Counter Reset Source
Counter Reset
Counter Value
Counter Current Value
8.6

Trigger Related Parameters

Under external trigger mode, you can set trigger activation, burst frame count, trigger delay,
trigger cache enable, and trigger debouncer. Different trigger sources can set various trigger
parameters, and their relation is shown below.
Parameters
Trigger Activation
Burst Frame Count
Trigger Delay
USB3.0 Board Level Camera
Read/Write
Read and write
Write is available
under certain
condition
Read and write
Read only
Figure 8-11 Counter Trigger Parameters
Table 8-3 Trigger Source and Trigger Parameter
Sources Software Trigger
User Manual
·
Description
disabled by default.
It selects the signal source of resetting counter.
Software is available only. It is disabled by default.
It resets counter and it can be executed when
selecting Software as Counter Reset Source.
It is the counter value with the range of 1 to 1023.
It displays the number of executed external trigger.
Hardware Trigger
×
√
√
23
Counter Trigger
√
√
√
×
√
√
