ADMtek ADM5120 Datasheet page 27

ADM5120
Pin Name
CSX0#
INTX0
CSX_1#
INTX1#
ADMtek Inc.
BGA Ball PQFP Pin#
D19 149
G17 150
E18 151
C20 NA
Type Descriptions
if low, then wait until WAIT# go high
O External chip select, active low,
available if en_csx_intx enable in the
switch control register GPIO_config2
(B+BC), bit[4]
I External interrupt input, active high,
available if en_csx_intx enable in the
switch control register GPIO_config2
(B+BC), bit[4]
O External chip select 1, active low,
available if en_csx_intx_1 enable in the
switch control register GPIO_config2
(B+BC), bit[5]
I Internal pull down. external interrupt
input 1, active high, available if
en_csx_intx_1 enable in the switch
control register GPIO_config2 (B+BC),
bit[5]
Interface Description
2-11
