ADM5120
2.2

Pin Description by Function

ADM5120 pins are categorized into one of the following groups:
Section
ADMtek Inc.
Section 2.2.1 Network Media Connection
Section 2.2.2 Clock for Network
Section 2.2.3 LED
Section 2.2.4 GMII/MII Management
Section 2.2.5 Memory Bus
Section 2.2.6 SDRAM Control Signals
Section 2.2.7 UART
Section 2.2.8 JTAG
Section 2.2.9 General Purpose I/O (GPIO)
Section 2.2.10 PCI
Section 2.2.11 USB
Section 2.2.12 NAND Flash
Section 2.2.13 External CS/INT/wait
Interface Description
2-4
