ........6-35 Haversine ......... 17-9 +Width ........6-30 Horizontal Expansion ....4-11 Acquisition Mode ......4-5 Horizontal Position ...... 3-3 AM ........17-14 I2C Decoding ......11-14 Anti-Aliasing ......4-11 I2C Trigger .......
  • Page 372 Chapter 22 Troubleshooting RIGOL Pulse Width Setting....5-11 Trigger LEVEL/Threshold Level ..5-3 Qualifier ........5-24 Trigger Mode ......5-4 Ramp ........17-4 Trigger Position ......5-26 -Rate ........6-35 tVmax ........6-31 Rectangular ....... 6-8 tVmin ........6-31 Rise Time ........ 6-30 Vamp ......

This manual is also suitable for:

Mso5000 seriesMso5074Mso5102Mso5104Mso5204Mso5354

Table of Contents

Save PDF
