ADM5120
19:15 RW fc_rec
24:20 RW PHY reset
29:25 RW Auto MDIX
30 RW Rec_mcc_average Per port PHY auto MDIX enable
31 Reserved

4.4.33 PHY_cntl3, offset 0x80

Bits Type Name
1:0 RW Rec_bslimit
3:2 RW FILTSEL
5:4 RW ISHSEL
6 RW IINSEL
7 RW APOLDIS
8 RW ENRJAB
9 RW DISJAB
10 RW NTH
11 RW FGDLINK
13:12 RW LFAILTM
14 RW INTCHKEN
15 RW CBDETEN
16 RW DISFEFI
21:17 RW FX_enable
31:22 Reserved

4.4.34 Pri_cntl, offset 0x84

Bits Type Name
5:0 RW Port_pri
7:6 Reserved
13:8 RW OffFC_en
15:14 Reserved
19:16 RW HN_rnd
31:20 Reserved

4.4.35 VLAN_pri, offset 0x88

Bits Type Name
5:0 RW VLAN_pri_en
ADMtek Inc.
the recommended FC value (reg4, bit10)
forced, 1: FC_rec ON
(default)
Per port PHY reset. 0: Reset. 1: Normal
Recommend MCC average enable Default value 0
Not Applicable
Description
Recommend base-line limit.
Pre-filter Recommend value.
Recommend Sample-Hold current.
Default: 0
Recommend Auto Polarity disable.
Recommend receive jabber enable.
Recommend transmit jabber disable.
Recommend Normal threshold.
Recommend force good link.
Recommend polarity link fail timer select. Default:
00(2sec). (3,4,8 sec)???
Recommend polarity LIU/LID interval check.
Recommend cable broken detect enable.
Disable far_end fault indication
Per port FX enable, default 0: disable
Not Applicable
Description
Force all the packet from the programmed port(s) are
priority 0: normal
→
Not Applicable
Auto-turn-off FC when the programmed ports receive
priority packet 0: disable
→
Not Applicable
The proportion of normal and high priority packet
0000 - unlimited, 0001 - 8:1, 0010 – 16:1 ...etc
Not Applicable
Description
Enable VLAN priority check
Note: [0] = port0, [1] = port 1 etc...
0: no
→
→
0: disable
→
Register Description
Initial value
11
10
00
0
0
1
0
0
0
00
1
0
00000
Initial value
Initial value
4-17
