No. Area Name
6 Feature Panel
Click in the camera's feature panel to unfold the specific parameters, and set them according to
actual demands.
The camera's feature tree and parameters may differ by camera models.
Attribute
Device Control
Image Format
Control
Acquisition Control
Analog Control
LUT Control
Shading Correction
Digital IO Control
Counter And Timer
Control
Transport Layer
Control
Stream Control
User Set Control
USB3.0 Board Level Camera
Description
You can view and set features of the selected camera, and perform
operations such as importing, exporting, and saving features.
Table 6-2 Feature Tree Description
Description
You can view the device information, edit its name, reset the device, etc.
You can view and set the device's resolution, image reverse function, pixel
format, region of interest, test pattern, etc.
You can view and set the device's acquisition mode, frame rate, trigger
mode, exposure time, etc.
You can view and set the device's gain, black level, Gamma correction,
sharpness, etc.
You can view the Look-Up Table (LUT), and set its index and value.
You can set shading correction to correct shade.
You can set the different input and output signals.
You can view and set the counter-related parameters.
You can view and set the parameters of the device's transport layer.
You can view the size of payload, data head, and data end.
You can save or load the device's parameters.
