ADM5120
4.2
System and Interrupt Registers
4.2.1 Interrupt Control Register Map
Offset Address
Base + 00
Base + 04
Base + 08
Base + 0c
Base + 10
Base + 14
Base + 18
Base + 1c
Base + 20
Base + 24
Note: Base = 0x1220_0000
4.2.2. Interrupt Request Source Description
Bit
[9]
[8]
[7]
[6]
[5]
[4]
[3]
[2]
[1]
[0]
Note: Only support level sensitive interrupts.
The external interrupt level, active high or low can be programmed
4.2.3 IRQ_status, offset: 0x00
Bits
Type
Name
9:0
RO
IRQ_status[7:0]
31:10 RO
Reserved
ADMtek Inc.
name
IRQ_status
IRQ_raw_status
IRQ_enable
IRQ_enable_clear
Reserved
INT_mode
FIQ_status
IRQ_test_source
IRQ_source_sel
INT_level
Name
Description
Sw_int
Switch interrupt, refer to B+B0, B+B4
PCI 2
PCI INT2
PCI 1
PCI INT1
PCI 0
PCI INT0
Intx_1
Internal interrupt 1, refer to GPIO[4] is the source
Intx_0
Internal interrupt 0, refer to GPIO[2] is the source
USB
USB interrupt source
UART1
UART1 interrupt source
UART0
UART0 interrupt source
timer
Timer interrupt, refer to B+F0 and B+F4
Description
The status of the interrupt sources after
masking.
1: the corresponding IRQ is active, and
generate the interrupt to MIPS
Register Description
Initial value
0
0
4-1
