ADM5120

4.7.30 MPMC PeriphID5-7 register, offset FD4h, FD8h, FDCh

Bit # Type Name
31:0 Reserved

4.7.31 Conceptual MPMC Peripheral ID register

Bit # Type Name
11:0 R Part number
19:12 R Designer
23:20 R Revision
31:24 R Configuration
Note:
The four eight-bit peripheral identification registers are described in the following sections:
MPMCPeriphID0 register
MPMCPeriphID1 registers on next page.
MPMCPeriphID2 registers on next page.
MPMCPeriphID3 registers on next page.

4.7.32 MPMC PeriphID0 register, offset FE0h

Bit # Type Name
7:0 R PartNumber0
31:8 Reserved
Note:
The MPMCPeriphID0 register is hard-coded and the fields within the register determine the reset value.

4.7.33 MPMCPeriphID1 register, offset FE4h

Bit # Type Name
3:0 R PartNumber1
7:4 R Designer0
31:8 Reserved
Note:
The MPMCPeriphID1 register is hard-coded and the fields within the register determine the reset value.

4.7.34 MPMC PeriphID2 register, offset FE8h

Bit # Type Name
3:0 R Designer1
7:4 R Revision
31:8 Reserved
Note:
The MPMCPeriphID2 register is hard-coded and the fields within the register determine the reset value.
ADMtek Inc.
Descriptions
Read undefined, must be written as zeros.
Descriptions
Identifies the peripheral. The part number for PL175 is
0x175.
Designer's ID number. This is 0x41 for ARM.
The peripheral revision number is revision dependent. 0
Configuration options are peripheral-specific. See
MPMCPeriphID3 register
Descriptions
These bits read back as 0x72.
Read undefined, must be written as zeros.
Descriptions
These bits read back as 0x1.
These bits read back as 0x1.
Read undefined, must be written as zeros.
Descriptions
These bits read back as 0x4.
These bits read back as the revision number,which can
be between 0 and 15.
Read undefined, must be written as zeros.
Register Description
Initial Value
0
Initial Value
175
41
0
Initial Value
72
Initial Value
1
1
Initial Value
4
0
4-50
