ADM5120
ADMtek Inc.
Offset Register
044h MPMCDynamicWR
048h MPMCDynamicRC
04Ch MPMCDynamicRFC
050h MPMCDynamicXSR
054h MPMCDynamicRRD
058h MPMCDynamicMRD
080h MPMCStaticExtendedWait
100h, MPMCDynamicConfig[0,1,2,3]
120h,
140h,
160h
104h, 124h, MPMCDynamicRasCas[0,1,2,3]
144h,
164h
200h, 220h, MPMCStaticConfig[0,1,2,3]
240h,
260h
204h, MPMCStaticWaitWen[0,1,2,3]
224h,
244h,
264h
208h, 228h, MPMCStaticWaitOen[0,1,2,3]
248h,
268h
20Ch, MPMCStaticWaitRd[0,1,2,3]
22Ch,
24Ch, 26Ch
210h, 230h, MPMCStaticWaitPage[0,1,2,3]
250h,
270h
214h, 234h, MPMCStaticWaitWr[0,1,2,3]
254h, 274h
218h, MPMCStaticWaitTurn[0,1,2,3]
238h,
258h,
278h
FD0h MPMCPeriphID4
FD4h, MPMCPeriphID5-7
FD8h,
FDCh
FE0h MPMCPeriphID0
FE4h MPMCPeriphID1
FE8h MPMCPeriphID2
FECh MPMCPeriphID3
Register Description
4-37
